Johnson Controls ZL Series Installation Manual page 30

Table 11: ZL08 to 14 medium indoor blower - with powered convenience outlet
Compressor 1 Compressor 2
RLA LRA MCC RLA LRA MCC
208-3-60 16.5 110 26 16
230-3-60 16.5 110 26 16
12 (10)
460-3-60 7.2 52 11 7.8
575-3-60 5.7 43.8 9 5.7 38.9
208-3-60 18.6 149 29 19.6 136
230-3-60 18.6 149 29 19.6 136
14
(12.5)
460-3-60 9 60.9 14 8.2 66.1
575-3-60 7.1 56 11 6.6 55.3
1 Minimum Circuit Ampacity.
2 Dual element, time delay type.
3 HACR type per NEC.
4 Non-fused disconnect. Verify on the unit nameplate that the disconnect is properly sized for the application. Units with field
installed electric heat kits may exceed the factory installed disconnect amperage rating.
30 Installation Manual ZL Series 7.5- 12.5 Ton 60 Hertz R-410A
