- Page 1 Operating and maintenance instructions WAREMA basic shaft awnings Original instructions To be handed over to the opera- tor. Please keep for future use. Valid from 18 April 2024 Document number 2030531 [Rev. 4 - en]...
-
Page 2: Table Of Contents
Table of contents Table of contents Introduction........................3 Information on safety............................ 3 Information on the target group and application of these instructions............3 Explanation of the signal words........................3 Basic safety instructions..........................3 Product information......................5 Intended use..............................5 Parts description............................5 Electric drive data............................ -
Page 3: Introduction
The instructions contain important information on the Possible risk during operation operation, care and maintenance of this item. They describe how to operate products with WAREMA standard Incorrect operation can result in personal injury. The drives. Other drives and special solutions are not dealt with. - Page 4 Introduction Operation in the event of a power supply interruption Operation in winter (product with control system) An electrically-operated product cannot be operated Products operated by a control system may start moving without power. A lowered product may be subjected to at any time and without prior notice.
-
Page 5: Product Information
Additional loads on the product in the form of hanging channel) objects could damage the product or cause it to detach Bearing console Bracket for guide from the wall and are therefore not permitted. WAREMA will (e. g. bracket H3) not be liable for any ensuing damage. Inspection cover (optional) To ensure intended use of the product it must be raised in Fig. -
Page 6: Electric Drive Data
Product information Electric drive data Parameter Value Current consumption [A] 0.35–0.87 A Rated voltage 230 V/50 Hz Degree of protection IP 44 Short-term operation (S2) 4 min. Emissions sound pressure level < 70 dB(A) The sound pressure level LpA in a standard installation of the product on a test stand is ≤ 70 dB(A). -
Page 7: Wind Resistance
The achieved class of resistance to wind loads does not allow any conclusions to be drawn about the suitability for use (raising/ lowering, intermediate position) under actual wind loads. For this reason, WAREMA defines wind speed limits. Wind speed limits are the maximum permissible wind speeds which must not be exceeded. When the wind speed limits are reached, the product must be raised. -
Page 8: Operation
Operation Operation Operation using a central control unit NOTICE INFO Product damage from failure of the control unit! Only operate the product if it is in technically Under certain external conditions, such as a power perfect condition. failure or a malfunction, the control unit will not be Do not operate a product if it is damaged. -
Page 9: Incorrect Operation
Operation Operation in stormy weather Movement Turn the crank. The The product must be raised product moves in the by hand before a bad selected direction. weather front passes over, even if a control is being used. The control triggers a move command for the product if the set limit val- ue is exceeded in order to... -
Page 10: Service
Operation Operation in cold weather or winter INFO The awning fabric can become electrostatically NOTICE charged. Contact with people or objects may result Product damage from forceful operation! in electrostatic discharge from charged fabric. After an impact with condensation water, rain or snow, the product can freeze up at low Cleaning and care temperatures. - Page 11 Cleaning with water and a mild soapy solution is recommended. If you Do not use high pressure washers, steam have any questions, please contact your WAREMA washers, abrasive sponges, abrasive cleansers, specialised retailer for further information. or aggressive cleaning agents or solvents such as alcohol or naphtha.
- Page 12 Service Performing detailed cleaning Drying the product Lower the product into the lower limit position. Prepare a bucket with water and cleaning agent for sun shading Leave awning fabric that has products. Note the dosing become wet to air-dry. quantities specified by the cleaning agent manufacturer.
-
Page 13: Maintenance
INFO To ensure proper functioning and your continued Weave flaws enjoyment of the product, WAREMA recommends Spinning of the yarns as well as warping in the weaving mill having it professionally maintained once a year. and the weaving process itself is executed under tension. -
Page 14: Warranty
Dismantling of the product must be undertaken by at no charge. a qualified specialist. Ask WAREMA for any missing Deletion of personal data contained in documents before commencing maintenance. the electric device before disposal is the responsibility of the owner/operator. -
Page 15: Troubleshooting
Troubleshooting Troubleshooting INFO Problems described here without reference to a qualified specialist or certified electrician may be resolved independently. All other problems listed must be handled by a qualified specialist or certified electrician. Fault: The motor is not functioning Cause Remedy Note The thermal protection switch on the... -
Page 16: Declaration Of Conformity
Used for motor drives without an integrated radio receiver. Directive on radio equipment 2014/53/EU (RED): Use for motor drives with an integrated radio receiver or for WAREMA components with an integrated radio receiver. Person in charge of the compilation of the technical documents: Elke Granzer; for address, see manufacturer.
