- Page 1 WAREMA articulated arm awning Type 530 Operating and maintenance instructions To be handed over to the operator – original instructions Valid from 01 April 2013 Document number 866011 [Rev. 2 - en]...
-
Page 2: Table Of Contents
Table of contents Table of contents Introduction........................3 Information on safety............................ 3 Information on the target group and application of these instructions............3 Explanation of symbols and signs....................... 3 Basic safety instructions..........................4 Product information......................5 Intended use..............................5 Parts description............................5 Technical data/accessories...........................5 Wind class.............................. -
Page 3: Introduction
No other alterations, additions, conversions or maintenance work is to be carried out on the product other than as described in these instructions without the written approval of WAREMA. 866011 [Rev. 2 - en]/2013-04-01 Page 3 | 14... -
Page 4: Basic Safety Instructions
Introduction Basic safety instructions Operation in wet weather In rain and at a smaller inclination angle than specified (see The safety instructions and warnings described here Chapter 2.5/Page 6), it is not permissible to extend the are intended to safeguard your health and to protect the awning. -
Page 5: Product Information
Parameter Value it to become detached from the wall and are therefore not Rated torque 25 - 40 Nm permitted. WAREMA will not be liable for any resulting Output speed 17 rpm damage. Mains voltage 230 V AC/50 Hz... -
Page 6: Rain Class
Conformity is part of these instructions. Only operate the product if it is in technically perfect condition. Name: WAREMA Renkhoff SE Do not operate a product if it is damaged. Always contact the specialist dealer and protect the product against being operated as agreed with... -
Page 7: Product With Motor
Operation Product with motor Retracting using the sunblind push button/venetian blind switch CAUTION Risk of crushing from failure to exercise care during Press the "UP" button and hold if necessary. operation. Persons who are located within the projection area may be injured. Turn the toggle switch to Keep the projection area clear of persons. -
Page 8: Incorrect Operation
Operation Incorrect operation Operation in wet weather NOTICE Access to operating elements Impairment of awning fabric through dampness. Never let children play Dampness promotes wrinkling and waffling of the with the operating ele- fabric. ments of the product, such as the hand-held Protect the awning fabric from wet weather. -
Page 9: Maintenance
Further tips and care instructions can be found at effectiveness of these measures depends on a large www.warema.de. number of factors that vary from case to case. Always follow the manufacturer instructions when Clean the surfaces with a suitable cleaning using chemical cleaning products. -
Page 10: Maintenance
Technical fabrics may exhibit certain characteristics due to The WAREMA warranty becomes invalid if the unit is production and sizing that may appear to the operator to be not maintained properly at least once a year. -
Page 11: Spare Parts/Repairs
A lack of appropriate product knowledge Dismantling of the product must be undertaken by may lead to dangerous situations. a qualified specialist. Ask WAREMA for any missing documents before commencing maintenance. The product should only be repaired by a qualified specialist. -
Page 12: Troubleshooting
Troubleshooting Troubleshooting INFO Problems described here without a reference to a qualified specialist or certified electrician may be rectified independently. All other problems described here are only to be dealt with by a qualified specialist or certified electrician. Problem Possible cause Remedy Motor is not operating Motor is faulty... -
Page 13: Ec Declaration Of Conformity
EC Declaration of Conformity EC Declaration of Conformity The product: WAREMA patio awning Type: Articulated arm awning 530 Cassette awning 550, 580 Articulated arm awning 630, 650 Cassette awning 680 Articulated arm awning 700 S Articulated arm awning 730, 740, 750... - Page 14 WAREMA Renkhoff SE - Hans-Wilhelm-Renkhoff-Straße 2 - 97828 Marktheidenfeld - Germany www.warema.com - info@warema.com...
