- Page 1 Operating and maintenance instructions WAREMA articulated arm awning Terrea 700S Original instructions To be handed over to the opera- tor. Please keep for future use. Valid from 1 September 2023 Document number 2003320 [Rev. 5 - en]...
- Page 2 Table of contents Table of contents Introduction........................3 Information on safety............................ 3 Information on the target group and application of these instructions............3 Explanation of the signal words........................3 Basic safety instructions..........................3 Product information......................5 Intended use..............................5 Parts description............................5 Electric drive data............................
- Page 3 The instructions contain important information on the Possible risk during operation operation, care and maintenance of this item. They describe how to operate products with WAREMA standard Incorrect operation can result in personal injury. The drives. Other drives and special solutions are not dealt with.
- Page 4 Introduction Operation in the event of a power supply interruption Operation in icy conditions/winter (general procedure) An electrically-operated product cannot be operated The operation of the product with temperatures around or without power. A extended product may be subjected to below the freezing point can lead to malfunctions and/or impermissible loads when bad weather fronts pass over damage to property in the case of unfavourable installation...
- Page 5 A lower wind speed may have been it to become detached from the wall and are therefore stipulated in the handover report. not permitted. WAREMA will not be liable for any ensuing The wind speed of 10 m/s is defined as a damage.
- Page 6 Declaration of performance Operation The declaration of performance can be INFO found at (www.warema.de/ce). Only operate the product if it is in technically perfect condition. Do not operate a product if it is damaged. Always contact the specialist dealer and protect the product against being operated as agreed with the specialist.
- Page 7 Operation INFO Operation in stormy weather of the motors used are not intended for continuous Before bad weather ar- operation. rives (forecast heavy rain, storm, thunder, hail etc.) or The integrated thermal protection switches the motor if warnings of bad weather off after approx.
- Page 8 Use of the product in a manner that is not intended or Product damage from forceful operation! failure to care for and check the product improperly render the product warranty from WAREMA void. After an impact with condensation water, rain or snow, the product can freeze up at low Proper and regular cleaning and maintenance and the temperatures.
- Page 9 It is important to abide by the interval of one year. Tip/recommendation Using the WAREMA cleaning glove together with Purpose of cleaning and care WAREMA cleaning agent concentrate for sun shading products is an ideal way to properly clean The benefit provided by regular and proper cleaning and product surfaces.
- Page 10 Vacuum cleaner (optional) the procedure as needed based Bucket on the degree of soiling. Low-calcium water (recommendation) WAREMA cleaning agent for sun shading products (do not use on wood products) WAREMA cleaning glove Remove the detached soiling Cotton cloth before drying.
- Page 11 Drying the product INFO To ensure proper functioning and your continued extend the product into the lower limit position. enjoyment of the product, WAREMA recommends having it professionally maintained once a year. Leave awning fabric that has Information on this can be obtained from become wet to air-dry.
- Page 12 [excerpt Dismantling of the product must be undertaken by from the Guideline for the Evaluation of Preassembled a qualified specialist. Ask WAREMA for any missing Awning Fabrics – published by the ITRS Industrieverband documents before commencing maintenance.
- Page 13 Dismantling/disposal Disposal Should the product no longer be required, ensure that it is disposed of correctly in accordance with the relevant regulations. Components identified in this manner should not be disposed of with the household waste. Products marked with the symbol must be handled as follows according to legal regulations: The electric and electronic components removed from the electrically operated product and other...
- Page 14 Troubleshooting Troubleshooting INFO Problems described here without reference to a qualified specialist or certified electrician may be resolved independently. All other problems listed must be handled by a qualified specialist or certified electrician. Fault: the motor is not functioning Cause Remedy Note The thermal protection switch on the...
- Page 15 Used for motor drives without an integrated radio receiver. Directive on radio equipment 2014/53/EU (RED): Use for motor drives with an integrated radio receiver or for WAREMA components with an integrated radio receiver. Person in charge of the compilation of the technical documents: Elke Granzer; for address, see manufacturer.
- Page 16 Hans-Wilhelm-Renkhoff-Straße 2 97828 Marktheidenfeld Germany WAREMA Renkhoff SE www.warema.com info@warema.com...
