A
.
Connector
Pinouts
This appendix contains
the pinouts for the
2060
CPU
board's:
Mouse/Keyboard
Connector
o
Serial Port(s)
Ethernet Connector
Video Connector
and
also contains a
signal description of
the
serial ports.
NOTE
In the following connectors, only
those pins
actually connected
to something are
listed;
open
pins are not documented.
A.l. Connectors on
the
2060
CPU
board
Table A-
1
Pinout of Mouse/Keyboard DB-15
Connector
Pin
Signal Pin
Signal
1
RXDOt
8
GND
2
GND
9
GND
3
TXDOt
10
VCC
4
GND
11
VCC
5
RXDlt
12
VCC
6
GND
14
VCC
7
TXDlt
15
VCC
+RXD0
and
TXDOarc
the keyboard
serial lines;
RXD1
and
TXD1
are the
mouse
serial lines.
