Installation, Start-Up and Service Instructions
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Step 1 - Prepare for Installation . . . . . . . . . . . . . . . 2
Step 2 - Receive Compressor . . . . . . . . . . . . . . . . . 3
Step 3 - Install Unit . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Step 7 - Assemble Water Piping . . . . . . . . . . . . . . 25
PREPARE FOR INITIAL START-UP . . . . . . . . . . . . . 26
Evacuate, Dehydrate and Leak Test . . . . . . . . . . . . 26
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Preliminary Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Start Compressor . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
High and Low-Pressure Switches . . . . . . . . . . . . . . 26
Adjust Capacity Control (if required) . . . . . . . . . . . 27
Capacity Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 574-603
Page
Printed in U.S.A.
Form 574-603
Open-Drive Compressors
• 5H40-5H86 FACTORY-INSTALLED ELECTRIC
UNLOADING
• 5H120/126 COMPRESSORS
• VALVES

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can be
hazardous due to system pressure and electrical components. Only
trained and qualified service personnel should install, repair, or
service air-conditioning equipment.
Untrained personnel can perform basic maintenance functions of
cleaning coils and filters and replacing filters. All other operations
should be performed by trained service personnel. When working
on air-conditioning equipment, observe precautions in the
literature, tags and labels attached to the unit, and other safety
precautions that may apply.
Follow all safety codes, including ANSI (American National
Standards Institute) Z223.1. Wear safety glasses and work gloves.
Use quenching cloth for unbrazing operations. Have fire
extinguisher available for all brazing operations.
It is important to recognize safety information. This is the safety-
alert symbol
. When you see this symbol on the unit and in
instructions or manuals, be alert to the potential for personal
injury.
Understand the signal words DANGER, WARNING, CAUTION,
and NOTE. These words are used with the safety-alert symbol.
DANGER identifies the most serious hazards which will result in
severe personal injury or death. WARNING signifies hazards
which could result in personal injury or death. CAUTION is used
to identify unsafe practices, which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability,
or operation.
WARNING
Before performing service or maintenance operations on unit,
turn off main power switch to unit. Electrical shock could
cause personal injury.
WARNING
Do not provide power to unit or turn-on compressor unless
suction and discharge service valves are open.
WARNING
CONTENTS UNDER PRESSURE
Compressor contains oil and refrigerant under pressure.
Pressure must be relieved before installation, servicing or
opening any connections.
Pg 1
7-24
5H
Replaces: 5F-H-24SI Rev B
