Summary of Contents for Profile Design HSC250
- Page 1 HSC250 Top Tube Flask HSC250 TOP TUBE FLASK REVISION 01-08-20-2024...
-
Page 2: Tools And Materials Required
Please read these instructions thoroughly before attempting to install this item. Proper installation is required for compliance with Profile Design's warranty policy. If you are not familiar with installation of bicycle accessories, please seek the assistance of your local Profile design dealer by logging on to www.profile-design.com and using "dealer search"... -
Page 3: Component List
HSC250 Top Tube Flask COMPONENT LIST QTY. Ref.# Part.# Part Description Req. B212 Cap - HSC250 600217 Bottle - HSC 250 414252 Cage - HSC250 313598 Bolt - M5x14 BHB 275673 Washer - M5x13x1... -
Page 4: Part Drawings
HSC250 Top Tube Flask PART DRAWINGS 295ml (10oz) 259 mm 90.6 mm 25 mm 39 mm 25 mm... - Page 5 HSC250 Top Tube Flask PRODUCT SPECIFIC SETUP LIMITATIONS +75°C -40°C WARNING While the product is dishwasher safe, we recommend cleaning with warm soapy water and a bottle brush to ensure a thorough clean. If you do use a dishwasher, please choose a setting that...
-
Page 6: Installation Instructions
HSC250 Top Tube Flask INSTALLATION INSTRUCTIONS 1. Ensure the contact area on the frame is clean prior to installation. 5. Align the bolt with the frame boss and carefully thread the bolt into the frame. 2. You may wish to install a protective sticker (not included) on the frame to protect the paint. - Page 7 HSC250 Top Tube Flask Cleaning the Bottle Using the bottle 1. For cleaning the flask a bottle brush and warm soapy water are recommended. 1. The cap pops off, rather than twisting. To remove, lever your finger under one side of the cap and pull it away from the flask.
-
Page 8: Warranty Policy
• Profile Design Worldwide Two Year Limited Warranty. • Profile Design, LLC (distributor) warrants to the original retail purchaser ("you") that the Profile Design product for which you received this warranty is free from defects in material and workmanship for (2) two years from the date of original retail purchase. For more details on this warranty, its exclusions and/or how to make a claim under the warranty please call +1 310.747.0085 extension 161 or visit... - Page 9 HSC250 Top Tube Flask 2677 El Presidio Street Long Beach, CA 90810 Ph: 310-884-7756 www.profile-design.com © Profile Design LLC...
