- Page 1 HSA Riser HSA RISER REVISION 01-02-06-2025...
- Page 2 Please read these instructions thoroughly before attempting to install this item. Proper installation is required for compliance with Profile Design's warranty policy. If you are not familiar with installation of Aerobars or their accessories, please seek the assistance of your local Profile design dealer by logging on to www.profile-design.com and using "dealer search"...
- Page 3 If anything is missing from the Riser kit please contact your dealer. Please note that threaded areas have been pre-treated by Profile Design during production with a special blue thread locking compound. This special compound is easy to detect on the threads of all bolts provided. If you cannot detect this thread locking compound or you are re-installing the bolt, re-apply a suitable thread locking compound as available from Loctite®...
- Page 4 HSA Riser COMPONENT LIST HSA Riser 45mm QTY. Ref.# Part.# Part Description Req. 293157 Riser - PFD HSA Riser 45mm BLK 313611 Bolt - M5 x 55mm SHB 275673 Washer 5.3 x 13 x 1.0mm HSA Riser 90mm QTY. Ref.# Part.# Part Description Req.
- Page 5 HSA Riser PART DRAWINGS...
- Page 6 HSA Riser TORQUE SETTINGS 1. A maximum of two layers can be stacked, using the provided 100mm screws and washers. 2. If the torque exceeds 1Nm, deformation may occur. Ref.# Location Torque Cage installation area...
- Page 7 INSTALLATION INSTRUCTIONS The following instructions use the HSA Mini BTA as an example. You can replace the HSA Mini BTA 2. Place the HSA Riser between the HSA Mini BTA and the bottle cage. with any standard spaced (64mm) BTA mount.
- Page 8 3. After placing it, use screws to secure it from the bottle cage side downward to the HSA Mini BTA: WARNING! Using bolts that are too short may lead to failure during use. • • HSA Riser(2pcs): Use the included M5x100mm screws with washers for securing. HSA Riser(1pcs): Use the included M5x55mm screws with washers for securing.
- Page 9 Profile Design Worldwide Two Year Limited Warranty Gallop Cycle Corp (hereinafter "Profile Design") the distributor, warrants to the original retail purchaser ("you") that the Profile Design product for which you received this warranty is free from defects in material and workmanship for (2) two years from the date of original retail purchase.
- Page 10 HSA Riser 2677 El Presidio Street Long Beach, CA 90810 Ph: 310-884-7756 www.profile-design.com...
