The table below describes the files that were selected to be included as part of this package.
Supplements, such as Figures and Illustrations, will appear as X number of Figures, X number of Illustrations, etc., rather
than naming each one.
E158873-A6215-DescriptionUL
Figure-26-Total
This material is provided on behalf of UL LLC (UL Solutions) or any authorized licensee of UL Solutions.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hanwha Vision PNM-C32083RQZ
Summary of Contents for Hanwha Vision PNM-C32083RQZ
- Page 1 The table below describes the files that were selected to be included as part of this package. Supplements, such as Figures and Illustrations, will appear as X number of Figures, X number of Illustrations, etc., rather than naming each one. E158873-A6215-DescriptionUL Figure-26-Total This material is provided on behalf of UL LLC (UL Solutions) or any authorized licensee of UL Solutions.
-
Page 2: Network Camera
Model: PNM-C32083RQZ, PNM-C16083RQZ Rating: PoE (55 Vdc), 0.75 A HANWHA VISION CO LTD Applicant Name and Address: 6, PANGYO-RO 319BEON-GIL, BUNDANG-GU SEONGNAM-SI GYEONGGI-DO 13488 KOREA This is to certify that representative samples of the products covered by this Test Report have been investigated in accordance with the above referenced Standards. - Page 3 It is a commercial equipment supplied from UL listed PoE (Power over Ethernet) input and installed by service personnel. Model Differences PNM-C32083RQZ is basic model. PNM-C16083RQZ is identical to basic model except model designation and sensor/lens module specification. Test Item Particulars...
- Page 4 Issue Date: 2024-06-26 Page 3 of 8 Report Reference # E158873-A6215-UL The product is intended for use on the following power systems : No direct connection Considered current rating of protective device as part of the building installation (A) : N/A Mains supply tolerance (%) or absolute mains supply : No direct connection The Risk Group of a lamp or lamp system (including LEDs) is : Exempt The following are available from the Applicant upon request : Installation (Safety) Instructions / Manual...
- Page 5 Issue Date: 2024-06-26 Page 4 of 8 Report Reference # E158873-A6215-UL BD1.0 TABLE: Production-Line Testing Requirements BD1.1 Electric Strength Test Special Constructions – Refer to Generic Inspection Instructions, Part AC for further information. Model Component Removable parts Test probe Test V rms Test V Test location...
- Page 6 Issue Date: 2024-06-26 Page 5 of 8 Report Reference # E158873-A6215-UL 4.1.2 TABLE: List of critical components Pass Object / part No. Manufacturer/ Type / model Technical data Product Category Mark(s) of Supplement ID trademark CCN(s) conformity Enclosure –Case LOTTE CHEMICAL HN-1068(+)(f1) Min.
- Page 7 Issue Date: 2024-06-26 Page 6 of 8 Report Reference # E158873-A6215-UL Transformer (T1) DONG IN SYSTEM UPDH110-T1 130 deg. C, See CO TLD enclosure for more detail. Transformer (T1) - DONG HEUNG UPDH110-T1 130 deg. C, See Alternate ELECTRONICS CO enclosure for more detail.
- Page 8 Issue Date: 2024-06-26 Page 7 of 8 Report Reference # E158873-A6215-UL INC MICRO- 3.4 V dc, Max Charging ENERGY DIV current: 300 mA Lithium Battery Interchangeable Interchangeable Diode (D41, 80 V, 500 Protection Circuit mA) and Resistor (R48, (BAT41) 3.3 Kohm) in series DC Fan (2ea) SUNONWEALTH EF5010BX-C05U-...
- Page 9 Issue Date: 2024-06-26 Page 8 of 8 Report Reference # E158873-A6215-UL Enclosures Type Supplement Id Description Photographs 03-01 External View - 1 Photographs 03-02 External View - 2 Photographs 03-04 Internal View - 1 Photographs 03-05 Internal View - 2 Photographs 03-06 IR LED Board - 1...
- Page 10 The following Page(s) are related to Diagrams-01. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
- Page 12 The following Page(s) are related to Diagrams-02. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
- Page 14 The following Page(s) are related to Manuals-01. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
-
Page 15: Explanation Of Graphical Symbols
overview IMPORTANT SAFETY INSTRUCTIONS 22. Screen distortion could occur outside of the subject distance. 23. While encoding, a real time fps fluctuation of ±1fps could occur. 1. Read these instructions. 24. Although a rapid change in temperature could cause frost inside the dome, there will be no problem with the video. - Page 16 overview Class construction Please read the following recommended safety precautions carefully. An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a ~ Do not place this apparatus on an uneven surface. protective earthing connection. ~ Do not install on a surface where it is exposed to direct sunlight, near heating equipment or heavy cold area.
-
Page 17: Optional Accessories For Installation
overview OPTIONAL ACCESSORIES FOR INSTALLATION You can purchase appropriate optional accessories available. Wall Mount and Pole Mount Mounting Hole Cover Hanging Mount Wall Mount Base Corner Mount Installation Box SBP-300WMW SBP-300PMW2 (Wall Mount) (Pole Mount) * SBP-300PMW2 required for pole installation SBP-315HMW SBP-156KMW SBP-300WMW1... - Page 18 Ceiling Mount Parapet Mount Assembly Individual Parts SBP-180CMB SBP-300LMW SBP-C15P SBP-140CMB SBP-150CMI SBP-300CMTS SBP-300CMI SBP-300CMTW SBP-180CMS SBP-150CMP SBP-C15H (Ball Head) SBP-300CMW1 (Ball Head) SBP-300CMP SBP-900CMW SBP-900CMP SBP-156LMW1 English _9...
-
Page 19: Installation
installation & connection INSTALLATION Disassembling 1. Remove the dome cover by turning the dome cover’s fastening screws counterclockwise. Note that it is not necessary to loosen the screws completely. The camera jack connected to the external cable is not waterproof. You are recommended to install this product below the edge of eaves to prevent the cable from being externally exposed. - Page 20 installation & connection Removing a Micro SD card Installation (mount plate) Gently press down on the exposed end of the Micro SD card as shown in the diagram to eject the Micro SD [Directly installing on ceiling] card from the slot. 1-1.
- Page 21 1-3. Take out the necessary cables from among the network and alarm cables through the hole of the mount 2-3. Place the pipe on the mount plate. plate. 2-4. Fix the mount plate using appropriate screws. [Installing using pipe] 2-1. Place the mount plate on the desired location considering the direction to be monitored, mark the locations for the screw holes, and then drill the holes.
- Page 22 installation & connection [Attaching to the unbundled adapter] Installation (camera body and dome cover) Choose and purchase a necessary one of the following options (unbundled) that is suitable to the installation 1. Connect the safety wire to the mount plate. site or for your convenience.
- Page 23 installation & connection 15. Fix the camera body by tightening the fastening screws on the camera body. Outdoor installation When you install it outside of the building, please waterproof it with waterproof butyl rubber tape (can be purchased in stores) so that water does not leak from the gap of the cable connected to the outside. 1.
- Page 24 The following Page(s) are related to Miscellaneous-01. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
- Page 25 DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - T1 DESCRIPTION RM10"V"8PIN 1. DIMENSIONS (UNIT:mm) * MARKING * UPDH110 - T1 DIS-10B PART NO 31.0 MAX DONGINAABB LOT NO WEEK YEAR MAKER 31.0 UPDH110 - T1 DIS-10B...
- Page 26 DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - T1 DESCRIPTION RM10"V"8PIN 2. CONNECTION (BOTTOM VIEW) × ① ② ③ ④ ⑤ REMOVED PIN #3,7 CUT PIN N.C PIN P/I TAPE,TUBE FLUX BAND DOT MARK ■START OF WINDING...
- Page 27 DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - T1 DESCRIPTION RM10"V"8PIN 8. CONSTRUCTION ③ ⑤ ② ④ ① NO GAP CORE NO GAP CORE ⑥ DRAWN BY CHECK BY APPR. BY REVISION DATE Safety...
- Page 28 DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - T1 DESCRIPTION RM10"V"8PIN 9. MATERIAL LIST ITEM MATERIAL MANUFACTURER FILE NO. RING TONG FERRITE CO., LTD. FERRITE CORE RM10 CORE NAN TONG FERRITE CO., LTD. LP-4 OR HX-40 OR PC-40 JI SHUN MAGNETICS CO., LTD PHENOL 94V-0...
- Page 29 The following Page(s) are related to Miscellaneous-02. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
-
Page 30: Specification
CUSTOMER : Manufacturing Solution Provide CO.,LTD. SHEET NO. SPECIFICATION D A T E 2024. 01. 08. PART NAME S/W TRANS MODEL NAME PART NO. UPDH110-T1 (CLASS B) TYPE RM 10 6. DIMENSION (UNIT : mm) * MARKING UPDH110-T1 PART NO. 31.0 MAX DH 0000 DHB-001 CLASS B SYSTEM... -
Page 31: Schematic Diagram
CUSTOMER : Manufacturing Solution Provide CO.,LTD. SHEET NO. SPECIFICATION D A T E 2024. 01. 08. PART NAME S/W TRANS MODEL NAME PART NO. UPDH110-T1 (CLASS B) TYPE RM 10 ① ② ③ ④ ⑤ 7. SCHEMATIC DIAGRAM. ① ② ③... -
Page 32: Internal Construction
CUSTOMER : Manufacturing Solution Provide CO.,LTD. SHEET NO. SPECIFICATION D A T E 2024. 01. 08. PART NAME S/W TRANS MODEL NAME PART NO. UPDH110-T1 (CLASS B) TYPE RM 10 12. INTERNAL CONSTRUCTION <TOP> <PIN> CAP [3] 3 LAYERS 0.025tx10.5mm [5] [WHITE] W3 SOLENOID [4] 2 LAYERS 0.025tx10.5mm [5] W2 SOLENOID [4]... -
Page 33: Material List
CUSTOMER : Manufacturing Solution Provide CO.,LTD. SHEET NO. SPECIFICATION D A T E 2024. 01. 08. PART NAME S/W TRANS MODEL NAME PART NO. UPDH110-T1 (CLASS B) TYPE RM 10 13. MATERIAL LIST I T E M MATERIALS & DIMENSIONS MANUFACTURER REMARK YR28... - Page 34 The following Page(s) are related to Miscellaneous-03. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
- Page 35 DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - L32 DESCRIPTION RM10"V"8PIN 1. DIMENSIONS (UNIT:mm) * MARKING * UPDH110 - L32 DIS-10B PART NO 31.0 MAX DONGINAABB LOT NO WEEK YEAR MAKER 31.0 UPDH110 - L32 DIS-10B...
- Page 36 DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - L32 DESCRIPTION RM10"V"8PIN 2. CONNECTION (BOTTOM VIEW) × × × ① ② ③ ④ ⑤ REMOVED PIN #1,4,5,7 CUT PIN N.C PIN P/I TAPE,TUBE FLUX BAND DOT MARK...
-
Page 37: Electrical Characteristics
DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - L32 DESCRIPTION RM10"V"8PIN 7. ELECTRICAL CHARACTERISTICS ITEM TERMINAL SPEC REMARK 6.5uH ± 10% LCR METER AG 4304 INDUCTANCE HP-4274A 9.75uH ± 35% at 1KHz 1V 0.05Ω... - Page 38 DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - L32 DESCRIPTION RM10"V"8PIN 8. CONSTRUCTION ③ ⑤ ② ④ ⑦ ① GAP CORE GAP CORE ⑥ EPOXY SK-015B DRAWN BY CHECK BY APPR.
- Page 39 DATE 2024. 03. 19 APPROVAL SHEET PAGE CUSTOMER PART NAME SWITCHING TRANS MODEL NO. PART NO. UPDH110 - L32 DESCRIPTION RM10"V"8PIN 9. MATERIAL LIST ITEM MATERIAL MANUFACTURER FILE NO. RING TONG FERRITE CO., LTD. FERRITE CORE RM10 CORE NAN TONG FERRITE CO., LTD. LP-4 OR HX-40 OR PC-40 JI SHUN MAGNETICS CO., LTD PHENOL 94V-0...
- Page 40 The following Page(s) are related to Miscellaneous-04. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
- Page 41 CUSTOMER : Manufacturing Solution Provide CO.,LTD. SHEET NO. SPECIFICATION D A T E 2024. 01. 18. PART NAME PFC TRANS MODEL NAME PART NO. UPDH110-L32 (CLASS B) TYPE RM 10 6. DIMENSION (UNIT : mm) * MARKING UPDH110-L32 PART NO. 31.0 MAX DH 0000 DHB-001 CLASS B SYSTEM...
- Page 42 CUSTOMER : Manufacturing Solution Provide CO.,LTD. SHEET NO. SPECIFICATION D A T E 2024. 01. 18. PART NAME PFC TRANS MODEL NAME PART NO. UPDH110-L32 (CLASS B) TYPE RM 10 ① ② ③ ④ ⑤ 7. SCHEMATIC DIAGRAM. ① ② ③...
- Page 43 CUSTOMER : Manufacturing Solution Provide CO.,LTD. SHEET NO. SPECIFICATION D A T E 2024. 01. 18. PART NAME PFC TRANS MODEL NAME PART NO. UPDH110-L32 (CLASS B) TYPE RM 10 12. INTERNAL CONSTRUCTION <TOP> <PIN> CAP [3] 3 LAYERS 0.025tx10.5mm [5] [WHITE] W2 SOLENOID [4] 3 LAYERS 0.025tx10.5mm [5] 2.0mm [6]...
- Page 44 CUSTOMER : Manufacturing Solution Provide CO.,LTD. SHEET NO. SPECIFICATION D A T E 2024. 01. 18. PART NAME PFC TRANS MODEL NAME PART NO. UPDH110-L32 (CLASS B) TYPE RM 10 13. MATERIAL LIST I T E M MATERIALS & DIMENSIONS MANUFACTURER REMARK YR28...
- Page 45 The following Page(s) are related to Miscellaneous-05. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
-
Page 46: Dimensions (Unit:mm)
DATE 2014. 11. 07 APPROVAL SHEET PAGE CUSTOMER M S P PART NAME LINE FILTER MODEL NO. SNP-6320RH-CT1 PART NO. DESCRIPTION UU1014"V"4PIN 1. DIMENSIONS (UNIT:mm) * MARKING * 010 DI 010 DI PART NO MARKING PART NO. MAKER TOP VIEW SIDE VIEW FRONT VIEW BOTTON VIEW... - Page 47 DATE 2014. 11. 07 APPROVAL SHEET PAGE CUSTOMER M S P PART NAME LINE FILTER MODEL NO. SNP-6320RH-CT1 PART NO. DESCRIPTION UU1014"V"4PIN 2. CONNECTION 3. WINDING SPECIFICATION TERMINAL INSULATION WINDING WIRE METHOD MATERIAL ( t / mm ) UEW 0.80Ø 1 TS 70 TS UEW 0.25Ø...
- Page 48 DATE 2014. 11. 07 APPROVAL SHEET PAGE CUSTOMER M S P PART NAME LINE FILTER MODEL NO. SNP-6320RH-CT1 PART NO. DESCRIPTION UU1014"V"4PIN 5. ELECTRICAL CHARACTERISTICS ITEM TERMINAL SPEC REMARK LCR METER AG 4304 1 - 2 0.5uH MIN INDUCTANCE HP-4274A 4 - 3 4.0 mH MIN at 1KHz 1V...
- Page 49 The following Page(s) are related to Miscellaneous-06. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
- Page 50 CUSTOMER : Manufacturing Solution Provide CO., Ltd. SHEET NO. SPECIFICATION DATE 2024. 01. 08 PART NAME LINE FILTER MODEL NAME SNP-6320RH-CT1 UU 10x14 CODE NO. LFU10-0104R5 DESCRIPTION 6. APPEARANCE & DIMENSION (UNIT:mm) ※ MARKING (BLACK) 010 0000 PRODUCTION LINE 12.0 MAX 0 1 0 0 0 0 0 WEEK...
- Page 51 CUSTOMER : Manufacturing Solution Provide CO., Ltd. SHEET NO. SPECIFICATION DATE 2024. 01. 08 PART NAME LINE FILTER MODEL NAME SNP-6320RH-CT1 UU 10x14 CODE NO. LFU10-0104R5 DESCRIPTION 7. SCHEMATIC DIAGRAM WINDING BOTTOM VIEW C.C.W REMOVED PIN CUT PIN TUBE 8. WINDING SPECIFICATION WINDING TERMINAL NO.
- Page 52 CUSTOMER : Manufacturing Solution Provide CO., Ltd. SHEET NO. SPECIFICATION DATE 2024. 01. 08 PART NAME LINE FILTER MODEL NAME SNP-6320RH-CT1 UU 10x14 CODE NO. LFU10-0104R5 DESCRIPTION 11. ELECTRICAL CHARACTERISTICS ELECTRICAL CLOSURE TERMINAL TOLERANCE TEST CONDITION CHARACTERISTICS 1 - 2 0.5 [uH] HP-4284A INDUCTANCE...
- Page 53 CUSTOMER : Manufacturing Solution Provide CO., Ltd. SHEET NO. SPECIFICATION DATE 2024. 01. 08 PART NAME LINE FILTER MODEL NAME SNP-6320RH-CT1 UU 10x14 CODE NO. LFU10-0104R5 DESCRIPTION 13. INTERNAL CONSTRUCTION I T E M MATERIALS & DIMENSIONS MANUFACTURER REMARK SAM HWA ELECTRONICS CO., LTD. ZHEJING DONGYANG DMEGC MAGNETIC CO.,LTD UU10x14mm ZIBO YANGGUANG ELECTRONICS CO., LTD...
- Page 54 The following Page(s) are related to Miscellaneous-07. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
-
Page 55: Specifications
ITEM LINE FILTER SPECIFICATIONS TNC SPEC NO CH935230S(LLF- 104) 2. ELECTRICAL CHARACTERISTIC ITEM TERMINAL SPECIFICATION REMARKS RATED VOLTAGE LINE TO LINE AC 300V RATED CURRENT START-FINISH 3.5A HP-4194A INDUCTANCE START-FINISH 16KHz 23.0mH +50%, -30% 1V (25℃±2℃) TEMPERATURE AT RATED 55℃ MAX RISE CURRENT HIOKI 3540... -
Page 56: Shape And Dimension
ITEM LINE FILTER SPECIFICATIONS TNC SPEC NO CH935230S(LLF- 104) 6. WINDING SPECIFICATION TERMINAL WINDING UNBALANCE WIRE TURNS METHOD SPECIFICATION START FINISH BETWEEN UEW 0.75Φ 52 ±3Ts HANDMADE L1 AND L2 (0.4mH MAX) 7. SHAPE AND DIMENSION Not include solder DIMENSION fillet 25.0mm MAX 24.0mm MAX... - Page 57 ITEM LINE FILTER SPECIFICATIONS TNC SPEC NO CH935230S(LLF- 104) 8. MATERIAL LIST No. NAME SPECIFICATION MANUFACTURER UL No. LG CHEM LTD E67171 LUPOX GP2156F(#) Core CHANG CHUN PLASTICS CO LTD E59481 Cover 4130-104XV SAMYANG CORPORATION E121254 1500GN-(k) SIAM PACIFIC ELECTRIC WIRE & E142108 Enamel UEW 0.75Φ...
-
Page 58: Line Filter
ITEM LINE FILTER SPECIFICATIONS TNC SPEC NO CH935230S(LLF- 104) 14. FERRITE CORE SPECIFICATION - Characteristics BH10 T19X13X11 M10K T19X13X11 Symbol Unit μi 10,000±30% 10,000±30% Hcms Brms ℃ >125 >120 TANδ / μiac <10.0 <20.0 /℃ -0.5~1.5 -0.5~1.5 αμr ρ Ω.m 0.15 g/㎤... - Page 59 The following Page(s) are related to Miscellaneous-08. The next supplement, if applicable, will be identified with a new Supplement Page Heading.
- Page 60 ITEM LINE FILTER SPECIFICATIONS TNC SPEC NO CV36045USA2 2. ELECTRICAL CHARACTERISTIC ITEM TERMINAL SPECIFICATION REMARKS RATED VOLTAGE LINE TO LINE AC 300V RATED CURRENT START-FINISH 7.5A HP-4194A INDUCTANCE START-FINISH 160KHz 450uH +50%,-30% 1V (25℃±2℃) TEMPERATURE AT RATED 60℃ MAX RISE CURRENT HIOKI 3540 DC RESISTANCE...
- Page 61 ITEM LINE FILTER SPECIFICATIONS TNC SPEC NO CV36045USA2 6. WINDING SPECIFICATION TERMINAL WINDING UNBALANCE WIRE TURNS METHOD SPECIFICATION START FINISH BETWEEN UEW 0.7Φ 9 ±1Ts HANDMADE L1 AND L2 (52.78uH MAX) 7. SHAPE AND DIMENSION Not include DIMENSION solder fillet 18.0mm MAX 18.5mm MAX 10.0mm MAX...
- Page 62 ITEM LINE FILTER SPECIFICATIONS TNC SPEC NO CV36045USA2 8. MATERIAL LIST NAME SPECIFICATION MANUFACTURER COLOR UL No. JFE Ferrite Corp MA100 R-13/7/5 LAIWU CHAINWELL Ferrite GRAY Core R10KF TR13X7X5C ELECTRONIC&MATERIAL CO.,LTD Equal. Hwa Il Electronics Co.,Ltd YELLOW E140246 Enamel UEW 0.7Φ SHANDONG PENGTAI STOCK Wire / 9±1Ts...
- Page 63 ITEM LINE FILTER SPECIFICATIONS TNC SPEC NO CV36045USA2 14. FERRITE CORE SPECIFICATION - Characteristics Symbol Unit MA100 R- 13/ 7/ 5 R10KF TR13X7X5C μi 10,000±25% 10,000±30% Hcms Brms ℃ >115 >120 TANδ / μiac <1.9 <7.0 /℃ -0.5~2.0 0~1.5 αμr ρ...
- Page 64 Miscellaneous-09 Page-1...
- Page 65 Photographs-01 Page-1...
- Page 66 Photographs-02 Page-1...
- Page 67 Photographs-04 Page-1...
- Page 68 Photographs-05 Page-1...
- Page 69 Photographs-06 Page-1...
- Page 70 Photographs-07 Page-1...
- Page 71 Photographs-08 Page-1...
- Page 72 Photographs-09 Page-1...
- Page 73 Photographs-10 Page-1...
- Page 74 Photographs-11 Page-1...
- Page 75 Photographs-12 Page-1...
- Page 76 Photographs-13 Page-1...
- Page 77 Photographs-14 Page-1...
- Page 78 Photographs-15 Page-1...
