Setting the power on mode

This function sets the input mode at the time the power is
switched on.
Example: Setting "VIDEO2"
Set "ADVANCED OSM" to "ON" in the main menu (1/
2), then perform the following operations.
On "PWR. ON MODE" of "OPTION3" menu, select
"VIDEO2".
The available inputs depend on the setting of input.
OPTION3
PREVIOUS PAGE
TIMER
PWR. ON MODE
CONTROL LOCK
IR REMOTE
LOOP OUT
ID NUMBER
VIDEO WALL
SEL.
ADJ.
Information
PWR. ON MODE settings
LAST: Last mode (the input that was last selected at
the time the power was switched off).
VIDEO1, 2, 3: VIDEO input mode.
RGB1, 2, 3: RGB input mode.
HD/DVD1, 2: HD/DVD input mode.

Enabling/disabling the front panel controls

This function enables/disables the front panel controls.
Example: Setting "ON"
Set "ADVANCED OSM" to "ON" in the main menu (1/
2), then perform the following operations.
On "CONTROL LOCK" of "OPTION3" menu, select
"ON", then press the MENU/ENTER button.
OPTION3
PREVIOUS PAGE
TIMER
PWR. ON MODE
CONTROL LOCK
IR REMOTE
LOOP OUT
ID NUMBER
VIDEO WALL
SEL.
ADJ.
Information
CONTROL LOCK settings
ON: Disables the buttons on the front panel.
OFF: Enables the buttons on the front panel.
* Even when the CONTROL LOCK is set, the POWER
switch will not be locked.
* This becomes effective when the on-screen menu goes
out.
3 / 3
:
VIDEO2
:
OFF
:
ON
:
OFF
:
ALL
EXIT
RETURN
3 / 3
:
LAST
:
ON
:
ON
:
OFF
:
ALL
EXIT
RETURN
Enabling/disabling remote control wireless
transmission
This function enables/disables remote control wireless
transmission.
Example: Setting "OFF"
Set "ADVANCED OSM" to "ON" in the main menu (1/
2), then perform the following operations.
On "IR REMOTE" of "OPTION3" menu, select "OFF", then
press the MENU/ENTER button.
PREVIOUS PAGE
TIMER
PWR. ON MODE
CONTROL LOCK
IR REMOTE
LOOP OUT
ID NUMBER
VIDEO WALL
SEL.
Information
IR REMOTE settings
ON: Enables remote control wireless transmission.
OFF: Disables remote control wireless transmission.
Set "OFF" to avoid unwanted control from other remote
controls.
Loop Out setting
When this feature is set to ON, the received signal will be
looped out.
Example: Setting "ON"
Set "ADVANCED OSM" to "ON" in the main menu (1/
2), then perform the following operations.
On "LOOP OUT" of "OPTION3" menu, select "ON".
PREVIOUS PAGE
TIMER
PWR. ON MODE
CONTROL LOCK
IR REMOTE
LOOP OUT
ID NUMBER
VIDEO WALL
SEL.
Information
LOOP OUT settings
ON: The received signal will be looped out via PC1
terminal or VIDEO1 terminal.
OFF: The received signal will not loop out.
* Even if LOOP OUT is ON, signals won't be sent out if
POWER is being turned off.
To connect another display...
See page 7.
If the RGB/PC1 signal is present at the time
the power switched on...
The RGB/PC1 input will be displayed regardless of the
setting of LOOP OUT.
28
OPTION3
3 / 3
:
LAST
:
OFF
:
OFF
:
OFF
:
ALL
ADJ.
EXIT
RETURN
OPTION3
3 / 3
:
LAST
:
OFF
:
ON
:
ON
:
ALL
ADJ.
EXIT
RETURN
