KI Passel PKFFA2448 Assembly Instructions Manual

leg
column
leg frame
bracket
M6 x 10 mm
motor
machine
housing
screw
Detail A
leg
column
motor
housing
leg frame
bracket
leg
column
M6 x 10 mm
motor
housing
Figure 1
Motor-Operated Furnishing
-FOR COMMERICAL USE ONLY-
ATTENTION: Following assembly,
prior to being placed into service.
table to malfunction.
Table "Zero Setting"
two seconds then release. Next, press and hold the Down
button until table has reached its lowest position then release
Down button. Then, press the Down button again and hold for
approximately 10 seconds. The table now re-set at its "Zero
Setting" position and is ready to operate.
M6 x 10 mm
motor
housing
Detail B
leg frame
bracket
machine
screw
Figure 2
table must be "zero set"
Failure to do so can cause
Press and hold the Up button for
:
Assembly Instructions
Passel™ Desking System
Adjustable-Height Tables
January 2025
motor housing
leg
column
leg frame
bracket
leg frame
machine
bracket
screw
Detail C
leg
column
leg motor
column housing
motor
housing
leg frame
bracket
M6 x 10 mm
machine screw
motor
housing
Detail D
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Passel Adjustable-Height Tables
Overview
Note: Although the figures
throughout this instruction illustrate
a Passel adjustable-height table
with C-legs being assembled, the
instructions also apply to Passel
adjustable-height tables with T-legs.
Your configuration may vary.
Adjustable-Height Base Assembly
M6 x 10 mm
1. Carefully remove contents from
machine screw
packaging and set out onto a soft,
protective surface. Identify parts and
hardware supplied.
2. Carefully place the leg columns
upside down on a soft, protective
surface with the motor housings
facing each other as illustrated
(Figure 1).
3. One leg column at a time, orient the
leg frame bracket so the end with the
cable notch is over the cable on the
motor housing. Lower the bracket
down the leg column, aligning the
larger opening of the tapered slot on
each side of the leg frame bracket
with the M6 x 10 mm machine
M6 x 10 mm
screws partially installed on each
machine
screw side of the motor housing (Figure 1
& Detail A).
4. Once the M6 x 10 mm machine
screw on each side of the housing
are in the openings of the tapered
slots, move the leg frame bracket so
leg
the screws are guided to the smaller
column
end of the slots (Detail B).
5. Align the mounting holes on the leg
leg frame
bracket
frame bracket with the mount holes
on each side of the motor housing
and secure using a M6 x 10 mm
machine screw per side (Figure 2 &
Detail C).
M6 x 10 mm
machine screw
6. Finish securing the leg frame bracket
to the motor housing by tightening
the two M6 x 10 mm machine screws
in the tapered slots (Detail D).
