Teldat SDE Installation Manual page 8

2 Components and Power Supply
Fig. 4: Left control panel view
Dell PowerEdge left control components are as follows:
Item
1
2
3
System health and system indicator codes
Code
Solid blue
Blinking blue
Solid amber
Blinking amber
Status LED indicators
Icon
4
Feature
Status LED indicators
System health and ID indicators
iDRAC Quick Sync 2 wireless indicat-
or
Condition
Indicates whether the system is powered on, is healthy, and system ID mode is
not active. Press the system health and system ID button to switch to system ID
mode.
Indicates the system ID mode is active. Press the system health and system ID
button to switch to system health mode.
Indicates the system is in fail-safe mode.
Indicates the system is failing. Check the System Event Log for specific error mes-
sages.
Description
Drive indicator
Temperature indicator
Electrical indicator
Memory indicator
PCIe indicator
Description
Indicates the status of the system.
Indicates the system health.
Indicates whether the iDRAC Quick Sync 2 wireless option is
activated. The Quick Sync 2 feature allows the system to be
managed using mobile devices.
Condition
The indicator turns solid amber if
there is a drive error.
The indicator turns solid amber if the
system experiences a thermal error
(for example, the ambient temperat-
ure is out of range or there is a fan
failure).
The indicator turns solid amber if the
system experiences an electrical er-
ror (for example, voltage out of range,
or a failed power supply unit (PSU) or
voltage regulator).
The indicator turns solid amber if a
memory error occurs.
The indicator turns solid amber if a
fault occurs in the PCIe card.
