2 Components and Power Supply
USB 2.0 Ports
USB 3.2 ports
VGA Port
LAN Ports
UID LED
The following table provides information and a description of expansion card:
Item
1
2
3
The following table provides information and a description of Power Supply Indicators:
Power Supply Condition
No AC power to the power supply
Power supply critical events causing a shutdown/failure/OCP/OVP/Fan Fail/OTP/UVP
Warning events where the power supply keeps operating: high temperature, over
voltage, under voltage, etc.
AC power present and only 12 VSB ON (PS OFF)
Output is on and working properly
AC cord unplugged and in redundant mode

2.2 Rack installation

The SDE devices can be installed in a 19" rack.

2.2.1 Standalone

An SDE device can be placed as a standalone on a flat, stable surface. The adhesive rubber feet must be stuck to
the underside panel to prevent the router from sliding.
Make sure there is enough space around the router (for ventilation purposes) and check that the electricity cables
can reach it.

2.2.2 Wall mounting

The SDE cannot be wall.mounted.

2.3 Power source

The SDE is powered by means of two internal AC/DC sources. The SDE has two power inputs and two power sup-
plies that operate simultaneously. It can operate each one individually or both at the same time. If SDE is powered by
the two power supplies and one of them fails, the other one acts as a backup.
10
Two USB 2.0 ports.
Two USB 3.2 Gen 1 ports.
One VGA video port
Two 1G LAN ports
Unit identifier LED
Description
One PCIe 5.0 x16 full-height full-length expansion slot.
One PCIe 5.0 x16 full-height full-length expansion slot.
3 One PCIe 5.0 x8 (in x16) low profile expansion slot.
Green LED Amber LED
OFF OFF
OFF ON
OFF 1 Hz Blinking
1 Hz Blinking OFF
ON OFF
OFF ON
