- Page 1 CO-W124C/P1301 Series User Manual Open Frame Panel PC 24” TFT-LCD Open Frame Panel PC with Intel® Alder Lake N Series Processor Version: V1.00...
-
Page 2: Table Of Contents
Ordering Information ......................... 10 Chapter 1 Product Introductions ....................... 11 1.1 Overview ..........................12 1.2 Specifications ........................14 1.2.1 CO-W124C/P1301 Series ......................14 1.3 External Layout ........................19 1.3.1 Front ............................19 1.3.2 Rear ............................19 1.3.3 Left ............................20 1.3.4 Right ............................ - Page 3 4.3.14 NVMe Configuration ....................... 73 4.4 Chipset Setup ........................74 4.4.1 System Agent (SA) Configuration....................74 4.4.2 PCH-IO Configuration ........................ 75 4.5 Security Setup ........................77 4.6 Boot Setup ..........................78 4.7 Save & Exit ..........................79 CO-W124C/P1301 Series | User Manual...
- Page 4 Chapter 5 Product Application ......................80 5.1 Where to download drivers? ....................81 5.2 Where to find the technical documents? ................81 CO-W124C/P1301 Series | User Manual...
-
Page 5: Preface
2024/11/11 Copyright Notice © 2024 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice. -
Page 6: Declaration Of Conformity
(such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service. -
Page 7: Technical Support And Assistance
Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies. -
Page 8: Conventions Used In This Manual
11. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient overvoltage. 12. Never pour any liquid into an opening. This may cause fire or electrical shock. CO-W124C/P1301 Series | User Manual... -
Page 9: Package Contents
Power Terminal Block Connector Thermal Pad (for CPU Thermal Block) Screw Pack Remote Power On/Off Terminal Block Connector DIO Terminal Block Connector Note: Notify your sales representative if any of the above items are missing or damaged. CO-W124C/P1301 Series | User Manual... -
Page 10: Ordering Information
Panel PC with Intel® Atom® x7425E Quad Core Slim Embedded Computer and P-Cap. Touch 24" TFT-LCD Full HD 16:9 Open Frame Display Modular CO-W124C/P1301-i3 Panel PC with Intel® Core i3-N305 Octa Core Slim Embedded Computer and P-Cap. Touch CO-W124C/P1301 Series | User Manual... -
Page 11: Chapter 1 Product Introductions
Chapter 1 Product Introductions CO-W124C/P1301 Series | User Manual... -
Page 12: Overview
1.1 Overview Cincoze open frame industrial panel PC series (CO-100/P1301) is equipped with an Intel® Alder Lake-N processor, rich I/O interfaces (2.5 GbE LAN, USB3.2 Gen2x1, COM, DIO, etc.), and flexible expansion. The biggest highlight is its adjustable mounting bracket design (Patent No.: D224544, D224545, I802427) that allows flexible adjustment and multi-stage locking to greatly improve the... - Page 13 The CO-100/P1301 series features a series of industrial-grade protections, such as a fanless design, wide operating temperature range (0°C to 60°C), wide range DC power input (9 to 48VDC), and IP65 dustproof/water resistant front panel for field-side HMI applications in harsh industrial environments CO-W124C/P1301 Series | User Manual...
-
Page 14: Specifications
• EN/BS EN61000-3-3 Voltage fluctuations & flicker • FCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A • EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV • EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m CO-W124C/P1301 Series | User Manual... - Page 15 • 1x 2.5” Front Accessible SATA HDD/SSD Bay SSD/HDD • 1 x M.2 SSD Shared by M.2 Key B Socket M.2 SSD Expansion • 1x M.2 Key B Type 3042/3052 Socket for 5G/Storage/Add-on Card Expansion M.2 Key B Socket CO-W124C/P1301 Series | User Manual...
- Page 16 Weight Information • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall/ VESA/ CDS/ DIN Rail Mounting • Fanless Design Physical Design • Jumper-less Design Reliability & Protection • Yes Reverse Power Input Protection CO-W124C/P1301 Series | User Manual...
- Page 17 • UL, cUL, CB, IEC, EN62368-1 Safety * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CO-W124C/P1301 Series | User Manual...
- Page 18 Dimension CO-W124C/P1301 Unit: mm CO-W124C/P1301 Series | User Manual...
-
Page 19: External Layout
1.3 External Layout 1.3.1 Front 1.3.2 Rear CO-W124C/P1301 Series | User Manual... -
Page 20: Left
1.3.3 Left 1.3.4 Right CO-W124C/P1301 Series | User Manual... -
Page 21: Chapter 2 Introduction To Switches & Connectors
Chapter 2 Introduction to Switches & Connectors CO-W124C/P1301 Series | User Manual... -
Page 22: Location Of Switches And Connectors
2.1 Location of Switches and Connectors 2.1.1 Top View 2.1.2 Bottom View CO-W124C/P1301 Series | User Manual... -
Page 23: Switches And Connectors Definition
DDR5 SO-DIMM Socket SPK_L1 Speaker out Connector for Left Side SPK_R1 Speaker out Connector for Right Side Super CAP Switch Power Select for COM1/COM2 USB2_1 USB 2.0 Connector USB3_2 USB 3.2 GEN2 Connector VGA1 VGA Connector (DB15) CO-W124C/P1301 Series | User Manual... -
Page 24: Definition Of Switches
Normal (Default) Right Clear CMOS PWR_SSD_LED1: Power / HDD Access LED Status Switch LED Color Definition Green POWER ON POWER LED Colorless POWER OFF Blinking Green Stand by Yellow HDD Read/Write HDD LED Colorless No Operation CO-W124C/P1301 Series | User Manual... - Page 25 Act LED Status Definition Blinking Yellow Data Activity Steady Yellow No Activity * LAN 2 here is equivalent to LAN 2 mentioned in Chapter 1. LAN 3 here is equivalent to LAN 1 mentioned in Chapter 1. CO-W124C/P1301 Series | User Manual...
-
Page 26: Definition Of Connectors
KEY Pin DEVSLP KEY Pin KEY Pin SIM_DETECT KEY Pin PCIE1_RXN/SATA_RXP RESET2# KEY Pin SUSCLK KEY Pin PCIE1_RXP/SATA_RXN CFG1 KEY Pin +3.3V KEY Pin M.2_BT_PCMCLK +3.3V CFG0 PCIE1_TXN/SATA_TXN M.2_BT_PCMIN +3.3V PCIE1_TXP/SATA_TXP CFG2 M.2_BT_PCMOUT RESET# PULL-UP CO-W124C/P1301 Series | User Manual... - Page 27 +3.3V USB_D‐ PCM_CLK WGR_D1N PCM_SYNC/LPC_RSTN WGR_D1P PCM_IN PCM_OUT WGR_D0N WGR_D0P UART_WAKE# WGR_CLKN UART_RX/BRI_RSP WGR_CLKP UARTX/RGI_DT UART_CTS/RGI_RSP PETP0 UART_RTS/BRI_DT PETN0 PERP0 PERN0 REFCLKP0 REFCLKN0 SUSCLK PERST0# CLKREQ0# W_DISABLE2# (PULL‐UP) PEWAKE0# W_DISABLE1# (PULL‐UP) I2C_DATA WTD1N I2C_CLK WTD1P CO-W124C/P1301 Series | User Manual...
- Page 28 Please disconnect the power source before mounting the DC power cables or connecting the DC power connector to system. (Veuillez débrancher la source d'alimentation avant de monter les câbles d'alimentation CC ou de connecter le connecteur d'alimentation CC au système.) CO-W124C/P1301 Series | User Manual...
- Page 29 Remote Power Button Remote Power LED Do not apply power to this connector! This port is used to connect a SWITCH! (Ne mettez pas sous tension ce connecteur! Ce port est utilisé pour connecter un SWITCH!) CO-W124C/P1301 Series | User Manual...
-
Page 30: Optional Module Pin Definition & Settings
Default setting of Pin1 to Pin4 is OFF/ON/ON/ON. 24V_12V_1 (on the module)：IGN Module Voltage Mode Setting Switch 12V / 24V Car Battery Switch Switch Definition Left 24V Car Battery Input (Default) Right 12V Car Battery Input CO-W124C/P1301 Series | User Manual... -
Page 31: Chapter 3 System Setup
Chapter 3 System Setup CO-W124C/P1301 Series | User Manual... -
Page 32: Removing Top Cover
Step 1. Loosen the 8 screws of front and rear panel, then place them aside. Step 2. Remove the cover from the chassis. Step 3. Place the top cover gently. CO-W124C/P1301 Series | User Manual... -
Page 33: Installing So-Dimm Memory
Step 2. Tilt the SO-DIMM module at a 45-degree angle and insert it to SO-DIMM socket until the gold-pated connector of module contacted firmly with the socket. 45° Step 3. Press the modules down until it’s fixed firmly by the two locking latches on each side. CO-W124C/P1301 Series | User Manual... -
Page 34: Installing M.2 Key B Card
Step 2. Insert the M.2 Key B card at a 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. Step 3. Press down the module and fasten the screw to secure the module. CO-W124C/P1301 Series | User Manual... -
Page 35: Key B Type 3042
Secure the bracket in place and fasten the screw. Step 3. Insert the M.2 Key B card at a 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45° CO-W124C/P1301 Series | User Manual... -
Page 36: Installing M.2 Key E Card
Step 2. Tilt the M.2 Key E card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. 45° Step 3. Press the card down and secure it with one screw. CO-W124C/P1301 Series | User Manual... -
Page 37: Installing Antenna(S)
Step 1. Remove the antenna hole cover(s) on the front or the side panel. Step 2. Have the antenna jack penetrate through the hole. Step 3. Put on the washer and fasten the nut with the antenna jack. CO-W124C/P1301 Series | User Manual... - Page 38 Step 4. Assemble the antenna and antenna jack together. Step 5. Attach the RF connector at another end of cable onto the module. CO-W124C/P1301 Series | User Manual...
-
Page 39: Installing Cpu Thermal Pad
Before assembling the system’s chassis cover, please make sure the protective film on the Thermal Pad has been removed! (Avant d'assembler le couvercle du châssis du système, assurez-vous que le film protecteur sur le coussin thermique a été retiré !d'alimentation CC au système.) CO-W124C/P1301 Series | User Manual... -
Page 40: Installing Top Cover
3.7 Installing Top Cover Step 1. Put on the cover. Step2. Fasten the 8 screws to fix the cover. CO-W124C/P1301 Series | User Manual... -
Page 41: Installing Sata Hard Drive
Step 4. Make the bottom side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together. CO-W124C/P1301 Series | User Manual... - Page 42 Step 5. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket until the connector of HDD contact the SATA connector firmly. Step 6. Fasten the screw on the HDD bracket. Step 7. Fasten the 2 screws on the front panel. CO-W124C/P1301 Series | User Manual...
-
Page 43: Installing Sim Card
Step 1. Loosen the 2 screws on front panel to remove cover plate. Step 2. SIM card slot is at the front panel of the system. Step 3. Insert the SIM card until you hear a click sound; that indicates the installation is complete. CO-W124C/P1301 Series | User Manual... -
Page 44: Installing Cfm Modules
2 screws to fix it. Step 3. Loosen the 2 screws on front panel to remove cover plate. Step 4. IGN function switch will be seen at the front panel of the system. CO-W124C/P1301 Series | User Manual... -
Page 45: Cfm-Poe02
Before putting on the thermal block (in the next step), please make sure the protective film on the Thermal Pad has been removed! (Avant de mettre le bloc thermique (à l'étape suivante), veuillez vous assurer que le film protecteur sur le coussin thermique a été retiré!) CO-W124C/P1301 Series | User Manual... - Page 46 été retiré !d'alimentation CC au système.) Step 6. When the system is power on, please note that the POE LED will light on if the POE module is properly installed. PoE LED CO-W124C/P1301 Series | User Manual...
-
Page 47: Disassembling The Co Display Module
Before starting the following steps, ensure the screws are secured in the default positions, as shown below. These positions are correct for Standard Mount, so no additional adjustments are necessary. CO-W124C 在出貨時，定位螺絲已固定在預設位置，如下圖紅圈所示。此位置適用於 Standard Mount 標準安裝，因此在作 Standard Mount 安裝時，不需要再額外調整定位螺絲的位置。 CO-W124C Top Side View CO-W124C Bottom Side View CO-W124C/P1301 Series | User Manual... - Page 48 One is to fix the CO-100/P1301 module from the front side of the cabinet, which is illustrated in chapter 3.12.1. The other one is to fix the CO-100/P1301 module from the rear side of the cabinet, which is illustrated in chapter 3.12.2. CO-W124C/P1301 Series | User Manual...
-
Page 49: Fixing From Front Side
If the cabinet panel is with bosses as the following figures, user can prepare 16 pcs of M4 screws for fixing the module through the oblong holes (oblong hole size: 9mmx 4mm, without screw thread). CO-W124C/P1301 Series | User Manual... -
Page 50: Installing Flat Mount
Step 1. Loosen the screws marked with blue circles on all four sides of the module (Top, Bottom, Left, Right). Then, remove the positioning screws marked with red circles, as shown in the four images below. CO-W124C Top Side View CO-W124C Bottom Side View CO-W124C/P1301 Series | User Manual... - Page 51 CO-W124C Left Side View CO-W124C Right Side View Step 2. Measure the cabinet or rack thickness. The thickness is measured 3mm in this example. Step 3. Locate the top and bottom-side mounting brackets. CO-W124C/P1301 Series | User Manual...
- Page 52 CO-W124C Top Side View CO-W124C Bottom Side View Step 5. Fasten the three screws on the top and bottom-side mounting brackets. CO-W124C Top Side View CO-W124C Bottom Side View CO-W124C/P1301 Series | User Manual...
- Page 53 Step 7. According to the thickness = 3mm for the example, push down the left and right-side mounting brackets to the place at screw hole = 3mm; and then fasten back the one positioning screw on the left and right-side mounting brackets. CO-W124C Left Side View CO-W124C Right Side View CO-W124C/P1301 Series | User Manual...
- Page 54 One is to fix the CO-100/P1301 module from the front side of the cabinet, which is illustrated in chapter 3.13.1. The other one is to fix the CO-100/P1301 module from the rear side of the cabinet, which is illustrated in chapter 3.13.2. CO-W124C/P1301 Series | User Manual...
-
Page 55: Fixing From Front Side
If the cabinet panel is with bosses as the following figures, user can prepare 16 pcs of M4 screws for fixing the module through the oblong holes (oblong hole size: 9mmx 4mm, without screw thread). CO-W124C/P1301 Series | User Manual... -
Page 56: Disassemble The Mounting Brackets
Step 1. Remove the 16 screws. Step 2. Remove the 3 screws on the left and right side of mounting brackets. Step 3. Remove the 3 screws on the top and bottom side of mounting brackets. CO-W124C/P1301 Series | User Manual... - Page 57 Step 4. Remove the four mounting brackets. CO-W124C/P1301 Series | User Manual...
-
Page 58: Installing Vesa Mount
Step 1. The following picture uses a panel PC (P1301+ Display Module) as a demonstration. To attach the panel PC to a VESA stand, please fasten eight screws as indicated to fix it on the stand. Panel PC (P1301+ Display Module) VESA Stand CO-W124C/P1301 Series | User Manual... -
Page 59: Installing Rack Mount
19”~24” Panel PC series. P2002E P2002/P1001E P1001/P1101/ P1201/P1301/P2102/ P2102E/P2202/P2202E Step 3. Assemble the brackets and the rack mount base by securing 4 M5x6 screws on each side. Side View Side View Bottom View CO-W124C/P1301 Series | User Manual... - Page 60 Step 4. Locate the mounting holes on the two rack mount brackets. Step 5. Assemble two rack mount brackets and the rack by fastening 4 M5x12 screws through the mounting holes on the two rack mount brackets, flat washers and hex nuts at each side. Rack CO-W124C/P1301 Series | User Manual...
-
Page 61: Chapter 4 Bios Setup
Chapter 4 BIOS Setup CO-W124C/P1301 Series | User Manual... -
Page 62: Bios Introduction
( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. CO-W124C/P1301 Series | User Manual... -
Page 63: Main Setup
Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. ◼ System Date Set the date. Please use <Tab> to switch between date elements. ◼ System Time Set the time. Please use <Tab> to switch between time elements. CO-W124C/P1301 Series | User Manual... -
Page 64: Advanced Setup
Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems. ◼ Active Processor Cores [All] Number of cores to enable in each processor package. CO-W124C/P1301 Series | User Manual... -
Page 65: Sata Configuration
Allows you to select which mode SATA controller will operates. Configuration options: [AHCI] ❑ Serial ATA Port 0 Port 0 [Enabled] Enables or disables SATA Port 0. ❑ Serial ATA Port 1 Port 1 [Enabled] Enables or disables SATA Port 1. 4.3.3 PCH-FW Configuration CO-W124C/P1301 Series | User Manual... -
Page 66: Trusted Computing Settings
Enables or disables Security Device Support function. ◼ SHA256 PCR Bank [Enabled] Enables or disables SHA256 PCR Bank function. ◼ SHA384 PCR Bank [Disabled] Enables or disables SHA384 PCR Bank function. ◼ SM3_256 PCR Bank [Disabled] CO-W124C/P1301 Series | User Manual... - Page 67 Enables or disables Storage Hierarchy function. ◼ Endorsement Hierarchy [Enabled] Enables or disables Endorsement Hierarchy function. ◼ Physical Presence Spec Version [1.3] Allows you to select which mode Physical Presence Spec Version will operate. Configuration options: [1.2], [1.3] CO-W124C/P1301 Series | User Manual...
-
Page 68: Acpi Settings
[S3 (suspend to RAM)]: Enables suspend to RAM state. 4.3.6 F81966 Super IO Configuration Set Parameters of Serial Ports. User can Enable/Disable the serial port and Select an optimal setting for the Super IO Device. CO-W124C/P1301 Series | User Manual... - Page 69 Configuration options: [RS232] [RS422/RS485 Full Duplex] [RS485 Half Duplex] ◼ Watch Dog Mode [Sec] Allows to set watchdog timer unit <Sec> or <Min>. ◼ Watch Dog Timer [0] Allows you to set watchdog timer’s value in the range of 0 to 255. CO-W124C/P1301 Series | User Manual...
-
Page 70: Hardware Monitor
Enables or disables wake system from S5 (soft-off state). [Disabled]: Disables wake system from S5. [Fixed Time]: Sets a fixed time (HH:MM:SS) to wake system from S5. [Dynamic Time]: Sets an increase minute(s) from current time to wake system from S5. CO-W124C/P1301 Series | User Manual... -
Page 71: Serial Port Console Redirection
Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support. ◼ USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. CO-W124C/P1301 Series | User Manual... -
Page 72: Network Stack Configuration
4.3.11 Network Stack Configuration ◼ Network Stack [Disabled] Enables or disables UEFI Network Stack. 4.3.13 CSM Configuration ■ CSM Support [Disabled] Enables or disables compatibility support module. CO-W124C/P1301 Series | User Manual... -
Page 73: Nvme Configuration
The screen allows users to select options for the NVMe configuration, and change the value of the selected option. If there is NVMe Device detected, the options will show as the NVMe Device is found. CO-W124C/P1301 Series | User Manual... -
Page 74: Chipset Setup
This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration ◼ Memory Configuration This item displays detailed memory configuration in the system. ◼ VT-d [Enabled] Enables or disables Intel® Virtualization Technology for Directed I/O (VT-d) capability. CO-W124C/P1301 Series | User Manual... -
Page 75: Pch-Io Configuration
❑ PCI Express Root Port (CN1) ◼ PCI Express Root Port [Enabled] Enables or disables PCI Express Root Port. ◼ PCIe Speed [Auto] Allows you to select PCI Express interface speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. CO-W124C/P1301 Series | User Manual... - Page 76 Allows you to specify which power state system will enter when power is resumed after a power failure (G3 state). [Always on]: Enters to power on state. [Always off]: Enters to power off state. [Keep last state]: Enters to the last power state before a power failure. CO-W124C/P1301 Series | User Manual...
-
Page 77: Security Setup
Security Boot ❑ Secure Boot [Disabled] Enable or disable Secure Boot function. (Enable this function to change the following settings.) ❑ Secure Boot Mode [Standard] Allows you to select Secure Boor Mode. Configuration options: [Standard] [Custom]. CO-W124C/P1301 Series | User Manual... -
Page 78: Boot Setup
Allows you to enable or disable Quiet Boot function. ◼ Fast Boot Allows you to enable or disable Fast Boot function. If enabled, system boots with initialization of a minimal set of devices required to launch active boot option. CO-W124C/P1301 Series | User Manual... -
Page 79: Save & Exit
Save as User Defaults This item allows you to save the changes done so far as user defaults. ◼ Restore User Defaults This item allows you to restore the user defaults to all the setup options. CO-W124C/P1301 Series | User Manual... -
Page 80: Chapter 5 Product Application
Chapter 5 Product Application CO-W124C/P1301 Series | User Manual... - Page 81 5.1 Where to download drivers? Please go to the CINCOZE website to download the drivers for CO-100/P1301 series. 5.2 Where to find the technical documents? Please go to the CINCOZE website to find the technical documents for CO-100/P1301 series. Catalog...
