CO-100/P2102 Series
User Manual
Open Frame Panel PC
TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel®
Core™ U Series Processor
Version: V1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CO-100/P2102 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cincoze CO-100/P2102 Series

Summary of Contents for Cincoze CO-100/P2102 Series

  • Page 1 CO-100/P2102 Series User Manual Open Frame Panel PC TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel® Core™ U Series Processor Version: V1.00...

  • Page 2: Table Of Contents

    Contents Preface ..........................5 Copyright Notice ........................5 Acknowledgement .........................5 Disclaimer ..........................5 Declaration of Conformity ......................6 Product Warranty Statement ....................6 Technical Support and Assistance ..................8 Conventions Used in this Manual ..................8 Safety Precautions.........................9 Package Contents ....................... 10 Ordering Information ......................10 Chapter 1 Product Introductions ..................11 1.1 Overview ........................
  • Page 3 3.8 Installing Thermal Pad of Thermal Block ..............43 3.9 Installing the Top Cover ..................44 3.10 Installing SIM Card ....................45 3.11 Disassemble the CO Display Module..............46 3.12 Installing SATA Hard Drive at Front Panel ............47 3.13 Installing SATA hard drive on Bottom Side ............50 3.14 Standard Mount ....................
  • Page 4 4.7 Save & Exit ......................81 Chapter 5 Product Application ..................... 82 5.1 Digital I/O (DIO) application ..................83 5.1.1 Digital I/O Programming Guide ............... 83 5.2 P2100 Digital I/O (DIO) Hardware Specification ............. 90 5.2.1 P2100 DIO Connector Definition ..............91 Chapter 6 Optional Modules and Accessories ..............

  • Page 5: Preface

    2022/09/05 Copyright Notice © 2022 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Declaration Of Conformity

    Product Warranty Statement Warranty Cincoze products are warranted by Cincoze Co., Ltd. to be free from defect in materials and workmanship for 2 years (2 Years for PC Module, 1 Year for Display Module) from the date of purchase by the original purchaser. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation.
  • Page 7 Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.

  • Page 8: Technical Support And Assistance

    Technical Support and Assistance 1. Visit the Cincoze website at www.cincoze.com where you can find the latest information about the product. 2. Contact your distributor or our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call: ⚫...

  • Page 9: Safety Precautions

    Safety Precautions Before installing and using this device, please note the following precautions. Read these safety instructions carefully. Keep this User’s Manual for future reference. Disconnected this equipment from any AC outlet before cleaning. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.

  • Page 10: Package Contents

    Package Contents Before installation, please ensure all the items listed in the following table are included in the package. Item Description Q’ty CO-W121C/P2102 Series Panel PC Utility DVD Driver Power Terminal Block Connector PCI / PCIe Card Installation Kit Thermal Pad (for CPU Thermal Block) Screw Pack Remote Power On/O Terminal Block Connector DIO Terminal Block Connector...

  • Page 11: Chapter 1 Product Introductions

    Chapter 1 Product Introductions Series | User Manual CO-100/P2102...

  • Page 12: Overview

    Cincoze’s high-performance open-frame modular panel PCs (CO-W121C/P2102 Series) use Intel® Core U series processors that provide high-performance data processing and graphics computing capabilities with only 15W low power consumption. The CO-100/P2102 series supports CFM technology that extends system functions according to requirements, with options such as Power Ignition Sensing (IGN) and Power over Ethernet (PoE).

  • Page 13: Key Features

    2x DDR4 SO-DIMM Socket, Supports Up to 2400MHz, 64GB ⚫ Designed with Adjustable Mounting Bracket ⚫ Support Flat / Standard / VESA / Rack Mount ⚫ Front Panel IP65 Compliant ⚫ Wide Operating Temperature ⚫ Cincoze Patent CDS Technology Support Series | User Manual CO-100/P2102...

  • Page 14: Hardware Specification

    1.4 Hardware Specification 1.4.1 CO-W121C-R10/P2102 Series The table on this page refers to the specifications of CO-W121 alone. Display • 21.5” (16:9) LCD Size • 1920 x 1080 Resolution • 300 cd/m2 Brightness • 5000:1 Contract Ratio • 16.7M LCD Color •...
  • Page 15 Model Name P2102 P2102E System Processor • Onboard 8th Intel® Core™ U Processors (Whiskey Lake) - Intel® Core™ i5-8365UE Quad Core Processor (6M Cache, up to 4.10 GHz) - Intel® Core™ i3-8145UE Dual Core Processor (4M Cache, up to 3.90 GHz) - TDP: 15 W Memory •...
  • Page 16 Model Name P2102 P2102E Expansion • 2x Full-size Mini-PCIe Sockets Mini PCI Express • 1x PCI or 1x PCIe x4 Expansion slot (with PCI Express Optional Riser Card) • 1x M.2 2230 E Key Socket for Wireless Module, Supports Intel CRF Module M.2 E Key Socket •...
  • Page 17 Model Name P2102 P2102E Reliability & Protection • Yes Reverse Power Input • Protection Range: 51-58V Over Voltage Protection • Protection Type: shut down operating voltage, • re-power on at the present level to recover • 15A Over Current Protection •...
  • Page 18 Dimension CO-W121C/P2102 Unit: mm CO-W121C/P2102E Unit: mm Series | User Manual CO-100/P2102...

  • Page 19: System I/O

    1.5 System I/O 1.5.1 Front Antenna IGN Setting Switch Used to connect an antenna for optional wireless Used to set up IGN function module Reset SIM Card Slot Used to reset the system Used to insert a SIM card HDD LED AT/ATX Switch Indicates the status of the hard drive Used to select AT or ATX power mode...

  • Page 20: Rear

    1.5.2 Rear DC IN Display Port Used to plug a DC power input with terminal Used to connect a monitor with DisplayPort block interface Digital I/O Used to connect to a monitor with analog signal The Digital I/O terminal block supports 16 interface isolated DIO (8 digital input and 8 digital output) LAN1, LAN2...

  • Page 21: Left

    1.5.3 Left Antenna COM1, COM2 Used to connect an antenna for optional wireless Used to connect to RS-232/422/485 serial devices WIFI module USB 2.0 Used to connect to USB 2.0/1.1 compatible devices 1.5.4 Right COM3, COM4 OSD Function (For CDS Display Module) Used to connect to RS-232/422/485 serial LCD On/Off devices...

  • Page 22: Chapter 2 Switches & Connectors

    Chapter 2 Switches & Connectors Series | User Manual CO-100/P2102...

  • Page 23: Location Of Switches And Connectors

    2.1 Location of Switches and Connectors 2.1.1 Top View 2.1.2 Bottom View Series | User Manual CO-100/P2102...

  • Page 24: Switches And Connectors Definition

    2.2 Switches and Connectors Definition List of Switch Location Definition AT_ATX1 AT / ATX Power Mode Switch BL_PWR1 Backlight Power on / off switching BL_UP1 Backlight Increase BL_DN1 Backlight Decrease LED1 HDD / Power Access LED Status PWR_SW2 Power button RTC2 Clear COMS Switch Reset1...

  • Page 25: Definition Of Switches

    2.3 Definition of Switches AT_ATX1: AT / ATX Power Mode Switch Switch Definition 1-2 (Left) AT Power Mode 2-3 (Right) ATX Power Mode (Default) BL_PWR1: Backlight Power on / off Switch Definition Push Backlight Power on / off switching BL_UP1: Backlight Increase Switch Definition Push...
  • Page 26 RTC2：Clear CMOS Switch Switch Definition 1-2 (Left) No Operation (Default) 2-3 (Right) Clear CMOS RESET1: Reset Switch Switch Definition Push Reset System SW1: COM1~4 with Power Select Switch Location Function DIP1 DIP2 0V(RI) ON (Default) ON (Default) COM1 Location Function DIP3 DIP4 0V(RI)

  • Page 27: Definition Of Connectors

    SW2: Super CAP Switch Location Function DIP1 DIP2 Super CAP ON (Default) Enabled OFF (Default) Super CAP Disabled 2.4 Definition of Connectors COM1 / COM2 / COM3/ COM4: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half RS232 Duplex...
  • Page 28 CN1： Mini PCI-Express Socket (Support mPCIE & SIM Module & USB) Definition Definition WAKE# 3.3V +1.5V SMB_CLK 31 PETN0(USB3TN0)/SATATN0 1.5V SMB_DATA CLKREQ# 33 PETP0(USB3TP0)/SATATP0 SIM_VCC SIM_DATA USB_D- REFCLK- RESERVED SIM_CLK USB_D+ REFCLK+ RESERVED SIM_Reset 3.3V SIM_VPP 3.3V PERST# +1.5V 23 PERN0(USB3RN0)/SATARP0 49 3.3V 25 PERP0(USB3RP0)/SATARN0 51 +3.3V...
  • Page 29 CN2： Mini PCI-Express Socket (Support mPCIE & USB) Definition Definition WAKE# 3.3V +1.5V SMB_CLK PETN0/SATATN0 1.5V SMB_DATA CLKREQ# PETP0/SATATP0 USB_D- REFCLK- USB_D+ REFCLK+ 3.3V 3.3V 3.3V PERST# +1.5V PERN0/SATARP0 +3.3VAUX PERP0/SATARN0 +3.3V Series | User Manual CO-100/P2102...
  • Page 30 CN3： M.2 Key E Socket (Support M.2 PCIE / Intel CNVi ) Definition Definition Definition +3.3V PULL-UP USB_D+ PEWAKE0# +3.3V USB_D- RGI_DT I2C_DATA WTD1N/PETP1 PCM_CLK RGI_RSP I2C_CLK WGR_D1N PETP0 WTD1P/PETN1 RBI_DT PCM_SYNC/LPCRSTN WGR_D1N PETN0 PCM_IN CLINK_REST REF_CLK WTD0N/PETP1 PCM_OUT CLINK_DATA WGR_D0N PERP0 WTD0P/PERN1...
  • Page 31 DC_IN1: DC Power Input Connector (+9~48V) Connector Type: Terminal Block 1X3 3-pin, 5.0mm pitch Definition +9~48VIN Ignition (IGN) Please disconnect the power source before mounting the DC power cables or connecting the DC power connector to system. LAN1 / LAN2 LED： LAN1 / 2 LED Status Definition LAN LED Status Definition...

  • Page 32: Chapter 3 System Setup

    Chapter 3 System Setup Series | User Manual CO-100/P2102...

  • Page 33: Removing The Top Cover

    3.1 Removing the Top Cover 1. Loosen the eight screws at front and rear panel. 2. Raise the edge of top cover (1), and raise the other side (2) subsequently to remove it from the chassis. 3. Place the top cover aside gently. Series | User Manual CO-100/P2102...

  • Page 34: Installing Half Size Mini Pcie Card

    3.2 Installing Half Size Mini PCIe Card Locate the Mini PCIe socket on the system board. Use two screws provided on adapter bracket to fasten the card and bracket together. Tilt the Mini PCIe card at a 45-degree angle and insert it into the socket until the golden finger connector of the card seated firmly.

  • Page 35: Installing Full Size Mini Pcie Card

    Press down the card and secure it with two screws. 3.3 Installing Full Size Mini PCIe Card 1. Locate the Mini PCIe slot on the system board. 2. Tilt the Mini PCIe card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly.

  • Page 36: Installing A M.2 E Key Card

    3. Press the card down and secure it with 2 screws. 3.4 Installing a M.2 E Key Card 1. Locate the M.2 E Key slot on the system board. 2. Tilt the M.2 E Key card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly.

  • Page 37: Installing Antennas

    3. Press the card down and secure it with 1 screw. 3.5 Installing Antennas 1. Remove the antenna rubber cover on front, left or right panel. 2. Penetrate the antenna jack through the hole. Series | User Manual CO-100/P2102...
  • Page 38 3. Put on the washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. Attach the RF connector at another end of the cable onto the card. Series | User Manual CO-100/P2102...

  • Page 39: Installing So-Dimm Module

    3.6 Installing SO-DIMM Module 1. Locate the SO-DIMM socket on the system board. 2. Tilt the memory module at a 45-degree angle, and insert it into SO-DIMM socket until the golden finger connector of the module is seated firmly. 3. Press down the memory module until retaining clips snap back in place. Series | User Manual CO-100/P2102...

  • Page 40: Installing Pci(E) Card

    4. For the upper SO-DIMM socket, please follow the same steps described earlier to install. 3.7 Installing PCI(e) Card 1. Loosen the two screws as indicated at rear panel. 2. Attach the PCI / PCIe Card Installation Kit on, and fasten the two screws back on rear panel to fix the Kit.
  • Page 41 4. Align the notch of golden fingers of Riser card(Optional) with the slot. Insert the card vertically, and press the card straight down into the slot until it’s seated firmly. 5. Align the notch of golden fingers of PCI(e) card with the expansion slot. Insert the card horizontally, and press the card straight down into the slot until it’s seated firmly.
  • Page 42 7. Locate the retention module of PCI(e) expansion card. 8. Loosen the two screw as indicated to have the clamp arm slidable. 9. Slide the clamp arm of retention module until it contacts the edge of PCI(e) expansion card. Series | User Manual CO-100/P2102...

  • Page 43: Installing Thermal Pad Of Thermal Block

    10. Finally, fasten the two screws that were previously loosen halfway to fix the retention module. 3.8 Installing Thermal Pad of Thermal Block 1. Place thermal pad on the top of CPU thermal block in order to provide a seamless contact with the body of chassis to create an efficient heat dissipation.

  • Page 44: Installing The Top Cover

    3.9 Installing the Top Cover 1. Put on the edge of top cover onto system, and the other side subsequently. 2. Fasten the eight screws at front and rear panel to secure the top cover. Series | User Manual CO-100/P2102...

  • Page 45: Installing Sim Card

    3.10 Installing SIM Card 1. Loosen the screw to remove the Maintenance cover bracket. 2. Locate the SIM card slot. 3. Insert the SIM card. Series | User Manual CO-100/P2102...

  • Page 46: Disassemble The Co Display Module

    3.11 Disassemble the CO Display Module The complete shipping product is the CO display module already installed on the P2102. This chapter will introduce how to dissemble CO display module and P2102. 1. Remove the 6 screws on the display module. 2.

  • Page 47: Installing Sata Hard Drive At Front Panel

    3.12 Installing SATA Hard Drive at Front Panel 1. Turn over the system to bottom side, and remove the screw. 2. Loosen the screw to remove the HDD bay cover bracket. 3. Pull the rotating arm of HDD bracket outward as indicated. Series | User Manual CO-100/P2102...
  • Page 48 4. Hold the rotating arm to pull out the HDD bracket. 5. Place the HDD bracket on screw-hole side of HDD. Use four screws provided to assemble HDD on the bracket. 6. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket and push it until the edge connector of HDD fully inserted into SATA slot.
  • Page 49 7. Put back HDD bay cover at front panel, and fasten it with the screw. 8. Fasten the screw to secure the HDD bracket on the system chassis. Series | User Manual CO-100/P2102...

  • Page 50: Installing Sata Hard Drive On Bottom Side

    3.13 Installing SATA hard drive on Bottom Side 1. Turn over the system to bottom side. Locate the cover of HDD compartment. 2. Loosen the two screws, lift the cover, and then remove it. 3. Loosen three screws and take the HDD bracket out of HDD compartment. Series | User Manual CO-100/P2102...
  • Page 51 4. Place the HDD bracket on screw-hole side of HDD. Use four screws provided to assemble HDD on the bracket. 5. Seat the HDD bracket into HDD compartment, and line up the connector of HDD with SATA slot, then push it until HDD is fully connected into slot. 6.
  • Page 52 7. Put back the cover and fasten the two screws. Series | User Manual CO-100/P2102...

  • Page 53: Standard Mount

    3.14 Standard Mount Before doing the following steps, please make sure the screw positions are fastened at the default positions as indicated in the following picture. The default positions are the correct positions for Standard Mount, so it does not need to change the screw positions additionally for Standard Mount.
  • Page 54 2. Fasten the screws from the rack’s front side. Please prepare 12 x M4 screws for fixing the module through the screw holes as shown below. User can also prepare 16 x M4 screws for fixing the module through the oblong holes as shown below.

  • Page 55: Flat Mount

    3.15 Flat Mount 1. Locate the left and right-side mounting brackets. 2. Remove the two screws on the left and right-side mounting brackets. 3. Loosen the three screws on the left and right-side mounting brackets. Series | User Manual CO-100/P2102...
  • Page 56 4. Measure the rack thickness. The thickness is measured 3mm in this example. 5. According to the thickness = 3mm for the example, push down the left and right-side mounting brackets to the place at screw hole = 3mm. 6. Fasten the two screws on the left and right-side mounting brackets. Series | User Manual CO-100/P2102...
  • Page 57 7. Fasten the three screws on the left and right-side mounting brackets. 8. Locate the top and bottom-side mounting brackets. 9. Remove the two screws on the top and bottom-side mounting brackets. Series | User Manual CO-100/P2102...
  • Page 58 10. Loosen the three screws on the top and bottom-side mounting brackets. 11. According to the thickness = 3mm for the example, push down the top and bottom-side mounting brackets to the place at screw hole = 3mm. 12. Fasten the two screws on the top and bottom-side mounting brackets. 13.
  • Page 59 14. Put the CO-100 module onto the rack back side. 15. Fasten the screws from the rack’s front side. Please prepare 12 x M4 screws for fixing the module through the screw holes as shown below. Series | User Manual CO-100/P2102...
  • Page 60 User can also prepare 16 x M4 screws for fixing the module through the oblong holes as shown below. Series | User Manual CO-100/P2102...

  • Page 61: Disassemble The Mounting Brackets

    3.16 Disassemble the mounting brackets Before the installation of VESA mount and rack mount, user need to disassemble the mounting brackets on the CO display module first. 1. Remove the 8 screws. 2. Remove the 3 screws on the left and right side of mounting brackets. Series | User Manual CO-100/P2102...
  • Page 62 3. Remove the 3 screws on the top and bottom side of mounting brackets. 4. Remove the four mounting brackets. Series | User Manual CO-100/P2102...

  • Page 63: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup Series | User Manual CO-100/P2102...

  • Page 64: Bios Introduction

    4.1 BIOS Introduction The BIOS (Basic Input/ Output System) is a program located on a Flash Memory on the motherboard. When you start the computer, the BIOS program will gain control. The BIOS first operates an auto-diagnostic test called POST (power on self-test) for all the necessary hardware, it detects the entire hardware device and configures the parameters of the hardware synchronization.

  • Page 65: Main Setup

    4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility, the Main Menu (as shown below) will appears on the screen. Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date.

  • Page 66: Advanced Setup

    4.3 Advanced Setup 4.3.1 CPU Configuration ■ Intel® Virtualization Technology [Enabled] Enables or disables Intel® Virtualization Technology. Virtualization enhanced by Intel® Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems.

  • Page 67: Pch-Fw Configuration

    ■ Hyper-Threading [Enabled] Allows you to enable or disable Intel® Hyper-Threading function of processor. 4.3.2 PCH-FW Configuration ■ Intel AMT [Enabled] Allows you to enable or disable Intel® Active Management Technology BIOS execution. ■ Firmware Update Configuration ❑ ME FW Image Re-Flash [Disabled] Allows you to enable or disable ME firmware image re-flash function.

  • Page 68: Trusted Computing

    4.3.3 Trusted Computing ■ Security Device Support [Disable] Allow you to enables or disables Security Device Support function. 4.3.4 ACPI Settings This item allows users to configure ACPI settings. ■ Enable ACPI Auto Configuration [Enabled] Enables or disables BIOS Advanced Configuration Power Interface® (ACPI) auto configuration.

  • Page 69: F81866 Super Io Configuration

    Allows users to select the highest Advanced Configuration Power Interface® (ACPI) sleep state that system will enter when suspend button is pressed. [Suspend Disabled]: Disables entering suspend state. [S3 (suspend to RAM)]: Enables suspend to RAM state. 4.3.5 F81866 Super IO Configuration The screen allows users to select options for the Super IO configuration, and change the value of the selected option.

  • Page 70: Hardware Monitor

    This item allows users to enable or disable serial port. ❑ Change Settings [Auto] This item allows users to change the address & IRQ settings of the specified serial port. ❑ Onboard Serial Port 1 Mode [RS232] This item allows users to select Serial Port Mode. Configuration options: [RS232] [RS422/RS485 Full Duplex] [RS485 Half Duplex] ■...

  • Page 71: S5 Rtc Wake Settings

    4.3.7 S5 RTC Wake Settings ■ Wake System from S5 [Disabled] This item allows users to change the way to wake system from S5 state. [Fixed Time]: Set the specified time (HH:MM:SS) to wake system. [Dynamic Time]: Set the increase time from current time to wake system. 4.3.8 Serial Port Console Redirection ■...

  • Page 72: Usb Configuration

    4.3.9 USB Configuration ■ Legacy USB Support [Enabled] This item allows users to enable or disable legacy USB support. When set to [Auto], legacy USB support will be disabled automatically if no USB devices are connected. ■ XHCI Hand-off [Enabled] This item allows users to enable or disable XHCI (USB3.2) hand-off function.

  • Page 73: Nvme Configuration

    This item allows users to enable or disable UEFI Compatibility Support Module (CSM) to support a legacy PC boot process. 4.3.11 NVMe Configuration The screen allows users to select options for the NVMe configuration, and change the value of the selected option. The options will show as the NVME Device is found. 4.3.12 Network Stack Configuration ■...

  • Page 74: Chipset Setup

    4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration ■ Memory Configuration This item displays detailed memory information in the system. Series | User Manual CO-100/P2102...

  • Page 75: Pch-Io Configuration

    ■ Graphics Configuration ❑ Primary Display [Auto] Allows users to select which graphics device should be primary display or select SG for switchable graphics. Configuration options: [Auto] [IGFX] [PEG] [PCIe] [SG] ❑ Internal Graphics [Auto] This item allows users to enable or disable Internal Graphics. When set to [Auto], it will detect by BIOS.
  • Page 76 ■ PCI Express Configuration ❑ PCI Express Root Port (CN1 mPCIe) ◼ PCI Express Root Port [Enabled] Allows you to enable or disable the PCI Express Port. ◼ PCIe Speed [Auto] Allows you to select PCI Express interface speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. ❑...
  • Page 77 ■ SATA Configuration ❑ SATA Controller(s) [Enabled] Enables or disables Serial ATA controller. ❑ SATA Mode [AHCI] This item allows users to choose [AHCI] or [RAID] mode. ❑ Serial ATA Port 0 Port 0 [Enabled] Enables or disables SATA Port 0. ❑...
  • Page 78 ❑ HD Audio [Enabled] Allows you to select HD Audio options. [Enabled]: HD Audio device is unconditionally enabled. [Disabled]: HD Audio device is unconditionally disabled. ■ LAN i219LM Controller [Enabled] Enables or disables i219LM LAN Controller. ■ Wake On LAN (i219) [Enabled] Enables or disables integrated LAN I219LM Wake On LAN function.

  • Page 79: Security Setup

    4.5 Security Setup This section allows users to configure BIOS security settings. 4.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility. 4.5.2 User Password User Password controls access to the system at boot and to the BIOS Setup utility. 4.5.3 Security Boot ❑...

  • Page 80: Boot Setup

    4.6 Boot Setup This section allows you to configure Boot settings. 4.6.1 Setup Prompt Timeout [1] Use this item to set number of seconds (1..65535) to wait for setup activation key. 4.6.2 Bootup NumLock State [Off] Allows you to select the power-on state for keyboard NumLock. 4.6.3 Quiet Boot [Disabled] Allows you to enable or disable Quiet Boot function.

  • Page 81: Save & Exit

    4.7 Save & Exit ■ Save Changes and Exit This item allows you to exit system setup after saving changes. ■ Discard Changes and Exit This item allows you to exit system setup without saving changes. ■ Save Changes and Reset This item allows you to reset the system after saving changes.

  • Page 82: Chapter 5 Product Application

    Chapter 5 Product Application Series | User Manual CO-100/P2102...

  • Page 83: Digital I/O (Dio) Application

    5.1 Digital I/O (DIO) application This section describes DIO application of the product. The content and application development are better understood and implemented by well experienced professionals or developers. 5.1.1 Digital I/O Programming Guide 5.1.1.1 Pins for Digital I/O Item Standard GPIO70 (Pin103) GPIO71 (Pin104)
  • Page 84 5.1.1.2 Programming Guide To program the Super I/O chip F81866A configuration registers, the following configuration procedures must be followed in sequence: (1) Enter the Extended Function Mode (2) Configure the configuration registers (3) Exit the Extended Function Mode The configuration register is used to control the behavior of the corresponding devices. To configure the register, use the index port to select the index and then write data port to alter the parameters.
  • Page 85 Series | User Manual CO-100/P2102...
  • Page 86 5.1.1.4 Sample Code in C Language 5.1.1.4.1 Control of GP70 to GP77 #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h <Output/Input Mode Selection>...
  • Page 87 5.1.1.4.2 Control of GP80 to GP87 #define AddrPort 0x4E #define DataPort 0x4F <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(DataPort, 0x06) // Select logic device 06h <Output/Input Mode Selection>...
  • Page 88 // Select configuration register 60h WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x03)) WriteByte(AddrPort, 0x61) // Select configuration register 61h WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x20)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Cincoze default GPIO Port base address is 0xA00h Series | User Manual CO-100/P2102...
  • Page 89 5.1.1.6 DATA Bit Table (DIO) = DI1 = DO1 = DI2 = DO2 = DI3 = DO3 = DI4 = DO4 = DI5 = DO5 = DI6 = DO6 = DI7 = DO7 = DI8 = DO8 Series | User Manual CO-100/P2102...

  • Page 90: P2100 Digital I/O (Dio) Hardware Specification

    DIO I/O Port Address 5.1.1.7 5.2 P2100 Digital I/O (DIO) Hardware Specification • XCOM+ / 2XCOM+ : Isolated power in V+ • XCOM- / 2XCOM- : Isolated power in V- • Isolated power in DC voltage : 9-30V • 8x / 16x Digital Input (Source Type) •...

  • Page 91: P2100 Dio Connector Definition

    5.2.1 P2100 DIO Connector Definition DIO-1/DIO-2 : Digital Input / Output Connector Connector Type: Terminal Block 2X10 10-pin, 3.5mm pitch Location Definition Location Definition DC INPUT DC INPUT DIO-1 DIO-2 Series | User Manual CO-100/P2102...
  • Page 92 Reference Input Circuit Reference Output Circuit Series | User Manual CO-100/P2102...

  • Page 93: Chapter 6 Optional Modules And Accessories

    Chapter 6 Optional Modules and Accessories Pin Definitions and Settings Series | User Manual CO-100/P2102...

  • Page 94: Location Of The Connectors And Switches

    6.1 Location of the Connectors and Switches SW2 on CFM-IGN101: IGN Module Timing Setting Switch Set shutdown delay timer when ACC is turned off Pin 1 Pin 2 Pin 3 Pin 4 Definition 0 second 1 minute 5 minutes ON (IGN enabled) 10 minutes 30 minutes OFF (IGN disabled)

  • Page 95: Installing Cfm-Ign Module

    6.2 Installing CFM-IGN Module Locate the power Ignition connector on system motherboard as indicated. Insert the female connector of power ignition board to the male connector on system motherboard. Fasten two screws to secure the power ignition board. Series | User Manual CO-100/P2102...

  • Page 96: Installing Cfm-Poe Module

    6.3 Installing CFM-PoE Module 1. Place a thermal pad on the top of the heatsink, and locate the two regions as marked. 2. Turn over the heatsink and paste the thermal pad at the marked region. Before putting on the thermal block, please make sure the protective film on the Thermal Pad has been removed! 3.
  • Page 97 Insert the female connector of PoE daughter board to the male connector on system motherboard. Put on the PoE thermal block and fasten two screws to secure the PoE board. Before assembling the system’s chassis cover, please make sure the protective films on the Thermal Pads have been removed! Series | User Manual CO-100/P2102...

  • Page 98: Installing Vesa Mount

    6.4 Installing VESA Mount Before the installation of VESA mount, user need to follow the chapter 3.16 to disassemble the mounting brackets on the CO display module first. This series supports VESA mounting that customer can mount system with panel complying with VESA 75mm and 100 mm standard for various usage.
  • Page 99 2. Fasten the VESA mount screws to complete the VESA mounting. Series | User Manual CO-100/P2102...

  • Page 100: Installing Rack Mount

    6.5 Installing Rack Mount Before the installation of rack mount, user need to follow the chapter 3.16 to disassemble the mounting brackets on the CO display module first. 1. Locate the screw holes on the PC or monitor module. 2. Put on the rack mount base and fasten the screws. Series | User Manual CO-100/P2102...
  • Page 101 Assemble two rack mount brackets by fastening 4 screws (M5x6) at each side. Rack mount bracket holes for 21” Panel PC series For P2002E For P2002 / P1001E For P1001 / P1101 / P2102 / P2102E Left Right Bottom 4. Assemble two rack mount brackets by fastening 4 screws (M5x12), flat washers and hex nuts at each side.
  • Page 102 © 2022 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
