  • Page 1 CO-W124C/P2102 Series User Manual Open Frame Panel PC 24” TFT-LCD Modular and Expandable Panel PC with 8th Gen. Intel® Core™ U Series Processor Version: V1.00...
  • Page 2 Chapter 1 Product Introductions ......................11 1.1 Overview ..........................12 1.2 Highlights..........................12 1.3 Key Features ........................... 13 1.4 Hardware Specification ......................14 1.4.1 CO-W124C/P2102 Series ......................14 1.5 System I/O ..........................20 1.5.1 Front ............................20 1.5.2 Rear ............................21 1.5.3 Left ............................. 22 1.5.4 Right ............................
  • Page 3 4.4 Chipset Setup ......................... 75 4.4.1 System Agent (SA) Configuration....................75 4.4.2 PCH-IO Configuration ......................... 76 4.5 Security Setup ........................80 4.5.1 Administrator Password ......................80 4.5.2 User Password ........................... 80 4.5.3 Security Boot ..........................80 CO-W124C/P2102 Series | User Manual...
  • Page 4 Chapter 6 Optional Modules and Accessories ..................94 6.1 Location of the Connectors and Switches ................95 6.2 Installing CFM-IGN Module ....................96 6.3 Installing CFM-PoE Module ....................97 6.4 Installing VESA Mount ......................99 6.5 Installing Rack Mount ......................101 CO-W124C/P2102 Series | User Manual...
  • Page 5 2024/11/11 Copyright Notice © 2024 by Cincoze Co., Ltd. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Cincoze Co., Ltd. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.
  • Page 6 (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in Cincoze RMA Request Form and obtain an RMA number from us. Our staff is available at any time to provide you with the most friendly and immediate service.
  • Page 7 Limitation of Liability Cincoze’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.
  • Page 8 Technical Support and Assistance 1. Visit the Cincoze website at www.cincoze.com where you can find the latest information about the product. 2. Contact your distributor or our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call: ⚫...
  • Page 9 16. Ensure to connect the power cord of power adapter to a socket-outlet with earthing connection. 17. Dispose of used battery promptly. Keep away from children. Do not disassemble and do not dispose of in fire. CO-W124C/P2102 Series | User Manual...
  • Page 10 Panel PC with 8th Gen. Intel Core i3-8145UE Dual Core Processor and P-Cap. Touch 24" TFT-LCD Full HD 16:9 Open Frame Display Modular CO-W124C/P2102E-i3 and Expandable Panel PC with 8th Gen. Intel Core i3-8145UE Dual Core Processor and P-Cap. Touch CO-W124C/P2102 Series | User Manual...
  • Page 11 Chapter 1 Product Introductions CO-W124C/P2102 Series | User Manual...
  • Page 12 1.1 Overview Cincoze’s high-performance open-frame modular panel PCs (CO-100/P2102 Series) use Intel® Core U series processors that provide high-performance data processing and graphics computing capabilities with only 15W low power consumption. The CO-100/P2102 series supports CFM technology that extends system functions according to requirements, with options such as Power Ignition Sensing (IGN) and Power over Ethernet (PoE).
  • Page 13 2x DDR4 SO-DIMM Socket, Supports Up to 2400MHz, 64GB ⚫ Designed with Adjustable Mounting Bracket ⚫ Support Flat / Standard / VESA / Rack Mount ⚫ Front Panel IP65 Compliant ⚫ Wide Operating Temperature ⚫ Cincoze Patent CDS Technology Support CO-W124C/P2102 Series | User Manual...
  • Page 14 • EN/BS EN 55032 Conducted & Radiated: Class A • EN/BS EN IEC 61000-3-2 Harmonic current emissions: Class A • EN/BS EN61000-3-3 Voltage fluctuations & flicker • FCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A CO-W124C/P2102 Series | User Manual...
  • Page 15 Power Mode Switch • 1x ATX Power On/Off Switch Power Switch • 1x Reset Button Reset Button • 1x Clear CMOS Switch Clear CMOS Switch • 1x Remote Power On/Off Connector, 2-pin Terminal Block Remote Power On/Off CO-W124C/P2102 Series | User Manual...
  • Page 16 • Extruded Aluminum with Heavy Duty Metal Mechanical Construction • Wall / VESA / CDS / DIN Rail Mounting • Fanless Design Physical Design • Jumper-less Design Reliability & Protection • Yes Reverse Power Input CO-W124C/P2102 Series | User Manual...
  • Page 17 Safety • EN45545-2 Fire Protection * Product Specifications and features are for reference only and are subject to change without prior notice. For more information, please refer to the latest product datasheet from Cincoze's website. CO-W124C/P2102 Series | User Manual...
  • Page 18 CO-W124C/P2102 Series | User Manual...
  • Page 19 Dimension CO-W124C/P2102 Unit: mm CO-W124C/P2102E Unit: mm CO-W124C/P2102 Series | User Manual...
  • Page 20 Used to select AT or ATX power mode Power LED Clear CMOS Indicates the power status of the system Used to clear CMOS to reset BIOS Power On/Off Removable HDD Power-on or power-off the system Used to insert a 2.5” SATA HDD/SSD CO-W124C/P2102 Series | User Manual...
  • Page 21 Used to connect to remote power on/off switch USB3.2 Gen2 Universal I/O Bracket (For P2102E) Used to connect to USB 3.2 Gen2/3.2 Gen1/2.0/1.1 Used to expand I/O for Mini-PCIe module or PCI(e) compatible devices card CO-W124C/P2102 Series | User Manual...
  • Page 22 Used to connect to USB 3.2 Gen2/3.2 Gen1/2.0/1.1 Increase Brightness compatible devices Press to increase brightness of the screen Line-Out Decrease Brightness Used to connect a speaker Press to decrease brightness of the screen Mic-In Used to connect a microphone CO-W124C/P2102 Series | User Manual...
  • Page 23 Chapter 2 Switches & Connectors CO-W124C/P2102 Series | User Manual...
  • Page 24 2.1 Location of Switches and Connectors 2.1.1 Top View 2.1.2 Bottom View CO-W124C/P2102 Series | User Manual...
  • Page 25 +5V/ +12V Power Output PWR_SW1 Remote Power On/Off Switch Connector SATA1, SATA2 SATA with Power Connector SIM1 SIM Card Socket SPK1, SPK2 Internal Speaker Connector USB2 USB 2.0 Port USB3.2 USB 3.2 Port VGA1 VGA Connector CO-W124C/P2102 Series | User Manual...
  • Page 26 LED1: HDD / Power Access LED Status LED Type Status LED Color HDD Read/Write Yellow HDD LED No Operation Colorless POWER ON Green POWER LED POWER OFF Colorless Stand by Blinking Green PWR_SW2: System Power Button Switch Definition Push Power System CO-W124C/P2102 Series | User Manual...
  • Page 27 ON (Default) ON (Default) COM1 Location Function DIP3 DIP4 0V(RI) ON (Default) ON (Default) COM2 Location Function DIP5 DIP6 0V(RI) ON (Default) ON (Default) COM3 Location Function DIP7 DIP8 0V(RI) ON (Default) ON (Default) COM4 CO-W124C/P2102 Series | User Manual...
  • Page 28 2.4 Definition of Connectors COM1 / COM2 / COM3/ COM4: RS232 / RS422 / RS485 Connector Connector Type: 9-pin D-Sub RS422 / 485 Full RS485 Half Duplex RS232 Definition Duplex Definition Definition DATA - DATA + CO-W124C/P2102 Series | User Manual...
  • Page 29 CN1： Mini PCI-Express Socket (Support mPCIE & SIM Module & USB) Definition Definition WAKE# 3.3V +1.5V SMB_CLK PETN0(USB3TN0)/SATATN0 1.5V SMB_DATA CLKREQ# PETP0(USB3TP0)/SATATP0 SIM_VCC SIM_DATA USB_D- REFCLK- RESERVED SIM_CLK USB_D+ REFCLK+ RESERVED SIM_Reset 3.3V SIM_VPP 3.3V PERST# +1.5V PERN0(USB3RN0)/SATARP0 3.3V PERP0(USB3RP0)/SATARN0 +3.3V CO-W124C/P2102 Series | User Manual...
  • Page 30 CN2： Mini PCI-Express Socket (Support mPCIE & USB) Definition Definition WAKE# 3.3V +1.5V SMB_CLK PETN0/SATATN0 1.5V SMB_DATA CLKREQ# PETP0/SATATP0 USB_D- REFCLK- USB_D+ REFCLK+ 3.3V 3.3V 3.3V PERST# +1.5V PERN0/SATARP0 +3.3VAUX PERP0/SATARN0 +3.3V CO-W124C/P2102 Series | User Manual...
  • Page 31 WGR_D1N PETP0 WTD1P/PETN1 RBI_DT PCM_SYNC/LPCRSTN WGR_D1N PETN0 PCM_IN CLINK_REST REF_CLK WTD0N/PETP1 PCM_OUT CLINK_DATA WGR_D0N PERP0 WTD0P/PERN1 CLINK_CLK WGR_D0P PERN0 COEX3 PEWAKE1# WTCLK/REFCLKP1 UART_WAKE COEX_TXD +3.3V WGR_CLKN REFCLKP0 WTCLK/REFCLKN1 BRI_RSP COEX_RXD +3.3V WGR_CLKP REFCLKN0 SUSCLK PERST0# CO-W124C/P2102 Series | User Manual...
  • Page 32 Connector Type: 1x4 4-pin Wafer, 2.0mm pitch Definition +12V PWR_SW1: Remote Power On/Off Switch Connector Connector Type: Terminal Block 1X2 2-pin, 3.5mm pitch Definition PWR_SW Do not apply power to this connector! This port is used to connect a SWITCH! CO-W124C/P2102 Series | User Manual...
  • Page 33 Chapter 3 System Setup CO-W124C/P2102 Series | User Manual...
  • Page 34 1. Loosen the eight screws at front and rear panel. 2. Raise the edge of top cover (1), and raise the other side (2) subsequently to remove it from the chassis. 3. Place the top cover aside gently. CO-W124C/P2102 Series | User Manual...
  • Page 35 Use two screws provided on adapter bracket to fasten the card and bracket together. Tilt the Mini PCIe card at a 45-degree angle and insert it into the socket until the golden finger connector of the card seated firmly. 45° CO-W124C/P2102 Series | User Manual...
  • Page 36 1. Locate the Mini PCIe slot on the system board. 2. Tilt the Mini PCIe card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. CO-W124C/P2102 Series | User Manual...
  • Page 37 1. Locate the M.2 E Key slot on the system board. 2. Tilt the M.2 E Key card at a 45-degree angle and insert it to the socket until the golden finger connector of the card seated firmly. CO-W124C/P2102 Series | User Manual...
  • Page 38 3. Press the card down and secure it with 1 screw. 3.5 Installing Antenna(s) 1. Remove the antenna rubber cover on front, left or right panel. 2. Penetrate the antenna jack through the hole. CO-W124C/P2102 Series | User Manual...
  • Page 39 3. Put on the washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. Attach the RF connector at another end of the cable onto the card. CO-W124C/P2102 Series | User Manual...
  • Page 40 2. Tilt the memory module at a 45-degree angle, and insert it into SO-DIMM socket until the golden finger connector of the module is seated firmly. 3. Press down the memory module until retaining clips snap back in place. CO-W124C/P2102 Series | User Manual...
  • Page 41 1. Loosen the two screws as indicated at rear panel. 2. Attach the PCI / PCIe Card Installation Kit on, and fasten the two screws back on rear panel to fix the Kit. 3. Loosen the screw as indicated to remove the PCI bracket. CO-W124C/P2102 Series | User Manual...
  • Page 42 5. Align the notch of golden fingers of PCI(e) card with the expansion slot. Insert the card horizontally, and press the card straight down into the slot until it’s seated firmly. 6. Fasten the screw back to secure the PCI(e) expansion card. CO-W124C/P2102 Series | User Manual...
  • Page 43 7. Locate the retention module of PCI(e) expansion card. 8. Loosen the two screw as indicated to have the clamp arm slidable. 9. Slide the clamp arm of retention module until it contacts the edge of PCI(e) expansion card. CO-W124C/P2102 Series | User Manual...
  • Page 44 1. Place thermal pad on the top of CPU thermal block in order to provide a seamless contact with the body of chassis to create an efficient heat dissipation. Before assembling the system’s chassis cover, please make sure the protective film on the Thermal Pad has been removed! CO-W124C/P2102 Series | User Manual...
  • Page 45 3.9 Installing Top Cover 1. Put on the edge of top cover onto system, and the other side subsequently. 2. Fasten the eight screws at front and rear panel to secure the top cover. CO-W124C/P2102 Series | User Manual...
  • Page 46 3.10 Installing SIM Card 1. Loosen the screw to remove the Maintenance cover bracket. 2. Locate the SIM card slot. 3. Insert the SIM card. CO-W124C/P2102 Series | User Manual...
  • Page 47 The complete shipping product is the CO display module already installed on the P2102. This chapter will introduce how to dissemble CO display module and P2102. 1. Remove the 6 screws on the display module. 2. Disconnect the modules. CO-W124C/P2102 Series | User Manual...
  • Page 48 3.12 Installing SATA Hard Drive at Front Panel 1. Turn over the system to bottom side, and remove the screw. 2. Loosen the screw to remove the HDD bay cover bracket. 3. Pull the rotating arm of HDD bracket outward as indicated. CO-W124C/P2102 Series | User Manual...
  • Page 49 5. Place the HDD bracket on screw-hole side of HDD. Use four screws provided to assemble HDD on the bracket. 6. Align the HDD bracket with the entrance of HDD bay. And insert the HDD bracket and push it until the edge connector of HDD fully inserted into SATA slot. CO-W124C/P2102 Series | User Manual...
  • Page 50 7. Put back HDD bay cover at front panel, and fasten it with the screw. 8. Fasten the screw to secure the HDD bracket on the system chassis. CO-W124C/P2102 Series | User Manual...
  • Page 51 1. Turn over the system to bottom side. Locate the cover of HDD compartment. 2. Loosen the two screws, lift the cover, and then remove it. 3. Loosen three screws and take the HDD bracket out of HDD compartment. CO-W124C/P2102 Series | User Manual...
  • Page 52 5. Seat the HDD bracket into HDD compartment, and line up the connector of HDD with SATA slot, then push it until HDD is fully connected into slot. 6. Secure the HDD bracket with three screws. CO-W124C/P2102 Series | User Manual...
  • Page 53 7. Put back the cover and fasten the two screws. CO-W124C/P2102 Series | User Manual...
  • Page 54 These positions are correct for Standard Mount, so no additional adjustments are necessary. CO-W124C 在出貨時，定位螺絲已固定在預設位置，如下圖紅圈所示。此位置適用於 Standard Mount 標準安裝，因此在作 Standard Mount 安裝時，不需要再額外調整定位螺絲的位置。 CO-W124C Top Side View CO-W124C Bottom Side View CO-W124C Left Side View CO-W124C Right Side View CO-W124C/P2102 Series | User Manual...
  • Page 55 3.14.2. 3.14.1 Fixing from front side 2. Fasten the screws from the cabinet’s front side. Please prepare 12 pcs of M4 screws for fixing the module through the circle holes (with screw thread). CO-W124C/P2102 Series | User Manual...
  • Page 56 If the cabinet panel is with bosses as the following figures, user can prepare 16 pcs of M4 screws for fixing the module through the oblong holes (oblong hole size: 9mmx 4mm, without screw thread). CO-W124C/P2102 Series | User Manual...
  • Page 57 1. Loosen the screws marked with blue circles on all four sides of the module (Top, Bottom, Left, Right). Then, remove the positioning screws marked with red circles, as shown in the four images below. CO-W124C Top Side View CO-W124C Bottom Side View CO-W124C Left Side View CO-W124C Right Side View CO-W124C/P2102 Series | User Manual...
  • Page 58 4. According to the thickness = 3mm for the example, push down the top and bottom-side mounting brackets to the place at screw hole = 3mm; and then fasten back the two positioning screws on the top and bottom-side mounting brackets. CO-W124C Top Side View CO-W124C/P2102 Series | User Manual...
  • Page 59 CO-W124C Bottom Side View 5. Fasten the three screws on the top and bottom-side mounting brackets. CO-W124C Top Side View CO-W124C Bottom Side View 6. Locate the left and right-side mounting brackets. CO-W124C/P2102 Series | User Manual...
  • Page 60 8. Lift up the left and right-side mounting brackets with aligning the top and bottom-side mounting brackets, then fasten the three screws by the indicated sequence 1, 2, 3 on each side. CO-W124C Left Side View CO-W124C Right Side View CO-W124C/P2102 Series | User Manual...
  • Page 61 3.15.2. 3.15.1 Fixing from front side 10. Fasten the screws from the cabinet’s front side. Please prepare 12 pcs of M4 screws for fixing the module through the circle holes (with screw thread). CO-W124C/P2102 Series | User Manual...
  • Page 62 If the cabinet panel is with bosses as the following figures, user can prepare 16 pcs of M4 screws for fixing the module through the oblong holes (oblong hole size: 9mmx 4mm, without screw thread). CO-W124C/P2102 Series | User Manual...
  • Page 63 Step 2. Remove the 3 screws on the left and right side of mounting brackets. Step 3. Remove the 3 screws on the top and bottom side of mounting brackets. Step 4. Remove the four mounting brackets. CO-W124C/P2102 Series | User Manual...
  • Page 64 Chapter 4 BIOS Setup CO-W124C/P2102 Series | User Manual...
  • Page 65 ( ↑↓ ) to highlight the field and press <Enter> to call up the sub-menu. Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. CO-W124C/P2102 Series | User Manual...
  • Page 66 Use arrow keys to move among the items and press <Enter> to accept or enter a sub-menu. 4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time. Please use <Tab> to switch between time elements. 4.3 Advanced Setup CO-W124C/P2102 Series | User Manual...
  • Page 67 ■ Active Process Cores [All] Allows you to choose the number of active processor cores. Configuration options: [All] [1] [2] [3] ■ Hyper-Threading [Enabled] Allows you to enable or disable Intel® Hyper-Threading function of processor. 4.3.2 PCH-FW Configuration CO-W124C/P2102 Series | User Manual...
  • Page 68 ■ Intel AMT [Enabled] Allows you to enable or disable Intel® Active Management Technology BIOS execution. ■ Firmware Update Configuration ❑ ME FW Image Re-Flash [Disabled] Allows you to enable or disable ME firmware image re-flash function. CO-W124C/P2102 Series | User Manual...
  • Page 69 4.3.4 ACPI Settings This item allows users to configure ACPI settings. ■ Enable ACPI Auto Configuration [Enabled] Enables or disables BIOS Advanced Configuration Power Interface® (ACPI) auto configuration. ■ ACPI Sleep State [S3 (Suspend to RAM)] CO-W124C/P2102 Series | User Manual...
  • Page 70 [S3 (suspend to RAM)]: Enables suspend to RAM state. 4.3.5 F81866 Super IO Configuration The screen allows users to select options for the Super IO configuration, and change the value of the selected option. ■ Serial Port 1~6 Configuration ❑ Serial Port [Enabled] CO-W124C/P2102 Series | User Manual...
  • Page 71 These items display the current status of all monitored hardware devices/ components such as voltages and temperatures. ■ Internal Smart Fan Function [Enabled] Enables or disables internal smart fan function. ■ Internal Smart Fan Configuration Allows users to setting internal smart fan parameters. CO-W124C/P2102 Series | User Manual...
  • Page 72 [Dynamic Time]: Set the increase time from current time to wake system. 4.3.8 Serial Port Console Redirection ■ Console Redirection [Disabled] These items allow users to enable or disable COM0, COM1, COM2, COM3, Com4, COM5 console redirection function. CO-W124C/P2102 Series | User Manual...
  • Page 73 This item allows users to enable or disable XHCI (USB3.2) hand-off function. ■ USB Mass Storage Driver Support [Enabled] Enables or disables support for USB mass storage devices. 4.3.10 CSM Configuration ■ CSM Support [Disabled] CO-W124C/P2102 Series | User Manual...
  • Page 74 The screen allows users to select options for the NVMe configuration, and change the value of the selected option. The options will show as the NVME Device is found. 4.3.12 Network Stack Configuration ■ Network Stack [Disabled] Enables or disables UEFI Network Stack. CO-W124C/P2102 Series | User Manual...
  • Page 75 4.4 Chipset Setup This section allows you to configure chipset related settings according to user’s preference. 4.4.1 System Agent (SA) Configuration ■ Memory Configuration This item displays detailed memory information in the system. CO-W124C/P2102 Series | User Manual...
  • Page 76 This item allows users to enable or disable Internal Graphics. When set to [Auto], it will detect by BIOS. Configuration options: [Auto] [Disabled] [Enabled] ■ VT-d [Enabled] This item allows users to enable or disable Intel® Virtualization Technology for Directed I/O (VT-d) function. 4.4.2 PCH-IO Configuration CO-W124C/P2102 Series | User Manual...
  • Page 77 ❑ PCI Express Root Port (PCIe1 Slot X4) ◼ PCI Express Root Port [Enabled] Allows you to enable or disable the PCI Express Port. ◼ PCIe Speed [Auto] Allows you to select PCI Express interface speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. CO-W124C/P2102 Series | User Manual...
  • Page 78 This item allows users to choose [AHCI] or [RAID] mode. ❑ Serial ATA Port 0 Port 0 [Enabled] Enables or disables SATA Port 0. ❑ Serial ATA Port 1 Port 1 [Enabled] Enables or disables SATA Port 1. ■ HD Audio Configuration CO-W124C/P2102 Series | User Manual...
  • Page 79 Allows you to specify which power state system will enter when power is resumed after a power failure (G3 state). [Always on]: Enters to power on state. [Always off]: Enters to power off state. [Keep last state]: Enters to the last power state before a power failure. CO-W124C/P2102 Series | User Manual...
  • Page 80 User Password controls access to the system at boot and to the BIOS Setup utility. 4.5.3 Security Boot ❑ Secure Boot [Disabled] Enable or disable Secure Boot function. ❑ Secure Boot Mode [Standard] Allows you to select Secure Boor Mode. Configuration options: [Standard] [Custom]. CO-W124C/P2102 Series | User Manual...
  • Page 81 Allows you to select the power-on state for keyboard NumLock. 4.6.3 Quiet Boot [Disabled] Allows you to enable or disable Quiet Boot function. 4.6.4 Fast Boot [Disabled] Allows you to enable or disable Fast Boot function. CO-W124C/P2102 Series | User Manual...
  • Page 82 ■ Save as User Defaults This item allows you to save the changes done so far as user defaults. ■ Restore User Defaults This item allows you to restore the user defaults to all the options. CO-W124C/P2102 Series | User Manual...
  • Page 83 Chapter 5 Product Application CO-W124C/P2102 Series | User Manual...
  • Page 84 GPIO70 (Pin103) GPIO71 (Pin104) GPIO72 (Pin105) GPIO73 (Pin106) GPIO74 (Pin107) GPIO75 (Pin108) GPIO76 (Pin109) GPIO77 (Pin110) GPIO80 (Pin111) GPIO81 (Pin112) GPIO82 (Pin113) GPIO83 (Pin114) GPIO84 (Pin115) GPIO85 (Pin116) GPIO86 (Pin117) GPIO87 (Pin118) 5.1.1.2 Programming Guide CO-W124C/P2102 Series | User Manual...
  • Page 85 Following is an example to enable configuration and to disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) 5.1.1.3 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. CO-W124C/P2102 Series | User Manual...
  • Page 86 CO-W124C/P2102 Series | User Manual...
  • Page 87 // Set (bit 0~7) = 0 to select GP 70~77 as Input mode. <Input Value> WriteByte(AddrPort, 0x82) // Select configuration register 82h ReadByte(DataPort, Value) // Read bit 0~7 (0xFF)= GP70 ~77 as High. <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) CO-W124C/P2102 Series | User Manual...
  • Page 88 // Set (bit 0~7) = 1 to select GP 80 ~87 as Output mode. <Output Value> WriteByte(AddrPort, 0x89) // Select configuration register 89h WriteByte(DataPort, Value) // Set bit 0~7=(0/1) to output GP 80~87 as Low or High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) CO-W124C/P2102 Series | User Manual...
  • Page 89 // Select configuration register 60h WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x03)) WriteByte(AddrPort, 0x61) // Select configuration register 61h WriteByte(DataPort, (ReadByte(DataPort) ǀ 0x20)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Cincoze default GPIO Port base address is 0xA00h CO-W124C/P2102 Series | User Manual...
  • Page 90 5.1.1.6 DATA Bit Table (DIO) = DI1 = DO1 = DI2 = DO2 = DI3 = DO3 = DI4 = DO4 = DI5 = DO5 = DI6 = DO6 = DI7 = DO7 = DI8 = DO8 CO-W124C/P2102 Series | User Manual...
  • Page 91 - DO Signal have to pull up resistor to XCOM+ for external device, the resistance will affect the pull up current - Signal High Level : Pull up resistor to XCOM+ - Signal Low Level : = XCOM- - Sink Current: 1A (Max) CO-W124C/P2102 Series | User Manual...
  • Page 92 5.2.1 P2102 DIO Connector Definition DIO-1/DIO-2 : Digital Output / Input Connector Connector Type: Terminal Block 2X10 10-pin, 3.5mm pitch DIO-1 (Out) DIO-2 (In) Location Definition Location Definition DC INPUT DC INPUT DIO-1 DIO-2 CO-W124C/P2102 Series | User Manual...
  • Page 93 Reference Input Circuit Reference Output Circuit CO-W124C/P2102 Series | User Manual...
  • Page 94 Chapter 6 Optional Modules and Accessories CO-W124C/P2102 Series | User Manual...
  • Page 95 2 hours Reserved (0 second) Default setting of Pin1 to Pin4 is OFF/ON/ON/ON. 24V_12V_1: IGN Module Voltage Mode Setting Switch 12V / 24V Car Battery Switch Definition 24V Car Battery Input (Default) 12V Car Battery Input CO-W124C/P2102 Series | User Manual...
  • Page 96 6.2 Installing CFM-IGN Module Locate the power Ignition connector on system motherboard as indicated. Insert the female connector of power ignition board to the male connector on system motherboard. Fasten two screws to secure the power ignition board. CO-W124C/P2102 Series | User Manual...
  • Page 97 2. Turn over the heatsink and paste the thermal pad at the marked region. Before putting on the thermal block, please make sure the protective film on the Thermal Pad has been removed! 3. Paste the thermal pad onto the coil of the CFM-PoE module. CO-W124C/P2102 Series | User Manual...
  • Page 98 Put on the PoE thermal block and fasten two screws to secure the PoE board. Before assembling the system’s chassis cover, please make sure the protective films on the Thermal Pads have been removed! CO-W124C/P2102 Series | User Manual...
  • Page 99 VESA 75mm and 100 mm standard for various usage. The 75mm VESA uses blue-circle-marked screw holes. The 100mm VESA uses red-circle-marked screw holes. 1. Put the VESA stand on, and align with the mounting holes. CO-W124C/P2102 Series | User Manual...
  • Page 100 2. Fasten the VESA mount screws to complete the VESA mounting. CO-W124C/P2102 Series | User Manual...
  • Page 101 Before the installation of rack mount, user need to follow the chapter 3.16 to disassemble the mounting brackets on the CO display module first. 1. Locate the screw holes on the PC or monitor module. 2. Put on the rack mount base and fasten the screws. CO-W124C/P2102 Series | User Manual...
  • Page 102 For P1001 / P1101 / P1201/ P1301/ P2102 / P2102E/P2202/P2202E Left Right Bottom 4. Assemble two rack mount brackets by fastening 4 screws (M5x12), flat washers and hex nuts at each side. For 19”~24” Panel PC series CO-W124C/P2102 Series | User Manual...
  • Page 103 © 2024 Cincoze Co., Ltd. All rights reserved. The Cincoze logo is a registered trademark of Cincoze Co., Ltd. All other logos appearing in this catalog are the intellectual property of the respective company, product, or organization associated with the logo.
