Specifications

Ports
• 24 100BASE-FX MT-RJ MMF ports
• 2 slots for expansion modules
Network Interface
• 10BASE-T: RJ-45 UTP Cat. 3,4,5
• 100BASE-TX: RJ-45 UTP Cat. 5
• 1000BASE-T: RJ-45 UTP Cat. 5
• 100BASE-FX: MT-45/SC/ST connector
• 1000BASE-SX: SC connector
• 1000BASE-LX: SC connector
Buffer Architecture
• 32Kbps per 100Mbps
• 2Mbps per 1000Mbps port
Aggregated Bandwidth
• 8.8 Gbps, non-blocking
Switching Database
• 8K MAC address entries
LEDs
• System: (power, RPU, Mgmt.)
• Port: (mode fl ow control, full duplex,
activity)
• Link: (speed, link, disable/partition)
Weight
• 4.82 Kg.
Size
• 44.0 x 28.5 x 6.4 cm
Temperature
• Operating: 0-50˚C
• Storage: -40 to 70˚C
Humidity
• Operating 5% to 95% (non-condensing)
Ac Input
• 100 to 240V , 47-63 Hz
Power Supply
• Internal, auto-ranging transformer:
100 to 240VAC, 47-63 Hz
• Redundant DC input
Power Consumption
• <70W
Maximum Current
• SMC6924MT: 0.80A @ 110VAC, 0.50A
@ 240VAC
MTBF
• 6 years (estimated)
Switch Features
• Spanning Tree Protocol
Forwarding Mode
• Store-and-forward
SMC Networks Europe
SMC Networks Eastern Europe
Head Offi ce
Telephone: +49 (0) 89 92861 142
Edifi cio Conata II
Facsimile: +49 (0) 89 92861-230
Fructuós Gelabert 6-8 20, 4a
SMC Networks Italia
08970 - Sant Joan Despi
Telephone : +39 (0) 33 55 70 86 02
Barcelona
SMC Networks Netherlands
Spain
Telephone: +31 627 075227
Telephone: +34 93 477 4920
Facsimile: +31 334 557 330
Facsimile: +34 93 477 3774
SMC Networks Nordic
SMC Networks Central Europe
Telephone: +46 (0) 8 687 0700
Telephone: +49 (0) 89 92861-0
Facsimile: +46 (0) 8 87 62 62
Facsimile: +49 (0) 89 92861-230
SMC Networks Northern Europe
SMC Networks CIS
Telephone: +44 (0)118 974 8700
Telephone: +7 095 789 35 73
Facsimile: +44 (0)118 974 8701
Facsimle: +7 095 789 35 73
SMC Networks North West Africa
SMC Networks Denmark
Telephone: +216 71 23 66 16
Telephone: +45 (0) 566 62283
Facsimle:+216 71 75 14 15
Facsimile: +45 (0) 566 62286
SMC is a registered trademark; and EtherPower, EZStart, SimulTasking, TigerSwitch and SuperDisk are trademarks of SMC Networks, Inc.
Other product and company names are trademarks or registered trademarks of their respective holders. © Copyright 2002 SMC Networks, Inc.
Flow Control
• Full-duplex: IEEE 802.3x
• Half-duplex: back pressure
VLAN Support
• Up to 256 groups, port-based or with
802.1Q VLAN tagging, GVRP for automatic
VLAN learning
Quality of Service
• Supports two levels of priority and
weighted Fair Queuing
• Broadcast Storm Control
• MultiLink Trunking
• Port Mirroring
Management Features
• In-Band Management: Telnet, SLIP,Web-
based HTTP or SNMP Manager
• Out-of-Band Management: RS-232 DB-9
console port
• Software Loading: TFTP in-band or
Xmodem out-of-band
MIB Support
• MIB II (RFC 1213), Bridge MIB (RFC 1493)
• Ethernet-like MIB (RFC 1643), RMON
MIB (RFC 1757), SMC proprietary MIB
RMON Support
• Groups 1, 2, 3, 9 (Statistics, History, Alarm,
Event)
Standards
• IEEE 802.3 Ethernet
• IEEE 803.3u Fast Ethernet
• IEEE 803.3z Gigabit Ethernet
• IEEE 802.1D Spanning Tree Protocol and
traffi c priorities
• IEEE 802.1P Priority Tags
• IEEE 802.1Q VLAN
• IEEE 802.3ac VLAN Tagging
• IEEE 802.3x Full-duplex fl ow control; ISO
IEC 8802-3
• SNMP (RFC 1157), RMON (RFC 1757),ARP
(RFC 826), IGMP (RFC 1112),MIB II
(RFC1213), Ethernet-like MIB (RFC 1643),
Bridge MIB (RFC 1493)
Compliances
• CE Mark
• Emissions
• FCC Class A
• Industry Canada Class A
• EN55022 (CISPR 22) Class A
• VCCI Class A
• C-Tick – AS/NZS 3548 (1995) Class A
• Immunity: IEC 1000 – 4 – 2/3//4/6
• Safety: CSA/NRTL (CSA22.2.950 & UL
1950), EN60950 (TUV/GS)
Warranty
• Limited lifetime
SMC Networks Sub-Saharan Africa
Telephone: +27 113 14 48 73
Facsimile: +27 113 14 91 33
SMC Networks South-East Europe
Telephone: +49 (0) 89 74 08 00 80
Facsimile: +49 (0) 89 74 08 00 81
SMC Networks Southern Europe
Telephone: +33 (0) 1 41 38 32 32
Facsimile: +33 (0) 1 41 38 01 58
SMC Networks Spain and Portugal
Telephone: +34 (0) 636 2043
Facsimile: +34 (0) 636 2044
SMC Switzerland
Telephone:+41 (0) 19409971
Facsimile:+41 (0) 19409972
Tiger Stack™
SMC2655W
Layer 2 Stackable 24-Port
Fiber Managed Switch with
Optional Gigabit Uplinks
Slinde-In Modules
• 100Base-FX Extender Module
Models
• SMC6900FSC,SMC6900FST
• SMC6900FSSC
Ports
• 2 – 100Base-FX MMF or
• 1 – 100Base-FX SMF
Model
• SMC6900G
• SMC6900GLSC
Ports
• (1) 1000Base-SX
• (1) 1000Base-LX
Model
• SMC6900GT
• SMC6900GLSC
Ports
• (1) 10/100/1000Base-T
Model
• SMCRPU150W
Function
• Redundant DC-Power Unit with cables;
supports one device
