SMC Networks SMC6924MT Specifications

Switches/Hubs
The TigerStack 100 is capable of delivering the power
and speed your network needs, with the quality you've
come to expect from SMC. Available in 24 100BASE-FX
MMF MT-RJ ports , each unit contains 2 expansion slots
that can be used for Gigabit, 100Mbps Fiber, or SMC's
innovative stacking module. This inexpensive module
allows you to 'Stack-As-You-Go' , creating a stack of up to
4 switches.
Overview
Advanced Features
• Stack-As-You-Go – Innovative stacking module
saves money by allowing you to stack as you
expand.
• High Port Density – Stack up to 4 units for a
total of 96 10/100 ports
• Convenient Expansion – Each unit comes with
2 slots supporting Gigabit , 100Mbps Fiber
SC/ST or Stacking Modules.
• QoS expedites critical data via prioritizing
and filtering
• MultiLink Trunking creates high-speed data
paths to servers or other switches
• VLAN Support provides port VLANs and GVRP
for auto-registration
• IGMP Snooping reduces multicast traffic for
maximum performance
3 8 T e s l a
• Broadcast storm control allows a userdefined
Irvine, CA 92618
threshold to limit broadcast traffic
1-800-SMC-4YOU
w w w. s m c. c o m
TigerStack
TM
Layer 2 Stackable 24-Port Fiber Managed Switch with
Optional Gigabit Uplinks
Benefits
• EliteView,SMC's full-features,Windows-based
SNMP management software, included free
• Manage and configure the TigerSwitch 100
from any Web-browser
• 4 group RMON support for detailed monitoring
of network performance
• RS-232 port available for out-of-band direct or
remote management
• Mirror port traffic from any port for easy troubleshooting
100
Model Number::
Advanced features like Quality of Service, VLAN sup-
port, MultiLink Trunking and Broadcast Control provide
maximum performance benefits while maintaining
security and reducing network problems. Spanning
Tree support, redundant management and optional
redundant power provide network resiliency and lower
the total cost of ownership. SNMP, RMON and a full-fea-
tured Web based interface provide the means to moni
tor network status and performance levels. The
TigerStack 100 is further backed by a comprehensive
limited lifetime warranty and SMC's award-winning
free technical support.
Compatibility
• IEEE 802.3 Ethernet
• IEEE 803.3u Fast Ethernet
• IEEE 803.3z Gigabit Ethernet
• IEEE 802.1d Spanning Tree Protocol
and traffic priorities
• IEEE 802.1P Priority Tags
• IEEE 802.1Q VLAN
• IEEE 802.3ac VLAN Tagging
• IEEE 802.3x Full-duplex flow control
• IEC 8802-3
• SNMP (RFC 1157), RMON (RFC 1757), ARP
(RFC 826),
• IGMP (RFC 1112),MIB II (RFC 1213),
Ethernet-like MIB
• (RFC 1643), Bridge MIB (RFC 1493)
SMC6924MT
