SMC Networks SMC6924MT Datasheet

Data Sheet
Tiger Stack™
SMC6924MT
Layer 2 Stackable 24-Port Fiber Managed
Switch with Optional Gigabit Uplinks
The TigerStack 100 is capable of delivering the power and speed
your network needs,with the quality you've come to expect from
SMC. Available in 24 100BASE-FX MMF MT-RJ ports , each unit
contains 2 expansion slots that can be used for Gigabit, 100Mbps
Fiber, or SMC's innovative stacking module. This inexpensive module
allows you to 'Stack-As-You-Go', creating a stack of up to 4 switches.
Advanced features like Quality of Service, VLAN support, MultiLink
Trunking and Broadcast Control provide maximum performance
benefits while maintaining security and reducing network problems.
Spanning Tree support, redundant management and optional
redundant power provide network resiliency and lower the total cost
of ownership.SNMP, RMON and a full-featured Web based interface
provide the means to moni tor network status and performance
levels. The TigerStack 100 is further backed by a comprehensive
limited lifetime warranty and SMC's award-winning free technical
support.
Features and Benefi ts
High Performance & Functionality
•
Stack-As-You-Go – Innovative stacking module saves money by allowing you to stack as you
expand.
•
High Port Density – Stack up to 4 units for a total of 96 10/100 ports
•
Convenient Expansion – Each unit comes with 2 slots supporting Gigabit , 100Mbps Fiber
SC/ST or Stacking Modules.
•
QoS expedites critical data via prioritizing and fi ltering
•
MultiLink Trunking creates high-speed data paths to servers or other switches
•
VLAN Support provides port VLANs and GVRP for auto-registration
•
IGMP Snooping reduces multicast traffi c for maximum performance
•
Broadcast storm control allows a userdefi ned threshold to limit broadcast traffi c
Compatibility
•
IEEE 802.3 Ethernet
•
IEEE 803.3u Fast Ethernet
•
IEEE 803.3z Gigabit Ethernet
•
IEEE 802.1D Spanning Tree Protocol and traffi c priorities
•
IEEE 802.1p Priority Tags
•
IEEE 802.1Q VLAN
•
IEEE 802.3ac VLAN Tagging
•
IEEE 802.3x Full-duplex fl ow control
•
IEC 8802-3
•
SNMP (RFC 1157), RMON (RFC 1757), ARP (RFC 826),
•
IGMP (RFC 1112),MIB II (RFC 1213), Ethernet-like MIB
•
(RFC 1643), Bridge MIB (RFC 1493)
Product Model No
TigerSwitch 100 SMC6924MT
Modules SMC6924MTNMM
SMC6900S
SMC6900G
SMC6900GLSC
SMC6900GT
SMC6900FSC
SMC6900FSSC
SMC6900FST
SMCRPU150W
Description
Stackable 24-Port Managed MT-RJ MMF switch with
optional Gigabit Uplinks (at least one SMC6924MTNMM is
required for each standalone or stack)
Management Module (sold separately)
Stacking Module with stacking cable
1-port 1000BASE-SX Expansion Module
1-port 1000BASE-LX Expansion Module
1-port 10/100/1000BASE-T Expansion Module
2-Port 100Base-FX MMF SC Fiber Module
1-Port 100Base-FX SMF SC fi ber Module
100Base-FX MMF SC Fiber Module with SC-ST converters
Redundant Power Supply
