TigerSwitch 16
Intelligent bandwidth acceleration for workgroups
Ethernet and Fast Ethernet Workgroup Switches
Three models, each with 16 10BASE-T ports plus:
Two 100BASE-TX ports
Two 100BASE-FX ports
One 100BASE-TX port and one 100BASE-FX port
Manageable in-band via SNMP, RMON and Telnet
User Guide
Advertisement
Chapters
Table of Contents
Related Manuals for SMC Networks SMC6516TF
Summary of Contents for SMC Networks SMC6516TF
-
Page 1: User Guide
TigerSwitch 16 Intelligent bandwidth acceleration for workgroups Ethernet and Fast Ethernet Workgroup Switches Three models, each with 16 10BASE-T ports plus: Two 100BASE-TX ports Two 100BASE-FX ports One 100BASE-TX port and one 100BASE-FX port Manageable in-band via SNMP, RMON and Telnet User Guide... - Page 2 UIDE SMC’ IGER WITCH AMILY July 1997 Pub. # 900.185 Rev. A Standard Microsystems Corporation 80 Arkay Drive Hauppauge, New York 11788...
- Page 3 Information furnished by Standard Microsystems Corporation (SMC) is believed to be accurate and reliable. However, no responsibility is assumed by SMC for its use, nor for any infringements of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of SMC.
-
Page 4: Limited Warranty
Limited Warranty HARDWARE: Standard Microsystems Corporation (“SMC”) warrants these TigerSwitch 16 units to be free from defects in workmanship and materials, under normal use and service, for the following length of time from the date of purchase from SMC or its Authorized Reseller: TigerSwitch 16 Units . - Page 5 IMITED ARRANTY SMC with a Return Material Authorization (RMA) number marked on the out- side of the package, and sent prepaid, insured, and packaged appropriately for safe shipment. The repaired or replaced item will be shipped to Customer, at SMC’s expense, not later than thirty (30) days after receipt by SMC. WARRANTIES EXCLUSIVE: IF AN SMC PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY SHALL BE REPAIR, REPLACEMENT OR REFUND OF THE PURCHASE PRICE PAID, AT SMC’S...
-
Page 6: Table Of Contents
ABLE OF Compliances ... v Quick Start... 1-1 Introduction ... 1-2 Connecting the Switch... 1-3 Configuring the Switch for SNMP and Telnet Management ... 1-5 About the Switches ... 2-1 Overview... 2-3 Features and Benefits ... 2-12 Switch Architecture... 2-13 Switch Operation ... - Page 7 ABLE OF ONTENTS Configuring and Monitoring ... 5-1 The Console Interface ... 5-3 Typical Configuration Operations ... 5-25 Typical Monitoring Operations ... 5-32 Using Telnet ... 5-34 Using SLIP ... 5-35 Managing Via SNMP and RMON ... 6-1 SNMP Protocol ... 6-2 Using RMON ...
- Page 8 Figure 3-2. Microsegmented LAN ... 3-7 Figure 3-3. Switched LAN ... 3-8 Figure 3-4. Sample Application with Model SMC6516TT. 3-9 Figure 3-5. Sample Application with Model SMC6516TF . 3-10 Figure 3-6. Sample Application with Model SMC6516FF . 3-11 Figure 4-1. Attaching the Brackets ... 4-4 Figure 4-2.
- Page 9 ONTENTS Figure 4-7. Connecting Fiber Cable... 4-12 Figure 5-1. Main Menu ... 5-4 Figure 5-2. Switch Configuration Menu ... 5-5 Figure 5-3. Configuration Display Screen ... 5-7 Figure 5-4. IP Configuration Menu ... 5-9 Figure 5-5. SNMP Configuration Menu... 5-11 Figure 5-6.
-
Page 10: Compliances
FCC A This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. -
Page 11: Quick Start
Introduction ......1-2 Connecting the Switch ....1-3 Configuring the Switch for SNMP and Telnet Management . -
Page 12: Introduction
Ethernet hubs, servers and workstations. Each switch also includes two ports for connection to Fast Ethernet devices. The switch, depending on the model chosen, will contain either two 100BASE-TX ports, two 100BASE-FX ports or one 100BASE-TX port and one 100BASE-FX port. The Fast Ethernet port types... -
Page 13: Connecting The Switch
Console Port” in Chapter 4.) 3. Connect one end of the 3-pin AC power cord supplied with the switch to the power receptacle on the rear of the chassis, and the other end to a grounded power outlet. (See “Connecting to a Power Source” in Chapter 4.) Make note of the diagnostic test results that appear on the PC attached to the Console port. -
Page 14: Figure 1-1. Main Menu
7. Press the Esc key on the terminal or PC. The Main Menu will appear on the screen. ___________________________________________________ >>>> Main Menu <<<< 1. Switch Configuration Menu 2. Port Configuration Menu 3. Statistics Menu 4. Utilities Menu 5. Exit Menus (Password Protect) Enter Selection: ___________________________________________________ Figure 1-1. -
Page 15: Configuring The Switch For Snmp And Telnet Management
Otherwise, select “IP Configuration” from the menu. The IP Configuration Menu will appear (see Figure 1-3). 10. To manually enter the IP address of the switch, you must first disable DHCP. Then, select “Switch IP Address” from the menu and enter the address to be assigned to the switch. -
Page 16: Figure 1-3. Ip Configuration Menu
Step 10. Installation is complete. 13. For SNMP Management: Check to be sure the manage- ment console and the switch use the same SNMP read-only and write community names. For the switch, both names are factory-set to “public.” If the name “public” is also used for both management console names, connect to the IP address assigned in Step 10 and then skip to Step 15. -
Page 17: Figure 1-4. Snmp Configuration Menu
Figure 1-4. SNMP Configuration Menu 16. Compile the MIB file into the SNMP network management platform. This file, supplied with the switch on a 3.5 inch floppy diskette, provides access to the private MIB exten- sions for the switch. Installation is complete. -
Page 18: About The Switches
Spanning Tree Protocol ....2-14 Switch Operation ..... . 2-15 Diagnostic Tests . - Page 19 BOUT THE WITCHES Non-volatile Parameter Storage ..2-15 Management Options ....2-16 Serial Console Interface ....2-16 Telnet .
-
Page 20: Overview
The three TigerSwitch 16 models are shown below: Figure 2-1. TigerSwitch 16 Model SMC6516TT with two 100BASE-TX Ports Figure 2-2. TigerSwitch 16 Model SMC6516FF with two 100BASE-FX Ports Figure 2-3. TigerSwitch 16 Model SMC6516TF with one 100BASE-TX Port and one 100BASE-FX Port BOUT THE WITCHES... - Page 21 BOUT THE WITCHES The Fast Ethernet ports on each switch are contained in a sin- gle, dual-port replaceable module.* This modular design allows you the option of installing different types of Fast Ethernet ports, according to your changing network needs.
-
Page 22: Figure 2-4. 10Base-T Ports
Figure 2-4. 10BASE-T Ports 100BASE-TX Port(s) Models SMC6516TT and SMC6516TF are equipped with at least one 100BASE-TX port (port 18). Port 17 on model SMC6516TT is another 100BASE-TX port. Like the 10BASE-T ports, each 100BASE-TX port is labeled with an “x”... -
Page 23: Figure 2-5. Smc6516Ff With 100Base-Fx Ports
100BASE-FX Port(s) Ports 17 and 18 on TigerSwitch 16 model SMC6516FF and port 17 on model SMC6516TF are 100BASE-FX ports with SC connec- tors. In full-duplex mode, these ports can be connected to a corporate backbone or central site with up to 2 km of fiber cable. -
Page 24: Figure 2-6. Rj-45 Integrated Leds
Yellow *Note: The Link LEDs on unconnected ports will blink approximately once every 5 seconds. This blinking reflects background diagnostics run automatically by the switch and is not indicative of any error. BOUT THE Description Port is not in use, attached device is... -
Page 25: Figure 2-7. Vertical Led Array And Port Select Button
BOUT THE WITCHES Shared Vertical LED Array and Port Select Button At power-up, the shared vertical LED array displays the status of port 1. To display the status of port 2, press the Port Select but- ton located to the right of the array. Repeated depressions of this button will cycle through all eighteen ports. -
Page 26: Figure 2-8. Console Port And Reset Button
Each switch contains a Console port on the front panel. This is an RS-232 serial port with a DB-9 connector. When connected to a PC, this port can be used to configure the switch and to monitor the switch out-of-band and in-band via Telnet. -
Page 27: Figure 2-9. Power Supply Receptacles
Redundant Power Unit (RPU). Figure 2-9. Power Supply Receptacles Power and RPU LEDs located on the front panel of each switch indicate the status of both the internal and redundant power supplies. These LEDs are described on the following page. - Page 28 Power Supply Status LEDs LED Condition Power Redundant Power Green Green Green Green BOUT THE Status No AC power Internal power supply is operating properly; redundant power supply is not present or has been disconnected Both internal and redundant power supplies are operating properly Internal power supply has failed;...
-
Page 29: Features And Benefits
• SNMP agent for management by SMC’s EliteView other SNMP-based application • RS-232 Console port simplifies switch configuration and allows switch to be managed out-of-band • 4-group RMON support - Event, Alarm, Statistics and History groups - for pro-active management •... -
Page 30: Switch Architecture
Addresses are automatically learned by each TigerSwitch 16 unit and main- tained in the address table to enable the switch to perform filter- ing and forwarding at line-rate speeds. When a packet contain- ing a destination address that does not appear in the table is encountered, the packet is broadcast to all segments. -
Page 31: Spanning Tree Protocol
BOUT THE WITCHES Spanning Tree Protocol The TigerSwitch 16 family supports the IEEE 802.1d Spanning Tree Protocol. This protocol adds a level of fault tolerance by allowing two or more redundant connections to be created between a pair of LAN segments. When there are multiple physical paths between segments, the protocol can choose a single path at any given time and disable all others. -
Page 32: Switch Operation
Upon power-up, the test results are displayed on the PC attached to the Console port. During the test sequence, the switch detects whether or not the software is loaded. If it is, the Main Menu is displayed. Otherwise, the Boot Loader Menu is displayed so that new software can be downloaded. -
Page 33: Management Options
Windows Terminal. An RS-232 standard null-modem cable with a DB-9 connector is used to connect the device to the Console port on the switch. (See “Connecting to the Console Port” in Chapter 4 for detailed instructions.) This interface operates at 9600 (default value) or 19,200 baud and can be password-protected. - Page 34 BOUT THE WITCHES SNMP In addition, the switches can be managed in-band from a work- station using EliteView or any other SNMP-based manager. Simple Network Management Protocol (SNMP), the most popu- lar management protocol in use today, defines the structure of information maintained on a device being managed, and the operations used to access the information.
-
Page 35: Planning
Integrating Ethernet and Fast Ethernet ..3-9 TigerSwitch 16 Model SMC6516TT ..3-9 TigerSwitch 16 Model SMC6516TF ..3-10 TigerSwitch 16 Model SMC6516FF ..3-11... -
Page 36: Benefits Of Switching
LANNING Benefits of Switching Ethernet is traditionally a shared technology. Its media (network cable) is shared, so only one transmission can take place at a time. Its 10 Mbps bandwidth is shared too, so as more users are added to the network, there is less available bandwidth for each user. -
Page 37: Switched Fast Ethernet - High-Speed Data Pipes
into multiple collision domains, yet cost-effective enough to allow users to dedicate bandwidth to workstations, file servers and print servers. At the desktop level, switches can replace Ethernet hubs. By providing servers and high-performance workstations with dedi- cated 10 Mbps LAN connections, switches boost the throughput and performance of bandwidth intensive applications, such as imaging, CAD/CAM and relational database access. -
Page 38: Segmenting The Network
LANNING Segmenting the Network Each port on a switch is a separate segment, so when imple- menting switching, you must decide how to segment the network. For desktop switching, the decision is easy, as each PC is on a separate segment. For segment switching, it is a good idea to investigate the traffic flow on the network and the interactions of the applications being used. -
Page 39: Full-Duplex Operation
LANNING Full-Duplex Operation Full duplex is a transmission method that allows a network device to transmit and receive concurrently. This mode is sup- ported by some 10BASE-T and 100BASE-TX switches and net- work cards, but not by hubs or by 100BASE-T4 devices. Connecting a pair of devices that can operate in full-duplex mode eliminates collisions and effectively doubles the band- width of that segment. -
Page 40: Sample Applications
LANNING Sample Applications Sample applications are provided below. They show how switching technology can increase the performance of a shared Ethernet Client/Server LAN without extensive network reconfig- uration and changes to the infrastructure. Shared Ethernet LAN In the traditional Client/Server LAN, all the workstations and servers are connected to stackable and/or standalone hubs. -
Page 41: Figure 3-2. Microsegmented Lan
LANNING Segmented Ethernet LAN To reduce contention, the network is segmented into separate repeater groups. This enables the workstations on each segment to share the 10 Mbps bandwidth of that segment. Reducing the number of stations on each segment decreases the amount of collisions that occur as a matter of course on a conventional shared Ethernet LAN when traffic is heavy. -
Page 42: Figure 3-3. Switched Lan
This provides them both with 20 Mbps of band- width. One of these ports is connected directly to a server and the other, to another Ethernet switch to provide additional ports for the stack segments. Figure 3-3. Switched LAN... -
Page 43: Figure 3-4. Sample Application With Model Smc6516Tt
In the following figure, one 100BASE-TX port is connected to SMC’s TigerSwitch 100 (an 8-port Fast Ethernet switch) and the other 100BASE-TX port to a server. Note that two PCs are con- nected directly to 10BASE-T ports on the TigerSwitch 16, pro- viding each power user with 20 Mbps of aggregate bandwidth in full-duplex mode. -
Page 44: Figure 3-5. Sample Application With Model Smc6516Tf
The 100BASE-TX port can be used to provide a dedicated bandwidth (200 Mbps in full-duplex mode) to a server or power user that is close to the switch. In the following figure, the 100BASE-FX port is connected to a remote central site and the 100BASE-TX port, to a server. -
Page 45: Figure 3-6. Sample Application With Model Smc6516Ff
The following figure shows the 100BASE-FX ports on an SMC6516FF switch connected to the 100BASE-FX ports on other TigerSwitch units, making it the central link in a 200 Mbps network backbone. The 100BASE-TX ports on the other switches, also configured in full duplex mode, are dedicated to servers. -
Page 46: Installing
Selecting a Site ..... . . 4-2 Equipment Checklist ....4-3 Package Contents . -
Page 47: Selecting A Site
Be sure to follow the guidelines below when choosing a location. The switch site should: • be able to maintain its temperature within 0° to 50° C and its humidity within 10% to 90%, non-condensing •... -
Page 48: Equipment Checklist
Equipment Checklist After unpacking your switch, check the contents of the box against the packing list below to be sure you’ve received all the components. Package Contents In addition to this user guide, the package should contain: One TigerSwitch 16 switch... -
Page 49: Mounting
Mounting instructions for each type of site follow. Rack Mounting Before rack mounting the switch, pay particular attention to the following factors: Temperature: Since the temperature within a rack assem- bly may be higher than the ambient room temperature, check that the rack-environment temperature is within the specified operating temperature range. -
Page 50: Figure 4-2. Installing The Switch In A Rack
1. Attach the four adhesive feet to the bottom of the switch. Figure 4-3. Attaching the Adhesive Feet 2. Set the switch on a flat surface near an AC power source, making sure there are at least two inches of space on all sides for proper air flow. -
Page 51: Connecting To The Console Port
To make the connection: 1. Plug the female end of a standard RS-232 null-modem cable into the switch connector labeled Console. Plug the other end of the cable into the serial connector on the PC (typically COM1 or COM2). See Appendix A for Console connector pin assignments. -
Page 52: Connecting To A Power Source
Connecting to a Power Source 1. Plug one end of the appropriate power cable (see below) into the back of the switch, and the other end into a grounded, 3-pin socket. For North American Use: Each switch is shipped with one standard AC line cord for North America that is UL and CSA approved. -
Page 53: Diagnostic Self-Tests
NSTALLING Diagnostic Self-Tests When the switch is powered up, diagnostic tests are performed, and the test results are displayed on the PC attached to the Console port. ___________________________________________________ ROM Checksum Local RAM Test (Byte) ..PASSED... -
Page 54: Making Network Connections
Making Network Connections Switches are designed to interconnect multiple segments, or collision domains. Each segment may contain a single server or workstation, or multiple workstations that are connected to a hub. An overview of the rules for both Ethernet and Fast Ethernet collision domains is provided below. -
Page 55: 100 Mbps Fast Ethernet Collision Domain
Cable Type Connecting Twisted Pair Any two devices Fiber Switch to Switch, Server or PC Half duplex Full duplex Any two devices *Note: Network Diameter is defined as the wire distance between two end stations in the same collision domain. -
Page 56: Twisted-Pair Devices
Crossover/Straight-Through Wiring Requirements The port on the TigerSwitch 16 is... Crossover (x) Crossover (x) If the hub or switch port is... Crossover (x) Straight-through NSTALLING Then use...cable Crossover Straight-through... -
Page 57: Figure 4-7. Connecting Fiber Cable
Use only certified Category 5 cable for the 100BASE- TX connection. Attach one end of the cable to an unused port on the switch, and the other end to the RJ-45 port on the other device. As each connection is made, the green LED above the port will light (after 2-3 seconds) to indicate that the connection is valid. -
Page 58: Default Settings
NSTALLING Default Settings Each switch is set to operate as a transparent bridge using the default operating parameters. It will automatically learn the addresses of all active stations on each segment and appropri- ately switch traffic between its ports. To change the configura- tion of the switch, turn to Chapter 5. -
Page 59: Configuring And Monitoring
Main Menu ......5-4 Switch Configuration Menu ... . 5-5 Configuration Display Screen . - Page 60 ONFIGURING AND ONITORING Telnet Menu ..... . . 5-24 Typical Configuration Operations ..5-25 Setting the Password .
-
Page 61: The Console Interface
The Console Interface Once a PC has been connected to the Console port on the front panel of the switch, it can be used to reconfigure the switch and monitor its operation out-of-band. If you have not already done so, power up the device and set the communications program to the following parameters: 9600, n, 8, 1 (9600 baud, no parity, 8 bits, 1 stop bit). -
Page 62: Figure 5-1. Main Menu
Switch Configuration Menu—Displays the Switch Configura- tion Menu (see Figure 5-2). This menu allows you to configure parameters which affect the operation of the switch. Port Configuration Menu—Displays the Port Configuration Menu (see Figure 5-9). This menu allows you to view port set- tings and to select a port so you can change its settings. -
Page 63: Switch Configuration Menu
ONFIGURING AND ONITORING Switch Configuration Menu The Switch Configuration Menu is accessed from the Main Menu. ___________________________________________________ >>>> Switch Configuration Menu <<<< 1. Configuration Summary 2. IP Configuration 3. SNMP Configuration 4. Spanning Tree Configuration 5. Address Aging Configuration 6. Port Mirroring Configuration <ESC>... - Page 64 ONFIGURING AND ONITORING Address Aging Configuration—Displays the Address Aging Configuration Menu (see Figure 5-7). This menu allows you to turn address aging on and off, and to set the aging time. Port Mirroring Configuration—Displays the Port Mirroring Configuration Menu (see Figure 5-8). This menu allows you to turn port mirroring on and off, and to select both the port to be mirrored and the port to be used for monitoring.
-
Page 65: Figure 5-3. Configuration Display Screen
Configuration Display Screen The Configuration Display Screen is accessed from the Switch Configuration Menu. ___________________________________________________ >>>> Configuration Display Number of Ports... [ 18 ] Port 1 MAC Address... [ 00800F80000A ] Switch IP Address... [ Default SNMP Manager IP Address [ Default Gateway IP Address... - Page 66 Subnet Mask—Displays the IP subnet mask that corresponds to the assigned IP address. SLIP Enable—Indicates whether SLIP is enabled or disabled. SLIP is not enabled until after the switch has been reset. SLIP IP Address—Displays the SLIP IP address. SLIP Subnet Mask—Displays the SLIP subnet mask that corre- sponds to the assigned SLIP IP address.
-
Page 67: Figure 5-4. Ip Configuration Menu
Default SNMP Manager IP Address—Allows you to enter the IP address of the default SNMP manager. Default Gateway IP Address—Allows you to enter the IP address of the default gateway to which the switch sends IP ONFIGURING AND ONITORING <<<<... - Page 68 “enable”, the swtich must be reset to actually enable SLIP. SLIP IP Address—Allows you to enter the SLIP IP address. Note: This address must be different from the Switch IP address. The Host Address can be the same,.but the network number must be different.
-
Page 69: Figure 5-5. Snmp Configuration Menu
(up to 10 alphanumeric characters) for write SNMP access. System Location—Allows you to enter the physical location (up to 24 alphanumeric characters) assigned to the switch for SNMP management purposes. System Name—Allows you to enter the administrative name (up to 24 alphanumeric characters) assigned to the switch for SNMP management purposes. -
Page 70: Figure 5-6. Spanning Tree Configuration Menu
Switch Forwarding Delay—Allows you to enter the amount of time (4 - 30 seconds) a switch port spends in the listening and learning states. Display Current Spanning Tree Parameters In Use—... -
Page 71: Figure 5-7. Address Aging Configuration Menu
ONFIGURING AND ONITORING Address Aging Configuration Menu The Address Aging Configuration Menu is accessed from the Switch Configuration Menu. ___________________________________________________ >>>> Address Aging Configuration Menu <<<< 1. Address Aging... [ On ] 2. Address Aging Time (120-1000000 sec). [ 300 ] <ESC>... -
Page 72: Figure 5-8. Port Mirroring Configuration Menu
ONFIGURING AND ONITORING Port Mirroring Configuration Menu The Port Mirroring Configuration Menu is accessed from the Switch Configuration Menu. ___________________________________________________ >>>> Port Mirroring Configuration Menu 1. Port Mirroring... [ 2. Mirror Port... [ 3. Monitor Port... [ <ESC> To Exit Menu... -
Page 73: Figure 5-9. Port Configuration Menu
ONFIGURING AND ONITORING Port Configuration Menu The Port Configuration Menu is accessed from the Main Menu. ___________________________________________________ >>>> Port Configuration Menu <<<< 1. Port Summary 2. Address Tables 3. Port Settings <ESC> To Exit Menu Enter Selection: ___________________________________________________ Figure 5-9. Port Configuration Menu Menu Selections Port Summary—Displays the Port Summary Display Screen (see Figure 5-10). -
Page 74: Figure 5-10 Port Summary Display Screen
ONFIGURING AND ONITORING Port Summary Display Screen The Port Summary Display Screen is accessed from the Port Configuration Menu by selecting “Port Summary.” All the fields on this screen are read-only. ___________________________________________________ >>>> Port Summary Display Port Port Type MAC Address 10BaseT] [00800F800014] [Forwarding] [ 10BaseT] [00800F800015] [Forwarding] [ 10BaseT] [00800F800016] [Forwarding] [... -
Page 75: Figure 5-11. Port Summary Configuration Menu
Port Summary Configuration Menu The Port Summary Configuration Menu is accessed from the Port Configuration Menu by selecting “Port Settings.” In addi- tion to displaying the settings for all ports, the menu allows you to change the settings for a particular port (see Figure 5-12). >>>>... -
Page 76: Figure 5-12. Port [X] Configuration Menu
ONFIGURING AND ONITORING Port [x] Configuration Menu The Port [x] Configuration Menu is accessed from the Port Summary Configuration Menu by entering the number of a port whose settings are to be edited. ___________________________________________________ Port [x] Configuration Menu 1. Port Status... [ 2. -
Page 77: Figure 5-13. Statistics Menu
ONFIGURING AND ONITORING Statistics Menu The Statistics Menu is accessed from the Main Menu. The selec- tions on this menu are standard MIB II read-only statistics (refer to RFC 1213). ___________________________________________________ >>>> Statistics Menu <<<< 1. Display System Statistics 2. Display IF Statistics 3. -
Page 78: Figure 5-14. Utilities Menu
ONFIGURING AND ONITORING Utilities Menu The Utilities Menu is accessed from the Main Menu. ___________________________________________________ >>>> Utilities Menu 1. Console Configuration 2. Display/Clear Error Log 3. Password Configuration 4. Reset To Factory Defaults 5. Initiate Software Download 6. Establish Telnet Session 7. - Page 79 ONFIGURING AND ONITORING Reset To Factory Defaults—Allows you to reset the system to factory defaults. This procedure only resets the switch parame- ters. You are prompted with the message: “Reset to factory defaults ? (Y/N).” Initiate Software Download—Displays the Boot Menu (see Figure 5-16).
-
Page 80: Figure 5-15. Console Configuration Menu
ONFIGURING AND ONITORING Console Configuration Menu The Console Configuration Menu is accessed from the Utilities Menu by selecting “Console Configuration.” ___________________________________________________ >>>> Console Configuration Menu 1. Baud Rate...[ 9600 ] 2. Accept New Settings <ESC> To Exit Menu Enter Selection: ___________________________________________________ Figure 5-15. -
Page 81: Figure 5-16. Boot Menu
ONFIGURING AND ONITORING Boot Menu The Boot Menu is accessed from the Utilities Menu by selecting “Initiate Software Download.” ___________________________________________________ >>>> TigerSwitch 16 Boot Menu <<<< Boot Code Version XX.XX 1. Software Download via RS-232 Interface 2. Software Download via TFTP 3. -
Page 82: Figure 5-17. Telnet Menu
ONFIGURING AND ONITORING Telnet Menu The Telnet Menu is accessed from the Utilities Menu by select- ing “Establish Telnet Session.” ___________________________________________________ >>>> Telnet Menu <<<< 1. Configure Telnet Server IP Address.[ 0. 0. 0. 0] 2. Initiate Telnet Session <ESC> To Exit Menu Enter Selection: ___________________________________________________ Figure 5-17. -
Page 83: Typical Configuration Operations
Setting the Password Setting a password prevents unauthorized users from reconfig- uring the switch. At the factory, the password is not enabled so that you may access the console interface and set the first pass- word. -
Page 84: Disabling The Password
2. At the Switch Configuration Menu, type 2 to display the IP Configuration Menu. 3. Type 1 to select “Switch IP Address,” and then enter the IP address assigned to the switch. 4. The system then asks you to confirm the address by prompt- ing: “Confirm Switch IP Address (Y/N).”... -
Page 85: Changing The Port Settings
Addresses relearned within the time configured have their aging timer reset. To configure address aging: 1. At the Main Menu, type 1 to display the Switch Configuration Menu. 2. At the Switch Configuration Menu, type 5 to display the Address Aging Configuration Menu. -
Page 86: Configuring Spanning Tree Protocol
The default settings should be acceptable in most networks. If you need to change the defaults, proceed as follows: 1. At the Main Menu, type 1 to display the Switch Configuration Menu. 2. At the Switch Configuration Menu, type 4 to display the Spanning Tree Configuration Menu. -
Page 87: Downloading New Software
Downloading New Software New software may be downloaded to the switch via TFTP or the RS-232 Console port. Downloading via TFTP is substantially faster. Serial downloading (via the Console port) may take in excess of half an hour or more. -
Page 88: Figure 5-18. Tftp Loader Menu
Enter the IP address. 8. Type 3, and you are prompted to enter the IP address of the switch. Enter the IP address. 9. If desired, you may select 7 to ping the server and test its status before beginning the download. -
Page 89: Downloading Software Via Rs-232 Port
4. Type 1 to initiate a software download. The system prompts with a warning and the message: “DO YOU WANT TO CON- TINUE? (Y/N).” Note: If you type Y, all network traffic through the switch will be disabled. 5. Type 1 to begin the download. A warning message is dis- played followed by the prompt: “START RS-232 DOWN-... -
Page 90: Typical Monitoring Operations
Displaying the Current Configuration To display information about the current configuration of the switch: 1. At the Main Menu, type 1 to display the Switch Configuration Menu. 2. At the Switch Configuration Menu, type 1 to display the Configuration Display Screen. -
Page 91: Displaying Spanning Tree Parameters
Displaying Spanning Tree Parameters To display the current Spanning Tree Parameters: 1. At the Main Menu, type 1 to display the Switch Configuration Menu. 2. At the Switch Configuration Menu, type 4 to display the Spanning Tree Configuration Menu. 3. At the Spanning Tree Configuration Menu, type 6 to display the current Spanning Tree Parameters. -
Page 92: Using Telnet
ONITORING Using Telnet The console interface can also be used to configure and moni- tor the switch in band via Telnet. Telnet is a common terminal emulation application used in TCP/IP networks for remote ter- minal access to computer devices. -
Page 93: Using Slip
SNMP using SLIP, proceed as follows: 1. From the Main Menu, type 1 to select the Switch Configuration Menu. 2. From the Switch Configuration Menu, type 2 to select the IP Configuration Menu. ________________________________________________________ >>>> IP Configuration Menu 1. - Page 94 ONFIGURING AND ONITORING 5. Connect one end of an RS-232 modem cable to the switch and the other end to a modem. Plug the modem into the phone jack. Also, be sure the modem is set to Auto-answer. 6. Configure the remote workstation to use the SLIP protocol.
- Page 95 and the operating mode (half or full duplex). 5-37...
-
Page 96: Managing Via Snmp And Rmon
HAPTER SNMP ANAGING RMON SNMP Protocol ..... . . 6-2 Using RMON ......6-3 MIB Objects . -
Page 97: Snmp Protocol
SNMP ANAGING SNMP Protocol SNMP (Simple Network Management Protocol) is a communica- tion protocol designed specifically for the purpose of managing devices or other elements on a network. Network equipment commonly managed with SNMP includes hubs, switches, bridges, routers and host computers. SNMP is typically used to configure these devices for proper operation in a network envi- ronment, as well as monitor them to evaluate performance and detect potential problems. -
Page 98: Using Rmon
Using RMON The switch offers an RMON subset contained within the basic system management. The objects supported are some of the most pertinent objects within RMON and include the Event, Alarm, Statistics and History groups. - Page 99 SNMP ANAGING The main standard MIB, referred to as MIB II, provides an over- all view of the managed agent and is supported, at least in part, by all SNMP agents. In addition, proprietary MIB extensions are defined by commercial vendors for managing device-specific functions of their products.
- Page 100 Specifications ......A-2 10BASE-T/100BASE-TX Pin Assignments ..A-3 Straight-Through Wiring ....A-4 Crossover Wiring .
-
Page 101: Cables
ABLES Specifications Cable Type 100 ohm UTP 22 - 26 AWG 0.4 - 0.6 mm Cable Type 62.5/125 micron core Twisted-Pair Cable Technology Category 10BASE-T 3, 4, 5 100BASE-TX 5 certified Fiber Cable Technology 100BASE-FX Connector male 8-pin RJ-45 Connector... -
Page 102: 10Base-T/100Base-Tx Pin Assignments
10BASE-T/100BASE-TX Pin Assignments Caution: Regulations regarding the connection of equipment to telephone networks vary from country to country. Check with your local telephone network supplier before using existing telephone wiring. An Ethernet twisted-pair link segment requires two pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes. -
Page 103: Straight-Through Wiring
ABLES Straight-Through Wiring If the twisted-pair link segment is to join two ports and only one of the ports has an internal crossover, the two pairs of wires must be straight-through. Straight-Through RJ-45 Pin Assignments End 1 1 (Tx+) 2 (Tx-) 3 (Rx+) 6 (Rx-) Crossover Wiring... -
Page 104: Serial Console Port Pin Assignments
Serial Console Port Pin Assignments Any cable connected to the Console port must be shielded to comply with FCC emissions regulations and with requirements of other regulatory agencies in various parts of the world. RS-232 Pin Assignments Signal Computer DB25 ABLES TigerSwitch 16... - Page 105 Model SMC6516FF ....B-4 Model SMC6516TF ....B-5...
-
Page 106: Specifications
PECIFICATIONS Specifications All Models Buffer Architecture Central memory, dynamic allocation 3 Mbytes DRAM Architecture Latency 12 µs MAC Addresses 8,192 total, dynamically allocated among all ports Forwarding/Filtering/Learning Rates Full line-rate for 10 Mbps ports Full line-rate for 100 Mbps ports In-band Management Telnet or any SNMP manager Out-of-band Management... - Page 107 LEDs Power Redundant Power Port Status - 1 per port Port Select - 1 per port Shared vertical array Receive Collision Full Duplex 100 Mbps Buttons Port Select Reset Size 16.9 in.W x 9.2 in. D x 1.7 in. H (42.9 cm x 23.4 cm x 4.3 cm) Temperature Operating 32°...
-
Page 108: Model Smc6516Tt
PECIFICATIONS Compliances CE marking Safety UL 1950 CSA 22.2 No. 950 EN 60950 Immunity IEC 801-2.3.4 EN 50082-1 Emissions FCC Class A CDOC Class A EN 55022 (CISPR 22) Class A VCCI Class 1 Warranty Three years Model SMC6516TT Ports 16 10BASE-T 2 100BASE-TX with Auto-Negotiation Weight... -
Page 109: Model Smc6516Tf
PECIFICATIONS Model SMC6516TF Ports 16 10BASE-T 1 100BASE-TX with Auto-Negotiation 1 100BASE-FX with full-duplex support Weight 10.0 lbs. (4.54 kg) -
Page 110: Sample Configuration
PPENDIX C AMPLE ONFIGURATION Introduction ......C-2 Windows Terminal ....C-3... -
Page 111: Introduction
• All data flow control parameters are turned OFF. • Any parameters that would add characters to the download file (such as line feeds) are turned OFF. • The console speed of the switch corresponds to the terminal setting. Setting the Console Speed To set the console speed on the switch: 1. -
Page 112: Windows Terminal
Windows Terminal If you are using the Windows program called Terminal, you can use the defaults except for the following: Menu Settings - Terminal Emulation Settings - Text Transfers Settings - Communications Settings - Terminal Preferences Transfers - Send Text File * If the menu screens start scrolling during the transfer, you may need to set Delay Between Lines to 1 and try the transfer again. -
Page 113: Troubleshooting
PPENDIX ROUBLESHOOTING Troubleshooting Chart ....D-2... -
Page 114: Troubleshooting Chart
Off Link LED is Off Troubleshooting Chart Action No AC power. Check connections between the switch, the power cord and the wall outlet. Contact SMC Tech Support. Internal or redundant power supply has failed or is disconnected. Internal power supply is operating not present or has been disconnected. - Page 115 FOR TECHNICAL SUPPORT, CALL: From U.S.A. and Canada (8:30 AM - 8:00 PM Eastern Time) (800) SMC-4-YOU; (516) 435-6250; (516) 434-9314 (Fax) From Europe (8:00 AM - 5:30 PM UK Greenwich Mean Time) 44 (0) 1344-420068; 44 (0) 1344-418835 (Fax) Bulletin Board Services (BBS) Modem settings: 9600,8,n,1 New York: (516) 434-3162 (connect speed up to 14,400)
