SMC Networks SMC6924VF Specifications

Switches/Hubs
The TigerSwitch 100 is capable of delivering the
power and speed your network needs, with the quali-
ty you've come to expect from SMC. Available in 24
100BASE-FX MMF VF-45 ports, each unit contains 2
expansion slots that can be used for Gigabit, 100Mbps
Fiber, or SMC' s innovative new stacking module. This
inexpensive module allows you to 'Stack-As-You-Go' ,
creating a stack of up to 4 switches.
Overview
Advanced Features
• Stack-As-You-Go – Innovative stacking
module saves money by allowing you to
stack as you expand.
• High Port Density – Stack up to 4 units for a
total of 96 10/100 ports
• Convenient Expansion – Each unit comes
with 2 slots supporting Gigabit , 100Mbps
Fiber SC/ST or Stacking M odules.
• QoS expedites critical data via prioritizing
and filtering
• MultiLink Trunking creates high-speed data
paths to servers or other switches
• VLAN Support provides port VLANs and
GVRP for auto-registration
• IGMP Snooping reduces multicast traffic for
6 H u g h e s
maximum performance
Irv i n e, CA 92618 • Broadcast storm control allows a user-
defined threshold to limit broadcast traffic
1-800-SMC-4YOU
w w w. s m c. co m
TigerSwitch
Layer 2 Stackable 24-Port Fiber Managed Switch with
Optional Gigabit Uplinks
Benefits
• EliteView, SMC's full-features, Windows-based SNMP
management software, included free
• Manage and configure the TigerSwitch 100 from any
Web-browser
• 4 group RMON support for detailed monitoring of
network performance
• RS-232 port available for out-of-band direct or
remote management
• Mirror port traffic from any port for easy
troubleshooting
100
TM
Model Number::
Advanced features like Quality of Service, VLAN sup-
port, MultiLink Trunking and Broadcast Control provide
maximum pe rfo rm a n ce benefits while maint a i n i n g
security and reducing network problems. Spanning
Tree support, redundant management and optional
redundant power provide network resiliency and lower
the total cost of ownership. SNMP, RMON and a full-fea-
tured Web based interface provide the means to mon-
i tor netwo rk status and pe rfo rm a n ce leve l s. Th e
TigerSwitch 100 is further backed by a comprehensive
limited lifetime warranty and SMC' s award winning free
technical support.
Compatibility
• IEEE 802.3 Ethernet
• IEEE 803.3u Fast Ethernet
• IEEE 803.3z Gigabit Ethernet
• IEEE 802.1d Spanning Tree Protocol and
• IEEE 802.1P Priority Tags
• IEEE 802.1Q VLAN
• IEEE 802.3ac VLAN Tagging
• IEEE 802.3x Full-duplex flow control
• IEC 8802-3
• SNMP (RFC 1157), RMON (RFC 1757), ARP
• IGMP (RFC 1112),MIB II (RFC 1213),
• (RFC 1643), Bridge MIB (RFC 1493)
SMC6924VF
traffic priorities
(RFC 826),
Ethernet-like MIB
