When drying clothes, they will dry quicker if the room is smaller and the air
is directed as shown in the picture
If the appliance is in the timer mode prior to entering the laundry mode,
the laundry mode will continue until the end of the set time and stop. If the
timer button is pressed while in the laundry mode, the unit will continue in
the laundry mode until the end of the set time and stop.

Compressor protection function

Should there be a problem with the unit causing the compressor to stop,
the compressor will turn off for 5 minutes. Normally the compressor will
restart after 5 minutes, if it does not unplug the unit for an hour and try
again. If it still does not start, call for service.
High/Low temperature protection
function
If the unit detects that the ambient temperature is 0°C≤ or ≥40°C, it will
shut down. In this condition both the POWER and DEFROST lights will fl ash.
While in the mode the ON/OFF button makes a sound but does not work.
To reset the unit, unplug the power and restart.

Continuous drainage function

Should it be necessary to provide continuous drainage, this can be
achieved by fi tting a 15 mm inner diameter pipe to the drainage hole on
the rear of the unit. When installed, water will drain through the pipe and
not into the water tank.
Ensure that the drainage pipe runs in a downwards direction, and it not
bent or damaged in any way so that the water runs freely out of the unit.
When fi tting the drainage pipe, make sure that it is pushed all the way into
the drainage hole so that it pushed over the drain outlet which is located
about 70 mm inside the unit from the rear cover of the unit.
Refer to the 3 on page 2 for the location of the drainpipe connection port.

Maintenance

When cleaning your dehumidifi er:
• Use a soft clean cloth.
• Do not use the alcohol, gasoline, and other benzene chemical solvents.
• To clean the fi lter, remove it, then use a vacuum cleaner to clear any dust
which may have built up. If necessary, use water to clean, then place it in
ventilated area until dry.
• Unplug the unit from the mains supply before cleaning.
Other advice:
• Before moving the unit, unplug the mains supply and pull out the water
in tank.
• If not using the unit for a long time, unplug the unit from the mains sup-
ply, empty the water tank, wait for 2 days to make sure the unit inside
completely dry before packing.
• Always store the unit in an upright position.
• Do not tilt the unit horizontally or turn upside down.
• If the unit requires repair, seek help of a professional person.
4.

Troubleshooting

Problem Cure
Check that the unit is plugged into the mains
Dehumidifi er does supply and turned on.
not work Check that the water tank is not full. If it is full,
empty the tank.
Check that the water tank is installed correctly.
Check that the water tank is not full. If it is full,
Does not empty the tank.
dehumidify Clean the air fi lter.
Ensure that the air fl ow through the unit is not
obstructed.
Reduce ventilation (closed doors and windows).
Ensure that there are not too many sources of
Does not remove
humidity.
enough moisture
Ensure that the unit is not being used to
from the air
dehumidify a room in excess of the size noted in
the specifi caitons.
Unit does not run Ensure that the castors are clean and not clogged
smoothy on the with debris.
castors
What to do if the product interferes with radio or TV reception.
If the dehumidifi er interferes with radio or television reception, try one or
more of the following measures:
– Adjust or reposition the receiving antenna.
– Increase the distance between the product and the radio or TV.
– Connect the equipment into an outlet on a circuit diff erent from that of
the radio or TV receiver.
– Consult the dealer or a qualifi ed radio or TV technician.

Technical specifi cation

Model
Dehumidifi cation (Litres per day); 30 °C,
80% RH
Rated voltage
Power consumption (W); 30 °C, 80% RH
Air fl ow volume (m³/h)
Room Size (m²)
Refrigerant
Refrigerant volume (g)
Water tank capacity (l)
Unit size (W x H x D in mm)
Weight (kg)
Cord length (cm)
Standby power (W)
NOTE:
– RH - Relative Humidity
– Room size based on JEMA (Japan Electrical Manufacturers' Association)
standard.
EN
UD-T10A, UD-T104A
10
220-240 V AC /50 Hz
220 W
90
Max 22
R290
35
2
290 x 476 x 245
12
180
0,42
