Konica Minolta DK-504 Installation Manual

Applied Machines: C353/C253/C203/C353P
COLOR MFP (Color/B&W): 35 ppm / 35 ppm, 25 ppm / 25 ppm, 20 ppm / 20 ppm
COLOR PRT (Color/B&W): 35 ppm / 35 ppm
Product Code: A02E
Note:
Lifting the machine in an awkward position or
transporting it in a poorly balanced position could
result in personal injury. When transporting the
machine, assign an adequate number of persons
to the job and ensure that each person can take a
good position of not being excessively loaded
(mass: approx. 20 kg (44 lb)).
I. Accessory parts
No. Name
1. Fixing leg
2. Fixing leg
cover
3. Fixing
bracket A
4. Fixing
bracket B
5. Fixing
bracket C
6. Screw A
(black)
(4 × 8 mm)
7. Screw B
(black)
(3 × 8 mm)
8. Screw C
(4 × 8 mm)
DK-504
INSTALLATION MANUAL
Shape Q'ty
4
4348U020AB
4
4348U099AB
2
4658U021AA
1
A093IXC003DA
1
A093IXC004DA
4
4038IXC033DA
1
4040IXC046DA
12
4038IXC033DA
Desk
No. Name
9. Installation
manual
After unpacking, be sure to get rid of the
packaging materials and keep them out of
the reach of children.
Putting the head in the plastic bag
involves danger of suffocation.
Note:
When removing the desk from its shipping carton,
do not hold onto the reinforcement bracket (as a
personal injury or a deformed frame could result).
Reinforcement bracket
II. When installing to C353P
This manual provides the illustration of the machine
used as MFP. However, the same installation proce-
dure is used for C353P.
E-1
Shape Q'ty
1
set
4980IXC019DA
A093IXE075DA
A093-9553-00
