Pioneer SC-LX901B Service Manual page 153

<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
: NSP
REF. NO. PART NAME DESCRIPTION
[ Semi-conductors ]
D7401 DIODE LN6SB60
D7402 DIODE LN6SB60
Q7211 TRANSISTOR 2SD2400A-D
Q7212 TRANSISTOR 2SB1569A-D
Q7241 HYBRID IC 78M15HF(NJM78M15FA)
Q7251 HYBRID IC 78M12HF(NJM78M12FA)
Q7252 HYBRID IC 79M12HF(NJM79M12FA)
Q7271 HYBRID IC 78M08HF(NJM78M08FA)
Q7272 HYBRID IC 79M08HF(NJM79M08FA)
Q7273 HYBRID IC 78M15HF(NJM78M15FA)
X1 CRYSTAL HC-49S 9B12.000MHz
[ Transformers, Coils ]
L5 ANTENNA COIL K7-D
[ Capacitors ]
C7213 SMG C CE04W16V-100M(SMG)
C7214 SMG C CE04W16V-100M(SMG)
C7215 SMG C CE04W50V-10M(SMG)
C7219 SMG C CE04W50V-10M(SMG)
C7221 SMG C CE04W25V-47M(SMG)
C7241 SMG C CE04W25V-2200M(SMG)
C7244 SMG C CE04W50V-22M(SMG)
C7246 SMG C CE04W35V-220M(SMG)
C7251 SMG C CE04W25V-2200M(SMG)
C7252 SMG C CE04W25V-2200M(SMG)
C7255 SMG C CE04W35V-220M(SMG)
C7256 SMG C CE04W35V-220M(SMG)
C7271 SMG C CE04W16V-2200M(SMG)
C7272 SMG C CE04W16V-2200M(SMG)
C7293 SMG C CE04W16V-220M(SMG)
C7294 SMG C CE04W16V-220M(SMG)
C7298 SMG C CE04W35V-220M(SMG)
C7401 ELECTROLYTIC CAPACITOR CE69W80V-10000M_LKS1K10
C7402 ELECTROLYTIC CAPACITOR CE69W80V-10000M_LKS1K10
[ Resistors ]
R7211 NON-FLAMMABLE CARBON FILM RESISTOR25J-1.0K
R7213 NON-FLAMMABLE CARBON FILM RESISTOR25J-1.0K
R7403 NON-FLAMMABLE CARBON FILM RESISTOR25J-10
[ Switches, Terminals, Wires ]
P1 TERMINAL NTM-1PDSC438
P2 TERMINAL NTM-2PDML439
BAPS-2089-1D
Q'TY PART NO. (SN) REMARKS
1 22380399
1 22380399
1 2202734
1 2202724
1 222780155JRC
1 222780125JRC
1 222790125JRC
1 222780085JRC
1 222790085JRC
1 222780155JRC
1 3010533
1 232212
1 395041017T
1 395041017T
1 395081007T
1 395081007T
1 395054707T
1 395052227S
1 395082207T
1 395062217T
1 395052227S
1 395052227S
1 395062217T
1 395062217T
1 395042227S
1 395042227S
1 395042217T
1 395042217T
1 395062217T
1 3504527
1 3504527
1 415471024T
1 415471024T
1 415471004T
1 25060516
1 25060517
