Pioneer SC-LX901B Service Manual page 119

<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
: NSP
REF. NO. PART NAME DESCRIPTION
[ Semi-conductors ]
D5411 DIODE D2SB60A
D5412 DIODE SARS01
D5413 DIODE SARS01
D5451 DIODE FMEN-220A
D5962 LED SLR343BC4T
D7554 LED SLR343BC4T
D7555 LED SLR343BC4T
D7556 LED SLR343BC4T
D7557 LED SLR343BC4T
D7558 LED SLR343BC4T
Q5411 HYBRID IC STR2A153
Q5412 PHOTO COUPLER TLP781(GR)
Q7558 FLUORESCENT TUBE 016MT097GINYK
Q7652 REMOTE SENSOR GP1UE274XKC4
Q7652or REMOTE SENSOR R2113TH-5AD
[ Transformers, Coils ]
L5401 CHOKE COIL PFC2225C
L5411 LINE FILTER HF2318-A303Y0R6-01
L5451 CHOKE COIL RP1315BNP-100M
T5411 POWER TRANSFORMER ATK7006-A
[ Capacitors ]
C5403 CERAMIC CAPACITOR DE2F3KY103MA4BM02
C5411 IS TYPE CAPACITOR LE104-MX-C3.5
C5412 ELECTROLYTIC CAPACITOR CE69W400V-100M(KMM)
C5413 ELECTROLYTIC CAPACITOR CE04W50V-22M(LXZ)
C5414 FILM C ECQE6222KF
C5421 IS TYPE CAPACITOR DE1E3KX152MB5BA01
C5422 IS TYPE CAPACITOR DE1E3KX152MB5BA01
C5451 ELECTROLYTIC CAPACITOR CE04W10V-4700M(LXZ)
C5453 PW TYPE ELECTROLYTIC CAPACITOR CE04W10V-470M(PW)
C5712 SMG C CE04W50V-10M(SMG)
C5717 SMG C CE04W16V-100M(SMG)
C5718 SMG C CE04W16V-100M(SMG)
C7588 SMG C CE04W25V-47M(SMG)
C7655 SMG C CE04W16V-100M(SMG)
[ Resistors ]
R5414 RESISTOR ERG1DJ154P
R5415 METAL OXIDE FILM RESISTOR ERG1SJ680P
R5416 METAL RESISTOR ERX1SJR68H
R7577 NON-FLAMMABLE CARBON FILM RESISTOR25J-10
R7587 NON-FLAMMABLE CARBON FILM RESISTOR25J-10
[ Switches, Terminals, Wires ]
P5702 ST JACK MSJ-035-12APCAG
P5705 ST JACK MSJ-064-13ABAGGR(O133)
RL5401 RELAY NRL-1P10A-DC5-207
S5941 ROTARY ENCODER XREB12504PVB30FINB1-2-24
S5981 ROTARY ENCODER XREB12505PVB30FINB1-2-12
BADIS-2074-1K
Q'TY PART NO. (SN) REMARKS
1 22380366F
1 22380397
1 22380397
1 22380396
1 225470
1 225470
1 225470
1 225470
1 225470
1 225470
1 22242995
1 24120175
1 212286A
1 24130029
(1) 24130033 N
1 231490
1 231501
1 231466M100
1 2302140 !
1 3300083
1 3800049S !
1 3504524
1 3500248T N
1 3700116
1 3300062S !
1 3300062S !
1 3500247S
1 393734717T
1 395081007T
1 395041017T
1 395041017T
1 395054707T
1 395041017T
1 4000283F
1 4400045
1 4500343
1 415471004T
1 415471004T
1 25046035
1 25046036
1 25065731
1 25065729 N
1 25065730 N
