<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
: NSP
REF. NO. PART NAME DESCRIPTION
[ Cabinet, Chassis, Screws, Nuts ]
1 REAR PANEL LX901MGP
2 COVER LX901(S) (Bent)
3 COVER (IR)LX901 (Bent)
4 BOTTOM LEG (PI)(G)
5 SHEET SP_LX901
6 CUSHION CIRCLE 14B .
7 HEAT COND SHEET .
8 BUSH/ANT .
9 HOLDER (PLUG)
10 DOOR SPRING (SUS) .
11 SHAFT/DOR .
12 DOOR SLV
13 DAMPER/DOR .
14 BASE SLD
15 KNOV ASSY SLV
16 RING STB
17 CLEAR PLATE .
18 FILTER 81HY(PC)
19 FRONT PANEL LX901(S)
20 FRONT BRACKET (Silver)
21 BADGE (PI)(B)
22 BUTTON ASSY STB
23 RING .
24 VOL STABILIZER LX85 .
26 LABEL .
28 NUT NK90FTC
[ Transformers, Coils ]
50 POWER TRANSFORMER NPT-1676PQ
[ Switches, Terminals, Wires ]
60 FUSE 5A-SE-EAK FUSE
61 FUSE 215004.MXP
62 FUSE 1A-SE-EAK FUSE
63 FUSE 0.8A-SE-EAK FSBFUSE
64 FUSE 0.8A-SE-EAK FSBFUSE
65 FUSE 1A-SE-EAK FUSE
66 FUSE 1A-SE-EAK FUSE
67 FUSE 0.8A-SE-EAK FSBFUSE
68 FUSE 0.8A-SE-EAK FSBFUSE
69 FUSE 1A-SE-EAK FUSE
70 FUSE 1A-SE-EAK FUSE
71 FUSE 1A-SE-EAK FUSE
72 FUSE 1.6A-SE-EAK IECFUSE
73 LABEL T1.6AL250V
74 FLEXIBLE FLAT CABLE NCFC7-070712
75 FLEXIBLE FLAT CABLE NCFC5-351512
76 ASSEMBLED PWB WCBN806L
77 WIFI BT ANTENNA RFDPA870918EMLB302
78 WIFI BT ANTENNA RFDPA870940EMLB303
79 FLEXIBLE FLAT CABLE NCFC7-210812
80 P RIVET JB-407A-C
SC-LX901(S)MGP
(S) : Silver color model
<MGP> : 220-230V
CE(European) model
Q'TY PART NO. (SN) REMARKS
1 27124771A N
1 28210157 N
1 28210161B
4 27175481
1 29096191
8 AED7081-A
11 AEB7434-A
2 AMR7706-B
1 27191418A
1 ABK7061-A
1 AMR7704-A
1 ANB7646-A N
1 AXA7159-A
1 AMR7636-A N
2 AAA7071-C N
1 AAK8574-A N
1 28192487
1 AAK8459-A N
1 27213886A
1 27111642 N
1 28135324 N
1 AAD7807-A N
2 ABH7213-A
2 AEC7644-A
1 AAX8244-A
2 865190
1 2302173 !, N
1 252078GR !
1 252408 !
1 252070GR !
1 252069GR !
1 252069GR !
1 252070GR !
1 252070GR !
1 252069GR !
1 252069GR !
1 252070GR !
1 252070GR !
1 252070GR !
1 252073GR !, N
1 29361769
1 2047070712 N
1 2045351512 N
1 24150135 N
1 2050102 N
1 2050103 N
1 204321045 N
22 880052
