Pioneer SC-LX901B Service Manual page 129

<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
: NSP
REF. NO. PART NAME DESCRIPTION
[ Semi-conductors ]
[ Transformers, Coils ]
T4100 COIL 7G23G-200M-R
T4200 COIL 7G23G-200M-R
T4300 COIL 7G23G-200M-R
T4400 COIL 7G23G-200M-R
T4500 COIL 7G23G-200M-R
T4600 COIL 7G23G-200M-R
T4700 COIL 7G23G-200M-R
T4800 COIL 7G23G-200M-R
T4900 COIL 7G23G-200M-R
T6500 COIL 7G23G-200M-R
T6600 COIL 7G23G-200M-R
[ Capacitors ]
C4008 SMG C CE04W16V-100M(SMG)
C4010 SMG C CE04W16V-100M(SMG)
C4023 SMG C CE04W50V-10M(SMG)
C4024 SMG C CE04W16V-100M(SMG)
C4036 SMG C CE04W16V-100M(SMG)
C4052 SMG C CE04W16V-100M(SMG)
C4053 SMG C CE04W16V-100M(SMG)
C4057 ELECTROLYTIC CAPACITOR CE69W80V-2700M_LGU1K272
C4058 ELECTROLYTIC CAPACITOR CE69W80V-2700M_LGU1K272
C4059 ELECTROLYTIC CAPACITOR CE69W80V-2700M_LGU1K272
C4060 ELECTROLYTIC CAPACITOR CE69W80V-2700M_LGU1K272
C4061 ELECTROLYTIC CAPACITOR CE69W80V-2700M_LGU1K272
C4062 ELECTROLYTIC CAPACITOR CE69W80V-2700M_LGU1K272
C4063 ELECTROLYTIC CAPACITOR CE04W25V-82M(LXY)
C4065 ELECTROLYTIC CAPACITOR CE04W16V-56M(LXY)
C4066 ELECTROLYTIC CAPACITOR CE04W16V-56M(LXY)
C4069 ELECTROLYTIC CAPACITOR CE04W16V-56M(LXY)
C4070 ELECTROLYTIC CAPACITOR CE04W16V-56M(LXY)
C4071 SMG C CE04W16V-100M(SMG)
C4081 SMG C CE04W16V-100M(SMG)
C4083 MICA CAPACITOR DM15C201J5
C4084 MICA CAPACITOR DM15C201J5
C4108 ELECTROLYTIC CAPACITOR CE04W16V-470M(KY_H15)
C4116 ELECTROLYTIC CAPACITOR CE04W25V-82M(LXY)
C4130 ELECTROLYTIC CAPACITOR CE04W50V-18M(LXY)
C4134 ELECTROLYTIC CAPACITOR CE04W50V-18M(LXY)
C4136 ELECTROLYTIC CAPACITOR CE04W50V-18M(LXY)
C4149 ELECTROLYTIC CAPACITOR UKT1K561MHMAPDCV
C4150 ELECTROLYTIC CAPACITOR UKT1K561MHMAPDCV
C4166 SMG C CE04W16V-100M(SMG)
C4167 SMG C CE04W16V-100M(SMG)
C4171 SMG C CE04W50V-10M(SMG)
C4208 ELECTROLYTIC CAPACITOR CE04W16V-470M(KY_H15)
C4216 ELECTROLYTIC CAPACITOR CE04W25V-82M(LXY)
C4230 ELECTROLYTIC CAPACITOR CE04W50V-18M(LXY)
C4234 ELECTROLYTIC CAPACITOR CE04W50V-18M(LXY)
C4236 ELECTROLYTIC CAPACITOR CE04W50V-18M(LXY)
BACLD-2095-1E
Q'TY PART NO. (SN) REMARKS
1 231519
1 231519
1 231519
1 231519
1 231519
1 231519
1 231519
1 231519
1 231519
1 231519
1 231519
1 395041017T
1 395041017T
1 395081007T
1 395041017T
1 395041017T
1 395041017T
1 395041017T
1 3504536
1 3504536
1 3504536
1 3504536
1 3504536
1 3504536
1 3500245T
1 3500244T
1 3500244T
1 3500244T
1 3500244T
1 395041017T
1 395041017T
1 3600032
1 3600032
1 3500274
1 3500245T
1 3500246ST
1 3500246ST
1 3500246ST
1 3500254S
1 3500254S
1 395041017T
1 395041017T
1 395081007T
1 3500274
1 3500245T
1 3500246ST
1 3500246ST
1 3500246ST
