Pioneer SC-LX901B Service Manual page 141

[ Packing ]
900 PAD .
902 PAD .
904 CARTON LX901S(GP)
906 PACKING PAD/S .
908 LABEL (fwup-wo-dtsx)CNT_EU
[ Accessories ]
950 FM ANT AS Type W
952 MIC KHM0018-010010
954 WARRANTY CARD (Pi-EU2016)
956 ANTENNA COIL AM LOOP-ANTENNA
956 or ANTENNA COIL AM LOOP ANTENNA (S&O)
958 REMOTE CONTROL TRANSMITTER RC-927R
960 POWER SUPPLY CORD ADG7119-A
962 INSTRUCTION MANUAL LX901MGP(En,Fr,Es)
964 INSTRUCTION MANUAL LX901MGP(It,De,Ni)
966 INSTRUCTION MANUAL LX901MGP(Ru)
968 INSTRUCTION MANUAL Safety_Pio_16Hi_U9
970 INSTRUCTION SHEET (Google cast)
974 INSTRUCTION SHEET (FWupdate-Fireconnect)
<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
: NSP
REF. NO. PART NAME DESCRIPTION
[ Switches, Terminals, Wires ]
<Note>
1. Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
2. The ! mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
: NSP
REF. NO. PART NAME DESCRIPTION
[ Semi-conductors ]
[ Capacitors ]
[ Resistors ]
[ Switches, Terminals, Wires ]
1 AHA7502-B N
1 AHA7500-B N
1 29055654
1 AHA7499-A N
1 29393393
1 292191
1 245051
1 29365227A
1 232207
(1) 232216
1 24140927
1 253468VOL !
1 29402403 N
1 29402404 N
1 29402405 N
1 29402498 N
1 29355956
1 29355967 N
BAAF-2081-1B
Q'TY PART NO. (SN) REMARKS
BAAF-2083-1D
Q'TY PART NO. (SN) REMARKS
