Service Manual
CONTENTS
Rocker PTFE coated Chemical Resistant Vacuum Pump
Model No.
Rocker 400C
Rocker 410C
©Rocker Scientific Co., Ltd.
Version. ROC-202005-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 400C and is the answer not in the manual?

Questions and answers

Related Manuals for Rocker 400C

Summary of Contents for Rocker 400C

  • Page 1: Table Of Contents

    Service Manual Rocker PTFE coated Chemical Resistant Vacuum Pump Model No. Rocker 400C Rocker 410C CONTENTS 1. Instruction 2. Failure to start – Maintenance SOP 3. Poor / No Vacuum – Maintenance SOP 4. Most Common Problems 5. Explored Part List...

  • Page 2: Instruction

    4. Make sure to unplug the power cord before disassembling the pump. 5. Make sure to use the right tools for disassembly to avoid damage to parts.  Applicable Models: Rocker 400C Rocker 410C Tools Preparation: Screwdriver, Allen key, Gear puller, Lubricant, Sand paper...

  • Page 3: Failure To Start - Maintenance Sop

    Failure to start – Maintenance SOP...

  • Page 4: Poor / No Vacuum - Maintenance Sop

    Poor / No Vacuum - Maintenance SOP...

  • Page 5: Most Common Problems

    Capacitor specs & applicable models: Failure to start Condenser Model 110V 220V Rocker 400C 10uf/300V 4uf/450V Rocker 410C 10uf/300V 4uf/450V a) Check if the shaft can be rotated by hand. b) Bearing is stuck  replace with new part.
  • Page 6 a) Remove the cylinder head and check if the cylinder block have crack  Replace with a new cylinder block 4. Cylinder & cylinder block b) Check if the O-ring is damaged replace with new part. c) Check if the cylinder is deformed Replace with a new cylinder a) Check if the Diaphragm is damaged ...

  • Page 7: Explored Part List

    Exploded Part List Rocker 400C Index Description Quantity Index Description Quantity Screw Plug Rear cover Connecting Rod Set Cooling fan Vacuum gauge Rubber stand Drain valve Cylinder Block Hose connector (outlet) Sealing ring Rubber valve plate Cylinder head Diaphragm Handle...

  • Page 8: Rocker 410C

    Rocker 410C Index Description Quantity Index Description Quantity Screw Plug Rear cover Connecting Rod Set Cooling fan Vacuum gauge Rubber stand Drain valve Cylinder Block Hose connector (outlet) Sealing ring Rubber valve plate Cylinder head Diaphragm Handle Moisture trap (inlet)

  • Page 9: Service Video Links

    Service Video Links Model No. Subject Video Link Rocker 400C/410C Replacement of bearing https://drive.google.com/open?id=1ZEcRTGpHElo52eS4Nz7iHhKFLl0_ZmJa Replacement of condenser Rocker 400C/410C https://drive.google.com/open?id=1W9UuTjMXtNMUGgt2_rHx9QydOkFCbGCr and on/off switch...
