- Page 1 INSTRUCTION MANUAL Oil Free Vacuum Pump Model No. Rocker 300 / 300DC / 400 / 410 Rocker 800 / 801 / 810 / 811...
- Page 2 Important Notice This instrument is designed for laboratory usage only. Please read this manual carefully before installing and operating. The instrument shall not be modified in any way. Any modification will void the warranty and may result in potential hazard. We are not responsible for any injury or damage caused by any non-intended purposes and modifying the instrument without authorization.
- Page 3 If there is any problem, please keep the serial number along with packing case and contact your local distributor immediately for assistance. Main Part Diagram Rocker 300DC Rocker 300 Position Designation Position Designation...
- Page 4 Rocker 400 Rocker 410 5 8 4 5 8 4 Rocker 800 Rocker 810 Rocker 801 Rocker 811 Position Designation Position Designation Power Switch Vacuum Gauge Air Outlet (Muffler) Prote Filter Cartridge Handle Moisture Trap Air Inlet Vacuum Regulator...
- Page 5 Operation Operation ● A. Press Power Switch (1) to activate the pump after making sure all tubing are well connected. A cold trap or trap bottle is recommended to connect before pump while amount of moisture ● exists. B. To setup vacuum by adjusting the vacuum regulator (8). C.
- Page 6 How to reset the Prote protection device ● 1. Remove the moisture trap (7) and filter cartridge (6) by rotating clockwise. 2. Disassemble the filter cartridge (6) to ensure the buoy is not closed. 3. Reinstall all components, filter cartridge and moisture trap back. How to replace cartridge ●...
- Page 7 Rocker 810 repair kit 167811-62 Rocker 811 repair kit 167300-21 Hose barb, 1/8 PT, 5/16 in. for Rocker 300 / 300DC / 400 / 410 / 801 / 811 167300-20 Hose barb, 1/4 PT, 3/8 in. for Rocker 800 / 810 167200-38 Silicone Tube, Ø...
- Page 8 Rocker Scienti c Co., Ltd. Tel: +886-2-26033311 Fax: +886-2-26036622 E-mail:export@rocker.com.tw https://www.rocker.com.tw...
