- Page 1 Instruction Manual Rocker 300C / 400C / 410C PTFE Coated Chemical Resistant Vacuum Pump Please read this instruction manual before using this product.
- Page 2 * Warning: The PTFE-coated diaphragm and chamber can o er good resistance to a wide range of chemicals except strong acid and alkali. Unpacking When unpacking, notice if the pump is in good situation. If not, please contact the distributor or contact us by e-mail: export@rocker.com.tw immediately for assistance.
- Page 3 Rocker 300C Main Part Diagram Model Position Designation On/Off Switch Air Outlet Air Inlet Rocker 300C Vacuum Gauge Vacuum Regulator Moisture Trap...
- Page 4 Rocker 400C Main Part Diagram Model Position Designation On/Off Switch Air Outlet Air Inlet Rocker 400C Vacuum Gauge Vacuum Regulator Moisture Trap...
- Page 5 Rocker 410C Main Part Diagram Model Position Designation On/Off Switch Air Outlet Air Inlet Rocker 410C Vacuum Gauge Vacuum Regulator Moisture Trap...
- Page 6 Operation Operating procedure 1. Press on/off (1) button to activate the pump after making sure all tubing are well connected. 2. To setup vacuum by adjusting the regulator (5). * Warning: When pump is used for aqueous solution ltration, please ensure the liquid level of ask not exceed safety level.
- Page 7 Ordering Information 189300-11(22) Rocker 300C, PTFE Coated Chemical Resistant Vacuum Pump, AC110V,60Hz (AC 220V,50Hz) 189400-11(22) Rocker 400C, PTFE Coated Chemical Resistant Vacuum Pump, AC110V,60Hz (AC 220V,50Hz) 189410-11(22) Rocker 410C, PTFE Coated Chemical Resistant Vacuum Pump, AC110V,60Hz (AC 220V,50Hz) 189300-62 Rocker 300C Repair kit...
- Page 8 Rocker Scienti c Co., Ltd. Tel: +886-2-26033311 Fax: +886-2-26036622 E-mail:export@rocker.com.tw https://www.rocker.com.tw...
