Summary of Contents for Rocker 300
- Page 1 INSTRUCTION MANUAL Oil Free Vacuum Pump and Compressor Model No. Tech support Rocker 300 / 300DC / 400 / 410 Rocker 900 / 901 / 910 / 911 Rocker 430...
-
Page 3: Table Of Contents
Table Of Contents Important Notice Unpacking Main Part Diagram (1) Vacuum Pump (2) Vacuum Pump and Compressor Operation Maintenance Troubleshooting... -
Page 4: Important Notice
The instrument is not designed to start against applied vacuum / pressure. To prevent damage, verify that the inlet and outlet are at atmospheric pressure before each start. If necessary, the inlet (and outlet of Rocker 430) can be vented to atmosphere by partially unscrewing the regulator knob. -
Page 5: Unpacking
-Pump head: Aluminum alloy - Valve plates: SUS - Piston seal: PTFE complex * Warning: While Rocker 430 is operated as a compressor, please ensure a 20-min break while every 30-min working to prevent the instrument shutdown from overheating. 2. Unpacking Please check if the package is complete without any damage before unpacking. -
Page 6: Main Part Diagram
3. Main Part Diagram (1) Vacuum Pump Rocker 300 Rocker 300DC Position Designation Position Designation Power Switch Prote Filter Cartridge Air Outlet (Mu er) Moisture Trap Handle Vacuum Regulator Air Inlet Power Cord Vacuum Gauge * The reference point of vacuum gauges is atmospheric pressure. - Page 7 Vacuum Gauge Air Outlet (Mu er) Prote Filter Cartridge* Handle Moisture Trap Air Inlet Vacuum Regulator * Rocker 900 / 910 is equipped with only lter cartridge, no Prote protection device. 5 8 4 5 8 4 Rocker 901 Rocker 911...
-
Page 8: Vacuum Pump And Compressor
(2) Vacuum Pump and Compressor Rocker 430 Position Designation Position Designation Power Switch Moisture Trap Air Outlet (Pressure Side) Vacuum Regulator Handle Pressure Gauge Air Inlet (Vacuum Side) Filter Cartridge Vacuum Gauge Moisture Trap Prote Filter Cartridge Pressure Regulator (Drain Valve) -
Page 9: Operation
Failure to comply could result in serious damage to the pump and void the warranty. If it occurs, please contact the distributor immediately for service. (2) While Rocker 430 is operated as a compressor, please ensure a 20-min break while every 30-min working period to prevent the instrument shutdown from overheating. -
Page 10: Maintenance
5. Maintenance 1. Please remove the liquid in the moisture trap after every use and keep pumping the air for at least 2 minutes to withdraw the residual steam. 2. If the liquid in moisture trap is more than 70%, please stop the experiment immediately to empty the liquid. - Page 11 183100-01(02) Pilot 100, Vacuum Controller, AC100-240V adaptor, US plug (EU plug) 167300-37 Hoop Holder for Rocker 300 / 400 / 410 / 300C / 400C / 410C, applicable to apparatus w/ Max. diameter of 118 mm 189300-37 Hoop Holder for Rocker 300 / 400 / 410 / 300C / 400C / 410C, applicable to apparatus w/ Max.
- Page 12 Rocker Scienti c Co., Ltd. Tel: +886-2-26033311 Fax: +886-2-26036622 E-mail:export@rocker.com.tw https://www.rocker.com.tw...
