Soundcore Rave 3 Manual

At a Glance

Front & Back

1. Handle
2. Top Panel
3. Wireless Microphones (×2)
4. Back Panel

Top Panel

1. Wired Mic Volume Control: Adjust the volume of your wired microphone.
2. Reverb Control: Rotate clockwise / counterclockwise to increase / decrease the amount of reverb applied to your microphone or audio source.
3. Reverb Level Indication: Display the current reverb applied to your microphone or audio source.
4. Power Button: Power on or off the device.
5. Battery Indicator: Display the battery level of the device.
6. Bluetooth Button: Press to enter Bluetooth pairing mode.
7. AI Vocal Removal: Press to remove the original vocals from the song, leaving only the accompaniment. Press again to restore the vocals.
8. AuraCast Button: Press to enable AuraCast feature.
9. LightShow Button: Press to turn the light effect on or off.
10. BassUp Button: Press to enhance the low frequency of the audio source.
11. Play/Pause Button:
    • Press once to play / pause the audio source.
    • Press twice to skip to the next track.
    • Press three times to skip to the previous track.
12. Volume Up and Volume Down Buttons: Press to turn up or down the volume of audio source.

Back Panel

1. Gain (Guitar): Adjust gain of the connected guitar.
2. Guitar Volume Control: Rotate clockwise / counterclockwise to increase / decrease the volume of the connected guitar.
3. USB-C Charging Port: Plug in the provided C-C cable to charge the device.
4. Guitar / Microphone Socket (6.5mm): Connect to a guitar or wired microphone.
5. Input Switch Toggle: Switch to the connected guitar or microphone input.
6. AUX IN: Connect to an external audio device through a 3.5 mm audio cable (not supplied).

Charging

Charging Your Speaker

• Use a certified C-C cable and charger to prevent any damage.


	Flashing Red	Low Battery
	Flashing White	Being Charged
	Steady White	Fully Charged

Powering On/Off

	Press Once	Power On
	Press and Hold for 2 Seconds	Power Off

• This speaker will power off automatically after 20 minutes of no audio input.
• You can also set an auto-power-off time in the soundcore app.

Using Your Speaker

Bluetooth Mode
Press the Bluetooth button to enter Bluetooth pairing mode, then select "soundcore Rave 3" from your device's Bluetooth list to connect.

	Press	Enter Bluetooth Pairing Mode
	Flashing Blue	Bluetooth Pairing
	Steady Blue	Bluetooth Connected

• To re-enter Bluetooth pairing mode, press the Bluetooth button once.
• This speaker can only play music on one mobile device at a time. To play from another connected device, pause the device that's currently active first.
• Each time you power on your speaker, it will automatically connect to your last connected device if available within the Bluetooth range. If not, press the Bluetooth button to enter Bluetooth pairing mode.

TWS (True Wireless Stereo) Mode
Two identical soundcore speakers can pair with each other for stereo sound. Both speakers can play the same audio (one as the left channel and the other as the right channel).
With one speaker connected to a smartphone or tablet, press the AuraCast button simultaneously on both speakers to enter TWS pairing mode powered by AuraCast technology.
Upon successful pairing, you will hear a sound prompt. Then double press the AuraCast button on either speaker to assign the left and right audio channels.

	Press Once	Enter / Exit TWS Pairing Mode
	Steady White	TWS Pairing
	Steady White (Speaker 1)	TWS Connected
	Steady White (Speaker 2)

AuraCast
With one speaker connected to a smartphone, press the AuraCast button on up to 10 soundcore speakers with AuraCast function to synchronize audio and light.

	Press Once	Enter / Exit AuraCast Pairing Mode
	Steady White	AuraCast Pairing
	Steady White	AuraCast Connected

• When you enable or disable the AuraCast feature, you will hear a notification sound.

Using the Wireless Microphones

1. Unscrew the battery cover.
2. Install two AA batteries.

	Press Once	Power On
	Press and Hold for 2 Seconds	Power Off
	Press	Mic Volume Up / Down
	Press	Adjust Vocal Removal Level

• Once you power on the wireless microphones, they will automatically connect to the speaker.
• The AI VOCAL REMOVAL button on the speaker can remove the original vocal from a song with just one press. While the AI Vocal Removal button on the wireless microphone allows for adjustable vocal retention, ranging from 4% to 100%.
• Once the vocal removal level is set on the microphone, the speaker will remember this setting even after restarting. This ensures that when you activate the vocal removal feature on the speaker, the vocal removal effect will match the level set on the microphone.

Guitar / Wired Microphone Connection

Connect a microphone or guitar to the speaker through 6.5mm audio cables (not suppplied).

• After connecting a microphone or guitar to the speaker, make sure to set the toggle switch to the correct sound input.

LightShow

The LED lights change with the rhythm of the music.

	Press Once or Press Again	Turn Light On / Switch Light Effect
	Press and Hold for 2 Seconds	Turn Off

• You can also select your preferred light effect, or customize its pattern and brightness in the soundcore app.

soundcore App

Download the soundcore app to enhance your experience.

Product information: Check the product name and software version, or read the user manual.
Firmware update: You will be informed once a new version of firmware is detected when you connect the speaker with the app.
Battery status: Indicates the remaining battery level of your speaker.
Volume control: Adjust the volume level via the app without pressing the buttons on the speaker.
EQ settings: There are various preset EQ settings you can choose from in the app to optimize your experience while enjoying different music genres.

• soundcore Signature: Standard EQ mode optimized for well-balanced sound.
• Voice: Voices stand out more clearly from other ambient sounds.
• Treble Boost: High frequencies are enhanced.
• Balanced: No enhancement for high-frequency and low-frequency sounds.

Set auto-power-off time: Set an auto-power-off time. The speaker will automatically power off when the time is up.
Voice prompt: Mute or restore the voice prompt while powering on/off.

Reset

Press and hold the Bluetooth button and volume up button simultaneously for 8 seconds to reset the speaker.
