Soundcore Model Zero - Wireless Portable Home Speaker Manual

Safety Instructions

• Avoid dropping.
• Do not disassemble.
• Do not submerge in water.
• Avoid extreme temperatures.
• Do not use the device outdoors during thunderstorms.
• Use original or certified cables.
• Do not use any corrosive cleaner/oil to clean.

What's Included

The adapter vary by region.

At a Glance

1. BassUp button / BassUp indicator
2. Volume down control
3. Multi-function button
4. Volume up control
5. Bluetooth button / Bluetooth indicator
6. Power button
7. Power indicator
8. 3.5mm audio input port (AUX)
9. Power port
10. Charging indicator

Using Your Soundcore Model Zero

Turn On / Off

Bluetooth mode

	Enter Bluetooth Pairing Mode
	Flashing Blue	Bluetooth Pairing Mode
	Solid Blue	Connected to a device
	Enter True Wireless Stereo Group Mode / Disconnect True Wireless Stereo
	Double Flashing White	True Wireless Stereo Group Mode
	Solid White	Connected to True Wireless Stereo

With True Wireless Stereo technology, you can pair your Soundcore Model Zero with another Soundcore Model Zero to explore the best sound effects with left and right sound channels separated on both speakers.

	Play / Pause
	Play Next Song
	Press to turn Bass Up on and off
	Answer Call / End Call / Switch between a call on hold and an active call
	Reject Call
	End current call and answer incoming call / End current call and switch to call on hold
	Switch audio source between Speaker and Phone
	Put current call on hold and answer incoming call
	Activate Siri / Other Voice Control Software
	Volume Up / Down
	Solid White (Bluetooth indicator)	On a Call
	Flashing Blue (Bluetooth indicator)	Incoming Call

When turned on, Soundcore Model Zero will automatically connect to the last connected device if available. If not, press the Bluetooth pairing button to activate pairing mode.
To pair a different device, press the Bluetooth button to re-enter pairing mode. Then repeat the pairing steps.
Having connection problems? Remove Soundcore Model Zero from your device's Bluetooth history and ensure it's less than 3 feet away. Then try pairing again. To get the best sound quality, make sure there is a clear line of sight between the connected device and your speaker.

Multi-point play

1. Connect the first mobile phone to your Soundcore Model Zero, press the Bluetooth button once on Soundcore Model Zero after the connection is successful.
2. Press the Bluetooth button on Soundcore Model Zero twice to enter Bluetooth pairing mode.
3. Connect the second mobile phone to Soundcore Model Zero. Once the second mobile phone is connected to Soundcore Model Zero, turn on the Bluetooth of the first mobile phone, then find Soundcore Model Zero in your pairing list. Click it for connection, make sure the connection is successful.

Note: Soundcore Model Zero can only play the music on one mobile phone at a time.

AUX-In mode

*SoundLine AUX cable sold separately.

Plugging in an audio cable will automatically switch to AUX mode. When using AUX mode, control audio playback via the connected device.

Charging your Soundcore Model Zero

	Slow Flashing Red (Power indicator)	Low Battery
	Solid Red (Power indicator)	Charging
Off		Fully Charged

Use the included adapter to charge your Soundcore Model Zero and make sure it is fully charged before its first use.
Disconnect your speaker from the charger when fully charged. Do not charge your speaker for extended periods.
When not in use, store your speaker in a cool place.

Specifications

Specifications are subject to change without notice.

• Input: 15 V 3A
• Audio output: 15 W x 2 + 15 W x 2
• Battery capacity: max. 6700 mAh
• Charging time: 3.0 hours
• Play time (varies by volume level and music content): 10 hours
• Size: 256 x 128 x 240mm
• Weight (without packaging): 3.9 kg / 138 oz
• Bluetooth version: V5.0
• Bluetooth range: 20 m / 66 ft

Anker Innovations Limited
Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong

Product Number Z5180
Bluetooth Speaker / Soundcore Model Zero

For FAQs and more information, please visit: https://www.soundcore.com/
Please note that your rights under applicable law governing the sale of consumer goods remain unaffected by the warranties given in this Limited Warranty.

Model No.: Z5180
V01
