Soundcore Wakey Manual

Safety Instructions

• Avoid dropping.
• Do not disassemble.
• Do not submerge in water.
• This product is exclusively for indoor use only.
• The product should not be exposed to dripping or splashing water.
• Avoid extreme temperatures.
• Do not use the device outdoors during thunderstorms.
• Use original or certified cables.
• Do not use any corrosive cleaner/oil to clean.

What's Included

At a Glance

1. Light Sensor
2. FM Radio Button
3. Volume - Button
4. Multi-function Button
5. Volume + Button
6. Bluetooth Button / Bluetooth Indicator
7. Clock Button
8. Wireless Charging Status LED Indicator
9. Wireless Charging area
10. DC IN Port
11. PowerIQ USB Port
12. 3.5mm Audio Input Port
13. FM Antenna Port

Using Your Soundcore Wakey

Turn On / Off

(Plug in the power adapter and Wakey switches on automatically)

Note: Download Soundcore App before you start using Soundcore Wakey. The time will automatically update when Soundcore Wakey is added to app list.

Bluetooth Mode

	Flashing White	Bluetooth Pairing Mode
	Solid White	Connected to a device

ㅤ

	Play / Pause
	Play Next Song
	Answer Call / End Call
	Reject Call / Switch between a call on hold and an active call
	End current call and answer incoming call / End current call and switch to call on hold
	Switch audio source between speaker and phone
	Put current call on hold and answer incoming call
	Volume Up / Down

Screen display light

	Solid White	On a Call
	Flashing White	Incoming Call

When turned on, Soundcore Wakey will automatically connect to the last connected device if available. If not, press the Bluetooth pairing button to activate pairing mode.
To pair a different device, press and hold the Bluetooth button for 2 seconds to re-enter pairing mode. Then repeat the pairing steps.
Having connection problems? Remove Soundcore Wakey from your device's Bluetooth history and ensure it's less than 3 feet away. Then try pairing again. To get the best sound quality, make sure there is a clear line of sight between the connected device and your speaker.

AUX-In mode

*SoundLine AUX cable sold separately.

Soundcore Wakey will play music via the Bluetooth connection over the AUX connection when both are connected.
When using AUX mode, control audio playback via the connected device.

FM Radio

Set the FM radio on the Soundcore App. (FM Radio needs to be used with the provided antenna cable)

	Solid White	FM radio turned on
OFF		FM radio turned off

	Change to next FM channel (When FM radio is on)
	Change to previous FM channel (When FM radio is on)

Note: You can store your favorite channels in the FM channel folder on the Soundcore app. If there are no channels saved in the FM channel folder, Wakey will automatically switch to previous or next available channel.

Alarm Preset

Set the preset alarm on the Soundcore App. You can set up alarms on the Soundcore App. When alarm activates on, press any button to enter snooze mode, press and hold any button for a few seconds to cancel current alarm clock.

	Solid White	Alarm is on
OFF		Alarm is off

Superior Sleep

This function offers a collection of sounds from nature for aiding sleep. Select your desired sounds on the Soundcore App. User can set sleep countdown timer to control the duration of playtime.

1. Add Soundcore Wakey to the Soundcore App list.
2. Enter Superior Sleep page.
3. Follow onscreen instructions to set the "Sleep timer" and "Ambient sound".

Charging Your Devices

You can charge your mobile phone wirelessly with Soundcore Wakey. Note: Wireless charging requires compatible smart devices.

	Solid Blue	Charging
	Flashing Blue	Misplacement (In charging area)

You can also charge your other devices via the PowerIQ USB ports on the rear of Soundcore Wakey.

When not in use, store your speaker in a cool place.

Specifications

Specifications are subject to change without notice.

• Input: 15 V 3 A
• Wireless charge out: 10W (for Samsung), 7.5W (for iPhone)
• Charge out: 5 V 2 A
• Audio output: 5 W × 2
• Size: 82 x 92 x 200 mm
• Weight (without packaging): 572 g / 20 oz
• Bluetooth version: V5.0
• Bluetooth range: 20 m / 66 ft

Soundcore App

• Full FM features
• Full Alarm features
• Superb sleep
• Device settings
• More

Apple and the Apple logo are trademarks of Apple Inc.

Google Play and the Google Play logo are trademarks of Google Inc.

Model No.: A3300
51005001390 V03
