Summary of Contents for d&b audiotechnik CCL-SUB

  • Page 1 CCL-SUB Manual 1.1 en...
  • Page 2: General Information

    Notes on document version Version 1.1: Preliminary edition. General information CCL-SUB Manual - preliminary - Version: 1.1 en, 02/2025, D2781.EN .01 Copyright © 2025 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference.
  • Page 3: Table Of Contents

    CCL-SUB loudspeaker............5 2.1  Intended use................5 2.2  Connections................6 2.3  Operation..................6 2.3.1  Controller settings..............6 2.4  Technical specifications.............. 7 Manufacturer's declarations........... 8 3.1  Conformity of loudspeakers............8 3.2  WEEE Declaration (Disposal)............ 8 - preliminary - d&b CCL-SUB Manual 1.1 en...
  • Page 4: Safety Precautions

    Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient. - preliminary - d&b CCL-SUB Manual 1.1 en...
  • Page 5: Ccl-Sub Loudspeaker

    Applicable d&b amplifiers: D40|D80|D90 Product description The CCL-SUB is a compact high performance cardioid subwoofer. It houses two long excursion neodymium drivers in an integrated cardioid setup: a 15" driver in a bass-reflex design facing to the front and a 10" driver in a 2-chamber bandpass design radiating to the rear.
  • Page 6: Connections

    Coupling function may still be used for additional corrections, for example of room properties or coupling effects between main hangs and outfills. Frequency response correction of the Coupling function for low and low-mid fequency level* *schematic diagram - preliminary - d&b CCL-SUB Manual 1.1 en...
  • Page 7: Technical Specifications

    1 x 15" driver front/1 x 10" driver rear Connections 1 x NLT4 F/M Pin assignment 2+/2– Optional front splay 0° or 2.5° Weight 44.5 kg (98 lb) CCL-SUB frequency response, Standard and 100 modes CCL-SUB cabinet dimensions in mm [inch] - preliminary - d&b CCL-SUB Manual 1.1 en...
  • Page 8: Manufacturer's Declarations

      3.1  Conformity of loudspeakers This declaration applies to: ▪ d&b Z0884 CCL-SUB loudspeaker by d&b audiotechnik GmbH & Co. KG. All product variants are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications.
  • Page 9 www.dbaudio.com...
