3.2.3 Operating elements at the microscope ............15 3.2.4 Rear view of the ATMOS i View 21 control device .......... 16 3.2.5 Rear view of the control device of the ATMOS i View 31 (not with built-in HD camera) ................16 3.2.6...
Page 3
4.14 Microscope zooming and object field sizes ............27 4.15 Measuring scale....................... 27 4.16 Image and video recording ..................28 4.16.1 Setting the light mode of the built-in HD camera .......... 28 4.17 Endoscope adapter ....................28 4.18 Adapter for external camera ................. 29 Sterilization .....................30 General information on cleaning and disinfection ..........
This manual is used to train and instruct operating personnel and is also intended as a reference manual. This document may be reprinted, either in part or in whole, only with the written permission of ATMOS. These operating instructions must always be kept available near the product.
1.2 Explanation of pictograms and symbols In the operating instructions DANGER Warning of a danger resulting directly in fatal or serious injury. Observe the necessary measures. WARNING Warning of a danger of fatal or serious injuries. Observe the necessary measures. CAUTION Warning of a danger of minor injuries.
Page 6
Weight setting for carrier arm No domestic waste Alternating current Fuse Do not reuse Do not look directly into the light source of the ATMOS i View UL listing test mark Store in a dry place Temperature limit Humidity limitation...
Page 8
ATMOS i View 31 control panel buttons Light on/off (independent of automatic light control) Video recording (start/stop) Change between stroboscope and permanent light With built-in HD camera: camera light mode setting Freeze frame Control device ATMOS i View 21 Output for the power supply of the electronics in the microscope...
Due to the therapeutic purposes. variety of options the ATMOS i View has to offer, the user is in a position to configure a microscope adapted to suit his or her requirements. The following functions can be...
IEC connector of the supply module! • The ATMOS i View is a device of protection class I, designed in line with IEC 60601-1-1/ EN60601-1. To avoid the risk of electrical shock, this device may be connected only to a mains supply with a properly installed earth conductor.
• Pull the power plug immediately if you notice any fumes, sparks or unusual noises at your device. • After lengthy use of the ATMOS i View with an ear speculum, the patient may feel dizzy! • With every light source, warming of tissue due to absorption may occur. Please make sure to reduce the duration of use to a minimum, switch off the light source when not in use and check the heat development of the light source if necessary.
3 Setting up the device and putting it into service 3.1 Device overview Description ATMOS i View 21 ATMOS i View 31 Examination microscope with Examination microscope with built-in, fanless, high transmis- built-in, fanless, high transmis- sion, high-performance LED sion, high-performance LED...
See chapter “9 Technical data” on page 38. Please observe that only PCs and monitors with IEC 606010-1/EN 60601-1 approval are allowed to be connected to the video output of the ATMOS i View supply module! 3.2.1 Connecting to the mains supply...
Adapter for SONY digital camera (optional) T handle (optional) Endoscope adapter (optional) Control panel (optional) 3.2.3 Operating elements at the microscope Light on/off (independent of auto- matic light control) Freeze Video recording With built-in HD camera: camera (start/stop) light mode setting frame Setting up the device and putting it into service...
Connection for potential equalization line in accordance with IEC 60417-5021 IEC power plug with fuse inlay for connection to the mains supply 3.2.5 Rear view of the control device of the ATMOS i View 31 (not with built-in HD camera) ...
• ATMOS C 11 Systema Integration into ATMOS S 61 Servant WARNING Please observe that a safe combination of the ATMOS i View can be guaranteed only with the aforementioned units. Setting up the device and putting it into service...
• The ceiling mount is suitable for accommodating the ATMOS i View and a monitor of up to 10.5 kg. Only the supply module of the ATMOS i View and the monitor may be connected to the power supply outlets of the ceiling mount.
Operate the brake of the height adjustment carefully. 3. To activate the ATMOS i View, please actuate the on/off switch on the front side of the control device. 3.5 Operating requirements ...
Page 20
Persons with glasses – People with defective vision and glasses: 1. Keep your glasses on and push the eyepiece lenses in the direction of the lens tube until you hear them engage. 2. Set the dioptre scale to zero. Persons with glasses – People with defective vision without glasses (refraction values known): 1.
4 Operation 4.1 Microscope suspension • The microscope head is connected laterally to the microscope arm by means of the corresponding suspension. • All connection cables run through the sus- pension – therefore no disturbing cables are visible from the outside (with the exception of the attachment of the option to an ex- ternal camera and direct connection to a monitor).
4.3 Handles When purchasing the ATMOS i View, you can choose between two versions of han- dles. 4.3.1 T handle 4.3.2 Lateral double handle The position of the lateral double hand grip can be gradually adjusted by simulta- neously pulling it laterally and turning the handle.
4.5 Adjusting the eyepiece lenses Persons without glasses: • The eyepiece lenses remain in their initial position. Initial position = eye guidance of the eyepiece lenses pulled out. • Make sure the zero of the dioptre scale matches the index on the eye- piece lenses.
4.6 Exchanging the objective lenses The designated thread on the microscope head allows for easy exchange and fixa- tion of the different objective lenses. Due to the integrated threads, the objec- tive lenses can be loosened by turning them anti-clockwise and fastened by turning them clockwise.
4.9 Setting the fivefold magnification changer The fivefold magnification changer from ATMOS allows the magnification to be changed between 0.5x and 2.0x. • Select the desired zoom factor on one of the lateral locking screws. • Make sure you hear the chosen zoom factor engage in the respective groove.
4.11 Exchanging the lens tube The tube's focal distance of 160 mm allows comfortable and fatigue-proof observation of the object with both eyes. Working is made easier due to the exceptionally large exit pupil and an increased stereo base of 24 mm. Please hold the tube tight with one hand while undoing the screw.
4.14 Microscope zooming and object field sizes Objective lens f Factor display on zoom unit Eyepiece in mm is lenses with equivalent 1.0* tube to the ap- proximate f = 160 mm working Total zoom / visual field Ø in mm distance 4 / 41 5.6 / 30 8 / 21 11.2 / 14 16 / 11...
4.16 Image and video recording Built-in camera: Optionally, an HD camera can be integrated in the ATMOS i View 31. External video sources: External video sourc- STROBO STROBO es can be controlled with the control panel buttons if they are connected to the “Freeze”...
4.18 Adapter for external camera You can connect a SONY digital camera with e-mount connection to the ATMOS i View by means of the specially developed adapter. This camera enables you to take and archive HD-resolution pictures. The adapter is covered with a cover cap when supplied.
If fluid enters the ATMOS i View, the device must be sent in for inspection and may not be put back into operation until it has been checked by a person authorized by ATMOS.
The endoscope mounting is protected against dirt and humidity by an end glass cover. This glass cover must also be cleaned and looked after like the other optical surfaces of the ATMOS i View. This can be done by following the instructions for cleaning optical surfaces.
5.4 Recommended surface disinfectants Changes in colour may occur if disinfectants containing aldehyde and amine are used on the same object. Do not use any • Disinfectants that contain organic or inorganic acids or bases because they could cause corrosion damage. •...
• Conduct a repeat test of the electrical safety in accordance with IEC 62353 at least every 24 months. ATMOS recommend conducting an inspection within this frame- work in accordance with the manufacturer’s specifications.
6.3 Exchanging spare parts Brake, star grip, copper insert REF 538.2013.0 Brake, star grip, POM REF 538.2015.0 Microscope arm Microscope arm until 2014-12 since 2014-12 Fuse T 3.15 A/H 250 V: REF 008.0751.0 The system must be disconnected from the mains supply before exchanging the main fuse.
2–3 hours. ATMOS i View is overheated Please notify ATMOS’s service department No function whatsoever ATMOS i View is switched Switch on the ATMOS i View off. at the connection box Fivefold magnification Notify ATMOS’s service changer is defective department.
Measuring scale (300 mm) 606.1200.0 H.A.S.I. filter 605.2200.0 T handle 538.1500.0 Double handle 538.1600.0 ENT microscope arm 538.2000.0 Cover cap set 538.3800.0 8.2 Accessories General Microscope add-on kit (ATMOS S 61 CORIAN® integral) 532.0880.0 Stand (S 61 Servant) 534.0119.0 36 Options and accessories...
Page 37
Slanted microscope column 534.0170.0 Microscope add-on kit (ATMOS C 21 / C 31, single cabinet) 506.7040.0 Microscope add-on kit (ATMOS C 21 / C 31, double cabinet) 506.7040.1 Microscope column (ATMOS C 21/31) 506.7826.0 Stand (ATMOS C 11) 541.2300.0 Mobile stand ENT 538.2100.0...
IP X0 ID no. (REF) 538.0000.0 ATMOS i View 21 539.0000.0 ATMOS i View 31 538.9000.0 ATMOS i View 21 PRO 539.9000.0 ATMOS i View 31 PRO 605.0000.0 ATMOS i View 21 COLPO 606.0000.0 ATMOS i View 31 COLPO Issue of technical data: June 2021...
Register), this type of device is excluded from the ElektroG regulations. To guarantee proper disposal of your old device, please either pass on your old device to your special- ized dealer or send it directly to ATMOS MedizinTechnik for professional disposal. The device surface must be disinfected before disposal or transport.
• Within the vicinity of HF surgical devices and in settings outside of an HF-shielded room of a magnetic resonance imaging system. • The customer or user of the ATMOS i View 21/31 must ensure that the device is operated in a prescribed environment.
