ROP-63 / ROP-63H
Manual Call Points
Installation and Maintenance Manual
IK-E328-001-GB
Edition 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ROP-63 and is the answer not in the manual?

Questions and answers

Summary of Contents for Polon-Alfa ROP-63

  • Page 1 ROP-63 / ROP-63H Manual Call Points Installation and Maintenance Manual IK-E328-001-GB Edition 4...
  • Page 2 IK-E328-001-GB, Edition 4, 11.2024 Manual call points ROP-63, ROP-63H, which are the subject of this IMM, meet the essential requirements of the following regulations of the European Parliament and of the Council (EU) and European Union directives: CPR CPR/305/2011 Regulation (EU) of the European Parliament and of the Council of 9 March 2011 laying down harmonised conditions for the marketing of construction products and repealing Council Directive 89/106/EEC;...
  • Page 3: Table Of Contents

    Figure 6.3.1 Manual call point detection line wiring diagram ..............8 Figure 6.3.2 How to open an call point ……………………………………………………………………………………………………9 Figure 6.3.3 Manual call point when opened …………………………………………………………………………………………10 Figure 6.4.1 Glass cover spring mounting ………………………………………………………………………………………………10 Figure 6.4.2 Glass to body assembly ………………………………………………………………………………………………………11 __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 4: Purpose

    IK-E328-001-GB, Edition 4, 11.2024 1. PURPOSE The ROP-63 and ROP-63H manual call points operate in conventional detection lines and are designed to transfer information about noticed fire by their manual actuation of the device. The ROP-63 in the standard version is designed for an indoor installation.
  • Page 5: Design Description

    The colour of the arrows in the call point control field changes from black to yellow, and the information about pressing the button is transmitted to the fire alarm control panel. __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 6 (the warning device will not be put into the alarm state), the glass should be pressed against the call point and by inserting the key from below as far as it will go, it should be blocked. __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 7: Installation

    Figure 6.1.1 Dimensions and mounting holes of the call point Figure 6.1.2 Dimensions and mounting holes of the RM-60-R masking frame Due to the considerable impact force required for starting, drywall call points should not be installed without additional reinforcement. __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 8: Wire Arrangement

    „+” and „-” Termination resistor. The value of the resistor is specified in the IMM of the control panel. Figure 6.3.1 Manual call point detection line wiring diagram __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 9 A clearance of at least 100 mm from walls or other equipment must be ensured on both sides and underneath the call point to ensure that keys are accessible. How to open the call point Figure 6.3.2 __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 10: Plastic Cover Replacement

    Figure 6.. Set of 3 pcs. of spare glass has the designation SZ-60. Figure 6.4.1 Glass cover spring mounting Insert the glass into the guides of the cover and hook the spring onto the lug in the cover as shown Figure __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 11 IK-E328-001-GB, Edition 4, 11.2024 Figure 6.4.2 Glass to body assembly __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 12: Operation And Maintenance

    Devices in factory packaging must be transported in confined spaces by normal means of land or sea transport. The equipment should be protected against violent shocks and ambient temperatures below - 40 °C and above +70 °C. __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
  • Page 13 IK-E328-001-GB, Edition 4, 11.2024 __________________________________________________________________________________ ROP-63 AND ROP-63H MANUAL CALL POINTS...
