IK-E356-001-GB, Edition 3, 03.2023
1
MICROPROCESSOR BASED
ADDRESSABLE CONTROL
AND MONITORING ELEMENT
EKS-6222P
POLON 3000 / POLON 6000 INTERACTIVE FIRE DETECTION AND ALARM SYSTEM
_________________________________________________________________________________
INSTALLATION AND MAINTENANCE MANUAL
IK-E356-001-GB
Edition III
_________________________________________________________________________________
EKS-6222P Control and Monitoring Element
Advertisement
Table of Contents
Related Manuals for Polon-Alfa EKS-6222P
Summary of Contents for Polon-Alfa EKS-6222P
- Page 1 IK-E356-001-GB, Edition 3, 03.2023 MICROPROCESSOR BASED ADDRESSABLE CONTROL AND MONITORING ELEMENT EKS-6222P POLON 3000 / POLON 6000 INTERACTIVE FIRE DETECTION AND ALARM SYSTEM _________________________________________________________________________________ INSTALLATION AND MAINTENANCE MANUAL IK-E356-001-GB Edition III _________________________________________________________________________________ EKS-6222P Control and Monitoring Element...
- Page 2 IK-E356-001-GB, Edition 3, 03.2023 The EKS-6222P monitoring and controlling element covered by the present manual complies with the requirements of the following European Union Directives: Regulation (EU) No 305/2011 of the European Parliament and of the Council of 9 March 2011 laying down harmonised conditions for the marketing of construction products and repealing Council Directive 89/106/EWG;...
-
Page 3: Table Of Contents
Storage ..............................16 9.2. Transport ............................. 16 List of Drawings Graph. 3-1 EKS-6222P dimensions ......................6G Graph. 6-1 How to press the START button ................... 12 Graph. 7-1 EKS-6222P Sample connection diagram ................14 _________________________________________________________________________________ EKS-6222P Control and Monitoring Element... -
Page 4: Purpose
(6÷220) VDC or 230 VAC. The outputs of the EKS-6222P element enable the connection of devices with a current consumption not exceeding 12 A at 230 VAC (starting current max 100 A at max 100 ms or max 250 A at max 50 ms at 230 VAC). -
Page 5: Technical Specifications
From -40 °C up to +70 °C Climate category 40/070/04 Admissible relative humidity Up to 95 % at 40 °C Insulation electrical strength 1500 V IP Rate IP 66 Material and frame colour polycarbonate (PC), grey _________________________________________________________________________________ EKS-6222P Control and Monitoring Element... -
Page 6: Design Description
IK-E356-001-GB, Edition 3, 03.2023 Design description The EKS-6222P control and monitoring device is made of a printed circuit board with electronic elements and a set of connectors all placed in a single housing. Wall mounting holes are located in the corners of the frame. Cable entries are in the bottom of the housing. -
Page 7: Principles Of Operation
IK-E356-001-GB, Edition 3, 03.2023 Principles of operation Communication between the POLON 6000 or POLON 3000 control panels and the EKS-6222P control and monitoring element is via an addressable two-wire detection line. A unique, fully digital communication protocol allows transfer of any information from the control panel to the element and from the element to the control panel. - Page 8 3 V. The same rules apply to IN HV inputs. If the IN HV outputs or inputs are not used, the position of corresponding jumpers is not relevant. ___________________________________________________________________________________ EKS-6222P Control and Monitoring Element...
-
Page 9: Operating Modes Of The Control Element
- YES (not triggered, triggered), - NO (without change), d) continuity monitoring of the cable connected to the control output (yes, no), e) group number - (0, 65535), f) number of cycles (0 ÷ 255). _________________________________________________________________________________ EKS-6222P Control and Monitoring Element... - Page 10 Break time – T T ow Triggering mode Definite Cyclic Trigger delay time - T Trigger time – T Break time – T Number of cycles – L L c = 3 T ow ___________________________________________________________________________________ EKS-6222P Control and Monitoring Element...
-
Page 11: Operating Conditions
IK-E356-001-GB, Edition 3, 03.2023 Operating conditions Reliable operation of EKS-6222P control element depends on proper operating conditions, correct installation and regular periodic inspections. The inspection is carried out in order to determine the proper operation of the element as well as its proper cooperation with the control panel. The inspection should be carried out at least every 6 months by a qualified person who is familiar with the element operation to such extent that its operation irregularities can be detected. -
Page 12: Graph. 6-1 How To Press The Start Button
IK-E356-001-GB, Edition 3, 03.2023 Figure 6.1 TEST button access/pressing method ___________________________________________________________________________________ EKS-6222P Control and Monitoring Element... -
Page 13: Installation Of Control Elements
258 (available for purchase at POLON-ALFA). Connect the cables as described at the connectors. There is a sticker on the enclosure cover that shows the functions of EKS-6222P terminals, depending on the element type, as shown in the drawing: Figure 7. Connect the shields of detection line cables to the fields marked as SHLD. -
Page 14: Graph. 7-1 Eks-6222P Sample Connection Diagram
Supply 642 VDC - R3 2 kΩ 750 Ω IN2+ IN2- COM2 Power Supply OFF2 Controlled 4,3 kΩ 230 VAC Device Controlled device (active X or Y state) Figure 7.1 EKS-6222P Sample connection diagram ___________________________________________________________________________________ EKS-6222P Control and Monitoring Element... -
Page 15: Safety Conditions
Maintenance and periodic inspections must be carried out by personnel that is authorised or trained by POLON-ALFA. All repairs must be carried out by the manufacturer. POLON-ALFA is not responsible for the operated equipment maintained and repaired by unauthorised personnel. 8.2. Work at height Work at height related to the installation of control elements must be carried out with special care using equipment and tools in sound condition. -
Page 16: Storage And Transport
Storage and Transport 9.1. Storage EKS-6222P control and monitoring element should be stored in closed rooms, with no corrosive fumes or gases, at the temperature range from 0°C to +40 °C, with relative humidity not exceeding 80 % at the temperature of +35 °C. - Page 17 IK-E356-001-GB, Edition 3, 03.2023 _________________________________________________________________________________ EKS-6222P Control and Monitoring Element...
