Operation and Maintenance Documentation
SONNIGER Polska Sp. z o.o. Sp.K.
ul. Śląska 35/37, 81-310 Gdynia, Poland, infolinia 801 055 155, tel. + 48 58 785 34 80, www.sonniger.com
Sąd Rejonowy Gdańsk-Północ, VIII Wydział Gospodarczy Krajowego Rejestru Sądowego, KRS 0000504509,
NIP 586 227 35 14,Regon 22154369 kapitał zakładowy: 1.655.000 PLN
Advertisement
Table of Contents
Related Manuals for Sonniger GUARD 100W
Summary of Contents for Sonniger GUARD 100W
- Page 1 Operation and Maintenance Documentation SONNIGER Polska Sp. z o.o. Sp.K. ul. Śląska 35/37, 81-310 Gdynia, Poland, infolinia 801 055 155, tel. + 48 58 785 34 80, www.sonniger.com Sąd Rejonowy Gdańsk-Północ, VIII Wydział Gospodarczy Krajowego Rejestru Sądowego, KRS 0000504509, NIP 586 227 35 14,Regon 22154369 kapitał zakładowy: 1.655.000 PLN...
-
Page 2: Purpose Of The Device
The GUARD air curtains are designed to protect against heat losses in buildings of medium and high capacity and with a required mounting height is of 3,5m such as the followings: supermarkets, large retail space, car showrooms and service stations, sports and show halls, exhibition surfaces BASIC TECHNICAL PARAMETERS www.sonniger.com... - Page 3 Operation and Maintenance Documentation of GUARD air curtains 3. HEAT OUTPUT RANGES GUARD 100-150-200 W Air curtains with water heater Max temperature of heating medium 130° C GUARD 100-150-200 E Air curtains with electric heater www.sonniger.com...
- Page 4 Pay special attention when working with electrical elements of the device. 5. ASSEMBLY Before mounting the unit, take into consideration the followings: accessibility/easy access for any servicing and maintenance works access to water and electrical installation possibility to mount the curtain directly at the gate entrance www.sonniger.com...
- Page 5 Pay special attention to proper leveling of the device. If the device is not placed horizontally or vertically, it may result Montaż poziomy: in damaging the fan and consequently malfunctioning the device. To sustain proper functioning of the device keep a safe distance– 200mm from its sides and 200mm from its backside (from the fan) www.sonniger.com...
- Page 6 2 point. place the front cover of the GUARD curtain back (similarly to number 1 point) www.sonniger.com...
-
Page 7: Control Panel
Once the required temperature set on the thermostat (SK1) is achieved, the control panel switches off the electric heaters. SA1 – control panel switch SA2 - speed switch SA3 – heat output switch SK1 – temperature regulation R1 – 120 k resistor XT1, XT2 – connecting clamps www.sonniger.com... - Page 8 The diagram of GUARD 100-150-200 C installation (curtain without heater) M1 – curtain’s motor R1, R2 – resistor C1 – condenser/capacitor XT1, XT2 – connecting clamps SA1 – network switch SA2 – fan’s speed switch SQ1 – door switch (optional) www.sonniger.com...
- Page 9 R1 – resistor SK1 – safety thermostat SK2 –thermostat regulating switching fans on/off XT1, XT2 – connecting clamps SA1 – network switch SA2 – fan’s speed switch SA3 – heat output switch SK3 – thermo regulator SQ1 – door switch (optional) www.sonniger.com...
- Page 10 1025 127,5 43,5 34,5 62,5 GUARD 150 W 1455 1385 1193 43,5 34,5 62,5 GUARD 200 W 1905 1835 1643 43,5 34,5 62,5 dimension mm Model GUARD 100 W 55,5 GUARD 150 W 30,5 GUARD 200 W 52,5 31,5 www.sonniger.com...
- Page 11 Operation and Maintenance Documentation of GUARD air curtains GUARD 100-150-200 E, GUARD 100-150-200 C dimension mm Model GUARD 100 E/C 1135 1065 147,5 44,5 35,5 62,5 GUARD 150 E/C 1500 1430 1193 148,5 44,5 35,5 62,5 GUARD 200 E/C 1950 1880 1643 148,5 44,5 35,5 62,5 www.sonniger.com...
-
Page 12: Operation And Maintenance
– in case of any problems contact the installer of the device or the SONNIGER Authorized Service immediately. 10. TROUBLESHOOTING AND TECHNICAL PROBLEMS Possible problems and solutions are shown below. To eliminate a problem encountered contact the SONNIGER Authorized Service. Fault, symptoms... -
Page 13: Guarantee Terms And Conditions
§3. SONNIGER Poland is not liable to: Current maintenance works, inspections following from Operation and Maintenance Documentation and device programming. - Page 14 The Claimant is obliged to give a written confirmation of the service provided. Sonniger Poland is entitled to refuse the warranty service if Sonniger Poland has not received full payment for the product complained about under the Guarantee or any previous servicing activities.
-
Page 15: Guarantee Card
Details of installation company: :………………………………………………………………... Person activating the device Name of company:…………………………………………………………………………………………. …………………………………………………………………………………………………………….…. Address:…………………………………………………………………………………………………….. Telephone:…………………………………………………………………………………………………… Signature of a person who has started the device:……………………………………………………… Installation works, check-ups/inspections, repairs: Date The scope of installation works, inspections, repairs Signature and installation company stamp www.sonniger.com...
