- Page 1 Operation and Maintenance Documentation SONNIGER Polska Sp. z o.o. Sp.K. ul. Śląska 35/37, 81-310 Gdynia, Poland, infolinia 801 055 155, tel. + 48 58 785 34 80, www.sonniger.com Sąd Rejonowy Gdańsk-Północ, VIII Wydział Gospodarczy Krajowego Rejestru Sądowego, KRS 0000504509, NIP 586 227 35 14,Regon 22154369 kapitał zakładowy: 1.655.000 PLN...
-
Page 2: Basic Technical Parameters
Loading/unloading sections in supermarkets and large commercial premises, Car showrooms and service stations, exhibition surfaces BASIC TECHNICAL PARAMETERS * for water parameters 90/70 C, inlet air temperature 0 C max temperature of heating agent 130°C www.sonniger.com... - Page 3 Large space of PTC coil, enhanced energy exchange between coil and air. Fully automated regulation of heat capacity depending on air flow No risk of system overheat, thanks to „self colling” option (coil automatically decreases its temperature and heat capacity whan air flow goes down) Very low energy consumption www.sonniger.com...
- Page 4 Before mounting the device, read the manual carefully and adhere to the rules concerning the mounting procedures. Not applying to the rules may result in the inappropriate functioning of the device and the loss of the guarantee rights. Pay special attention when working with electrical elements of the device. www.sonniger.com...
- Page 5 N x 4 = number of GUARDPRO multi-purpose connectors Vertical assembly (N - number of curtains) (N x 4) – 2 = number of GUARDPRO multi-purpose connectors Installation of connector inside the curtain Installation of connector at the back of the www.sonniger.com...
- Page 6 Possibility to connect DOORSTOP door switch (start/stop at the moment of opening gate) Possibility to connect SPEEDER S2 speed regulator (for two GUARD PRO curtains) Possibility to connect SPEEDER S3 speed regulator (for three GUARD PRO curtains) Delivery does not include main/maintenance switch www.sonniger.com...
-
Page 7: Electrical Connection Diagrams
The regulation of air flow of GUARD PRO curtains by SPEEDER S2 - 10A or SPEEDER S3 - 14A speed regulator which is available optionally. 7.1 Connection scheme for GUARDPRO W (water coil) and C (without coil) with a switch and power board carried out by an installer. www.sonniger.com... - Page 8 ! Required electrical supply wires - 3 x 1,5 mm² for 2 GUARDPRO curtains (up to 6 fans) or 3 x 2,5 mm² for 3 pcs GUARDPRO curtains (up to 9 fans) ! Electrical connection, maitanance and service operations may be run while main supply is OFF. Only qualified staff is allowed to run above operations www.sonniger.com...
- Page 9 ! GUARDPRO 150E – supply wires min 5 x 4mm2, required protection B25 ! GUARDPRO 200E – supply wires min 5 x 6mm2, required protection B40 7.3 Connection scheme for GUARDPRO E (electric heater) with a switch and power board carried out by an installer. www.sonniger.com...
- Page 10 Operation and Maintenance Documentation of GUARD PRO air curtains v201708 7.4 Connection scheme for GUARDPRO E (electric heater) with CONTROLBOX S3 and SPEEDER S2 or SPEEDER S3 speed regulator. www.sonniger.com...
- Page 11 Operation and Maintenance Documentation of GUARD PRO air curtains v201708 8. DIMENSIONS GUARD PRO 150W, GUARD PRO 150C, GUARD PRO 150E, GUARD PRO 200W, GUARD PRO 200C, GUARD PRO 200E www.sonniger.com...
-
Page 12: Operation And Maintenance
If the device being operated gives metallic clatter, vibration or the level of noise is increasing, check if the mounting of the fan has not become loose – in case of any problems contact the installer of the device or the SONNIGER Authorized Service immediately. www.sonniger.com... -
Page 13: Guarantee Terms And Conditions
§ thermal shock of the heater and heat exchanger caused by sudden changes of outside temperature. §3. SONNIGER Poland is not liable to: Current maintenance works, inspections following from Operation and Maintenance Documentation and device programming. Defects caused by banking of a device while waiting for the warranty service. - Page 14 The Claimant is obliged to give a written confirmation of the service provided. Sonniger Poland is entitled to refuse the warranty service if Sonniger Poland has not received full payment for the product complained about under the Guarantee or any previous servicing activities.
-
Page 15: Guarantee Card
Details of installation company: :………………………………………………………………... Person activating the device Name of company:…………………………………………………………………………………………. …………………………………………………………………………………………………………….…. Address:…………………………………………………………………………………………………….. Telephone:…………………………………………………………………………………………………… Signature of a person who has started the device:……………………………………………………… Installation works, check-ups/inspections, repairs: Date The scope of installation works, inspections, repairs Signature and installation company stamp www.sonniger.com...
