BASIC TECHNICAL PARAMETERS Curtain with water heater Curtain with electric heater Curtain without heater TECHNICAL PARAMETER S GUARD 100W GUARD 150W GUARD 200W GUARD 100E GUARD 150E GUARD 200E GUARD 100C GUARD 150C GUARD 200C Lenght of unit Max installation height Max air output m³/h...
Page 3
Fully automatic heat control depending on airflow Complete elimination of the risk of a system overheating due to self-regulating heating modules (heat capacity automatically reduces when airflow goes down) Low energy consumption HEAT OUTPUT RANGES GUARD W GUARD 100W 50/30 60/40 70/50 80/60...
GENERAL AND SAFETY PRINCIPLES The GUARD air curtains are manufactured in compliance with the rules and standards concerning quality, ecology, utility, and work comfort. Before starting the device be sure to read the Manual carefully. The GUARD air curtains are delivered ready-to-use in a cardboard package that is to protect from any mechanical damage. The package consists of the device, the Manual (Operation and Maintenance Documentation), and the Guarantee.
Page 5
device, otherwise, it may be damaged. When tightening the pipeline to the exchanger, the heater connection must be protected against torque (which may cause leakage in the exchanger). Horizontal installation under the ceiling using mounting pins Installation under the ceiling is done by using 4 M8 pins. To hang the device on the pins, drill holes Ø 8-9mm in the EPP housing directly in front of the existing holes in the steel inlet grille.
Page 6
Installation using brackets for vertical mounting It is also possible to install the unit vertically with the engine downwards and upwards. Two vertical mounts are used for this purpose. In the brackets there are Ø9mm holes for M8 screws. In the EPP housing, drill holes Ø 12-13mm in front of existing holes in the steel intake grille.
CONTROL PANEL The system is ready to start once the connections between the thermostat and the valve actuator are done, 230V power is supplied to the thermostat and the fan’s motor is powered by the revs controller. COMFORT NEW panel description OFF-I-II-III - switch and fan speed regulation HEAT - the thermostat gives an operation signal to the actuator and fan, the fan turns off when the set temperature is reached, the valve closes the water supply...
Page 8
Power supply 230V/50Hz; protection of the C10 system; cross section of power supply cables min. 3 x 1.5 mm COMFORT control panel - 3-speed fan control with thermostat (min. 5x 1.0mm) Actuator valve - control 230V / 50Hz (min. 2 x 0.75mm - TS Lite SONNIGER),...
Page 9
8.3. Diagram of connection of one GUARD 100-150-200 E curtain (electric heater) to the COMFORT panel 8.4. Diagram of connection of two GUARD 100-150-200 E curtain (electric heater) to one COMFORT panel In the MASTER curtain between the L1-NC terminal, replace the factory-made fuse (C 3.15) with C 6.3 400V / 50Hz power supply;...
Page 10
CONNECTION DIAGRAM OF GUARD 100-150-200 W AND C WITH INTELLIGENT 9.1. Diagram of connecting one GUARD 100-150-200 W (water heater) and C (without heater) to the INTELLIGENT panel 9.2. Diagram of connecting two GUARD 100-150-200 W (water heater) and C (without heater) to the INTELLIGENT panel...
Page 11
9.3. Diagram of connecting one GUARD 100-150-200 E (electric heater) to the INTELLIGENT panel 9.4. Diagram of connecting two GUARD 100-150-200 E (electric heater) to the INTELLIGENT panel ATTENTION! PTC heaters power supply 3x400V/50Hz or 3x400V/60Hz min. 5 x 2,5 mm for G100E; (B16) min.
– in case of any problems contact the installer of the device or the SONNIGER Authorized Service immediately. TROUBLESHOOTING AND TECHNICAL PROBLEMS Possible problems and solutions are shown below. To eliminate a problem encountered contact the SONNIGER Authorized Service. Fault, symptoms...
Page 13
Intelligent WIFI allows to management work of the device via the mobile app TUYA SMART. Functions Panel INTELLIGENT is designed for the SONNIGER products • Weekly thermostat (5/1/1 days) •...
Page 14
Dimensions Settings menu When Panel Intelligent is switched off, press and hold MODE for 5 seconds To change option use MODE button. To change value use +/- buttons. Setting menu Option Value Temperature calibration –9°C ~ +9°C EEPROM 1: memory C1: Thermostatic mode Fan status C2: Continuous mode...
BMS Functions Setting/Reading work parameters Work/Stop conditions Weekly program Temperature Fan speed Heating, ventilation, cool mode Antifreeze mode Setting Paremeters Working Mode RS485 Semi-duplex; PC or main controller is master; thermostat is slave Interface A(+),B(-), 2 wires Baud Rate 0-2400 / 1-9600 / 2-19200 Byte 9 bits in total: 8 data bit + 1 stop bit Modbus...
▪ thermal shock of the heater and heat exchanger caused by sudden changes of the outside temperature. ▪ §3. SONNIGER Poland is not liable to: Current maintenance works, and inspections follow from Operation and Maintenance Documentation and device programming. Defects caused by banking of a device while waiting for the warranty service.
Page 17
The Claimant is obliged to give a written confirmation of the service provided. Sonniger Poland is entitled to refuse the warranty service if Sonniger Poland has not received full payment for the product complained about under the Guarantee or any previous servicing activities.
GUARANTEE CARD : …………………………………………………………………………… INVESTEMENT Device model:…………………………………………………………………………………………….… Serial number:……………………………………………………………………………………………... Date of purchase:………………………………………………………………………………....Start date: ………………………………………………………………………………………………….. Details of installation company: :………………………………………………………………... Person activating the device Name of company:…………………………………………………………………………………………. …………………………………………………………………………………………………………….…. Address:…………………………………………………………………………………………………….. Telephone:…………………………………………………………………………………………………… Signature of a person who has started the device:……………………………………………………… Installation works, check-ups/inspections, repairs: Date The scope of installation works, inspections, repairs Signature and installation company stamp...
