Bolt X

Electric Ride-On.

A guide for your ride.

IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE.

MODEL SKU: JBOLTX-BLK

FEATURING THE

SMART CARGO SYSTEM

Table of Contents

Need help?

Do you have a question about the Bolt X and is the answer not in the manual?

Questions and answers

Summary of Contents for Jetson Bolt X

Page 1 Bolt X Electric Ride-On. A guide for your ride. IMPORTANT: READ CAREFULLY AND RETAIN FOR FUTURE REFERENCE. MODEL SKU: JBOLTX-BLK FEATURING THE SMART CARGO SYSTEM...
Page 3 Jetson's top two riding rules: Be safe. Have fun!
Page 4: Table Of Contents
Contents Safety Warnings ........................4 Warranty Coverage .
Page 5 3. Functions & Features 3.1 Powering On & Off ......................3 3 3.2 Checking Battery Charge Level .
Page 6: Safety Warnings
Safety Warnings • Before use, please read the user manual and safety warnings carefully, and make sure you understand and accept all the safety instructions. The user will be responsible for any loss or damage caused by improper use. • Failure to use correct charger can result in fire and explosion, resulting in property damage, injury, and death. •...
Page 7: Maintenance Precautions
• AVERTISSEMENT- Risque d’incendie et de choc électrique - Aucune des pièces ne peut être réparée par l’utilisateur. MODIFICATIONS Do not attempt to disassemble, modify, repair, or replace the unit or any components of the unit without instruction from the Jetson Care Team. This will void any warranty, and can lead to malfunctions which may cause injury.
Page 8: Warranty Coverage
Your new Jetson product is warranted against defects in materials and workmanship as indicated on ridejetson.com/ warranty for a period of time from the date of original retail purchase when used in accordance with Jetson's user manuals (refer to ridejetson.com/support). Under this warranty, you will be able to direct your claims to Jetson even in situations where you purchased the Jetson Product from one of our authorized retailers.
Page 10: Product Overview
Product Overview 1. HANDLEBAR 4. FOLDING LATCH WITH LOCKING RING 14. DISC BRAKE A. POWER BUTTON 5. WHEEL REFLECTOR (X2; FRONT AND REAR) B. BELL (X2; FRONT AND REAR) 15. CARRYING HANDLE C. LEFT HANDBRAKE 6. WHEEL (X2; FRONT AND REAR) 16.
Page 11 10 15 NOTE: IMAGES MAY NOT REFLECT EXACT APPEARANCE OF ACTUAL PRODUCT.
Page 12 INCLUDED TOOLS FOR ASSEMBLY, TIGHTENING, AND MAINTENANCE: MULTI-TOOL TIP IDENTIFICATION: 6MM ALLEN KEY FLAT-HEAD SCREWDRIVER 5MM ALLEN KEY 10MM SOCKET 4MM ALLEN KEY 9MM SOCKET 3MM ALLEN KEY 8MM SOCKET 2.5MM ALLEN KEY 14 GAUGE SPOKE WRENCH 2MM ALLEN KEY 8MM HEX WRENCH MULTI-TOOL INCLUDING SOCKET SCREW...
Page 14: Product Specs
Product Specs · PRODUCT DIMENSIONS, UNFOLDED: 44.5” (L) × 19.3” (W) × 39.4” (H) · MOTOR: 250W · PRODUCT DIMENSIONS, FOLDED: 44.5” (L) × 13.6” (W) × 26.6” (H) · MAX SPEED: 15.5 MPH* · PRODUCT WEIGHT: 43.3 LB · MAX THROTTLE RANGE: 15 MILES* ·...
Page 15: Online Resources
Online Resources Scan for our most updated Bolt X onboarding materials and support resources.
Page 16: Getting Started
THE DIRECTIONS GIVEN IN THIS MANUAL—RIGHT, LEFT, FRONT/FORWARD, AND REAR/BACK—ARE ORIENTED AS THE RIDER WOULD SEE THEM WHEN SEATED ON THE BOLT X. THE "RIGHT SIDE" OF THE BOLT X, FOR EXAMPLE, IS THE SIDE WHERE THE RIDER'S RIGHT HAND WILL BE.
Page 17: Unfolding & Folding The Handlebar
Unfolding & Folding the Handlebar WHEN TO UNFOLD: FOR RIDING WHEN TO FOLD: FOR STORAGE AND TRANSPORT HOW TO UNFOLD: 1. GENTLY RAISE THE HANDLEBAR UNTIL THE STEM IS RESTING VERTICALLY ON THE FRAME. HANDLEBAR STEM FRAME...
Page 18 FOLDING LATCH 2. PUSH THE FOLDING LATCH IN UNTIL IT CLICKS INTO THE CLOSED (LATCHED) POSITION.
Page 19: Locking Ring
UNTIL THE TAB ON THE RING SLIDES INTO THE TAB SLOT ON THE LATCH. 4. CHECK THAT THE LATCH IS SECURED BY ENSURING THAT IT CANNOT BE PULLED OPEN. IMPORTANT: NEVER RIDE THE BOLT X WITHOUT THE FOLDING LATCH CLOSED AND SECURED BY THE LOCKING RING.
Page 20 HOW TO FOLD: 1. ROTATE THE LOCKING RING COUNTERCLOCKWISE AROUND THE STEM UNTIL THE TAB CLEARS FROM THE TAB SLOT ON THE FOLDING LATCH. 2. WHILE HOLDING THE HANDLEBAR STEM STEADY WITH ONE HAND, USE THE OTHER HAND TO PULL THE LATCH OPEN (UNLATCHED).
Page 22: Attaching The Seat
Attaching the Seat 1. PULL OPEN THE LATCH ON THE SEAT CLAMP. 2. LOCATE THE "MINIMUM INSERTION" MARK ENGRAVED NEAR THE BOTTOM OF THE SEAT POST. 3. HOLD THE SEAT IN POSITION ABOVE THE BIKE. 4. LOWER THE SEAT POST THROUGH THE CLAMP AND INTO THE SEAT TUBE UNTIL THE MINIMUM INSERTION MARK IS BELOW THE CLAMP.
Page 23 6. CHECK THAT THE SEAT IS SECURE: USE YOUR HAND TO PUT DOWNWARD PRESSURE ON THE SEAT. IF THE SEAT POST SLIPS FURTHER DOWN INTO THE TUBE, BRING IT BACK TO POSITION AND TIGHTEN THE CLAMP BY TURNING THE KNOB CLOCKWISE. TROUBLESHOOTING: IF YOU CANNOT OPEN THE CLAMP LATCH WITH EASE, THE KNOB MAY BE TOO TIGHT.
Page 24: Attaching The Foot Pegs
SPINDLE FOOT PEG Attaching the Foot Pegs 1. LOCATE THE HOLE ON THE END OF EACH FOOT PEG. 2. POSITION THE HOLE OF ONE FOOT PEG AGAINST THE END OF THE SPINDLE ON ONE SIDE OF THE FRAME. FULLY TWIST THE FOOT PEG CLOCKWISE ONTO THE SPINDLE. 3.
Page 25 4. CHECK THAT THE FOOT PEGS ARE SECURE.
Page 26: Securing The Bell
Securing the Bell 1. LOOSEN (BUT DO NOT REMOVE) THE SCREW ON THE BELL CLAMP BY TURNING IT COUNTERCLOCKWISE FOR 1 - 2 ROTATIONS WITH THE PHILLIPS-HEAD SCREWDRIVER TIP (8) OF THE MULTI-TOOL. 2. ROTATE THE BELL AROUND THE HANDLEBAR UNTIL IT IS IN A PLACE THAT CAN EASILY BE REACHED BY THE RIDER'S LEFT-HAND THUMB WHILE HOLDING ONTO THE HANDLEBAR.
Page 27: Securing The Front Reflector
PHILLIPS-HEAD SCREWDRIVER FRONT REFLECTOR SCREW Securing the Front Reflector 1. ROTATE THE FRONT REFLECTOR CLAMP AROUND THE HANDLEBAR UNTIL THE REFLECTOR IS FACING THE FRONT OF THE BIKE. 2. SLIDE THE REFLECTOR TOWARDS THE CENTER OF THE HANDLEBAR UNTIL THE REFLECTOR CLAMP FEELS SNUG ON THE THICKER PART OF THE HANDLEBAR.
Page 28: Preparing To Ride
2. Preparing to Ride Adjusting the Handlebar THE HANDLEBAR CAN BE ROTATED SLIGHTLY FORWARD OR BACKWARDS SO THAT ALL OF THE FEATURES AND FUNCTIONS ON IT ARE IN THE IDEAL POSITION. THEY SHOULD BE EASILY REACHABLE WHILE RIDING AND ANGLED IDEALLY IN THE LINE OF SIGHT FOR EACH USER.
Page 29 2. ROTATE THE HANDLEBAR FORWARD OR BACKWARD TO REPOSITION IT. 3. WHILE HOLDING THE HANDLEBAR IN THE NEW POSITION WITH ONE HAND, USE THE OTHER HAND TO PUSH THE LATCH DOWN AND BACK INTO THE CLOSED (LATCHED) POSITION. TROUBLESHOOTING: IF THE HANDLEBAR DOES NOT STAY SECURE WITH THE CLAMP CLOSED, YOU MAY NEED TO TIGHTEN THE CLAMP.
Page 30: Repositioning The Seat
Repositioning the Seat WHEN A RIDER IS SITTING ON THE SEAT AND HAS A FOOT ON THE PEDAL AT THE LOWEST PEDAL ROTATION POINT, THERE SHOULD BE A SMALL BEND IN THE KNEE. LEGS SHOULD NEVER BE FULLY EXTENDED DURING PEDALING. TO RAISE OR LOWER THE SEAT: 1.
Page 32: Charging The Battery
5. CLOSE THE CHARGING PORT COVER. CHARGER COMPATIBILITY: • ONLY USE THE INCLUDED CHARGER OR ONE OBTAINED DIRECTLY THROUGH JETSON LABELED WITH JY-420150 OR THE PART SKU PJBLTPX-CH. FAILURE TO USE CORRECT CHARGER CAN RESULT IN FIRE AND EXPLOSION, RESULTING IN PROPERTY DAMAGE, INJURY, AND DEATH.
Page 33 PLUG THE CHARGER INTO THE WALL BEFORE THE CHARGING PORT. • ALWAYS KEEP THE CHARGING PORT CLOSED WHEN NOT ACTIVELY CHARGING YOUR PRODUCT. NEVER TURN ON YOUR BOLT X WHILE IT IS CHARGING. • FOR BEST BATTERY HEALTH, CHARGE THE BATTERY FULLY DURING EACH CHARGING •...
Page 34: Tire Inflation & Pressure
3. REMOVE THE AIR PUMP AND REPLACE THE DUST VALVE BY TWISTING IT ON CLOCKWISE. 4. REPEAT WITH THE OTHER TIRE. IMPORTANT: ONLY USE A MANUAL AIR PUMP TO INFLATE THE TIRES ON YOUR BOLT X. NEVER USE AN AIR COMPRESSOR; DOING SO MAY CAUSE THE TIRE TUBES TO POP.
Page 35: Functions And Features
AUTO-OFF FEATURE: AFTER 10 MINUTES WITHOUT MOVEMENT, THE BOLT X WILL AUTOMATICALLY POWER OFF. QUICK-PRESS THE POWER BUTTON TO TURN IT BACK ON. IMPORTANT POWER NOTES: TO PRESERVE BATTERY POWER, ALWAYS REMEMBER TO POWER YOUR BOLT X OFF WHEN MAKING A PIT STOP OR PUTTING IT • AWAY FOR THE NIGHT.
Page 36: Checking Battery Charge Level
76-100% 51-75% 26-50% (CHARGE YOUR BOLT X NOW!) IMPORTANT: WHEN THE BATTERY CHARGE DEPLETES TO 0%, THE PRODUCT WILL POWER OFF. CHARGE TO FULL POWER (SEE SECTION 2.3) PRIOR TO YOUR NEXT RIDE. Using the Headlight IF RIDING IN LOW LIGHT CONDITIONS, TURN ON THE HEADLIGHT SO YOU CAN BETTER SEE THE ROAD AHEAD AND ONCOMING RIDERS CAN BETTER SEE YOU.
Page 37: Using The Kickstand
KICKSTAND Using the Kickstand TO USE THE KICKSTAND: PIVOT IT DOWN AND GENTLY TILT YOUR BIKE ONTO IT TO STAND. TO RAISE THE KICKSTAND: PIVOT IT BACK UP. IMPORTANT: ALWAYS RAISE THE KICKSTAND BEFORE RIDING.
Page 38: Using The Rackit Smart Cargo System Rack
Using the RackIt Smart Cargo System Rack YOUR BOLT X IS EQUIPPED WITH THE JETSON RACKIT SMART CARGO SYSTEM RACK — DESIGNED TO CARRY COMPANION “CLICK ON, CLICK OFF” CARRY-ALL ACCESSORIES*. BASKET COOLER TOTE BAG CUSTOMIZE YOUR BOLT X FOR YOUR CARRYING NEEDS. SCAN THIS TO LEARN MORE ABOUT THE SYSTEM AND AVAILABLE...
Page 39 USING THE RACKIT WITH A COMPANION CARGO ACCESSORY*: ALL RACKIT COMPANION CARGO ACCESSORIES HAVE AN INTEGRATED BASE PLATE THAT CLICKS SECURELY INTO THE RACKIT CARGO RACK. TO CLICK AN ACCESSORY ON OR OFF: SCAN THIS FOR INSTRUCTIONS *ACCESSORIES NOT INCLUDED. SELECTION MAY VARY.
Page 40 USING THE RACKIT WITHOUT A COMPANION CARGO ACCESSORY: 1. PLACE YOUR CARGO ON THE RACK. 2. SLIP 1 HOOK OF A BUNGEE STRAP INTO ONE BUNGEE ATTACHMENT LOOP ON THE RACK. 3. STRETCH THE BUNGEE STRAP OVER THE CARGO AND AROUND THE RACK UNTIL IT IS TAUT. 4.
Page 41 FOR SAFETY AND SECURITY: • ALWAYS SECURE CARGO TO THE RACK WITH A BUNGEE STRAP OR DEDICATED RACKIT CARGO ACCESSORY. NEVER RIDE WITH UNSECURED CARGO. • LIMIT CARRYING CONTENTS ON THE RACK TO 25 LB. • ENSURE THAT THE TOTAL CARRYING WEIGHT (RIDER PLUS CARGO) DOES NOT EXCEED 220 LB.
Page 42: Making Moves
4. Making Moves IMPORTANT: ALWAYS REST YOUR FEET ON THE FOOT PEGS. NEVER RIDE WITH THEM DANGLING OFF THE SIDE OF THE BOLT X. Using the Throttle TO ACCELERATE, SLOWLY ROTATE THE TWIST THROTTLE TOWARDS YOU WITH YOUR RIGHT HAND THUMB AND FOREFINGER.
Page 43: Activating Cruise Control
Activating Cruise Control CRUISE CONTROL LOCKS THE BIKE IN AT A CERTAIN PACE. ONCE YOU SET CRUISE CONTROL, THE MOTOR WILL DO THE WORK TO KEEP THE PACE — NO THROTTLE REQUIRED. CRUISE CONTROL/ HEADLIGHT BUTTON 1. USE THE THROTTLE TO REACH AND MAINTAIN YOUR DESIRED SPEED. 2.
Page 44: Using The Brakes
Using the Brakes SQUEEZE ONE OR BOTH HANDBRAKES TO SLOW DOWN; SQUEEZE MORE FORCEFULLY TO COME TO A COMPLETE STOP. TO AVOID ABRUPT MOVEMENTS, TRY TO SQUEEZE THE HANDBRAKE(S) GRADUALLY. LEFT HANDBRAKE FRONT WHEEL BRAKE • RIGHT HANDBRAKE REAR WHEEL BRAKE •...
Page 45: Maximizing Riding Range & Speed
Maximizing Riding Range & Speed THE HARDER THE MOTOR NEEDS TO WORK, THE FASTER YOUR BATTERY WILL DRAIN. IN IDEAL CONDITIONS, THE MAXIMUM MILEAGE THAT CAN BE ACHIEVED FROM A FULLY CHARGED BATTERY IS 15 MILES USING ONLY MOTOR POWER, AND THE MAXIMUM SPEED IS 15.5 MPH.
Page 46: Safe Journeying
5. Safe Journeying Pre-Ride Safety Checks ROLL SMOOTHLY AND SAFELY! CONDUCT THESE IMPORTANT SAFETY CHECKS BEFORE EVERY JOURNEY: BRAKES MAKE SURE THE BRAKES WORK PROPERLY SUCH THAT: THE HANDBRAKE LEVERS ARE SECURED TO THE HANDLEBAR AND LUBRICATED SO THEY COMPRESS EASILY. •...
Page 47 Helmet Safety A HELMET SHOULD BE WORN BY THE RIDER AT ALL TIMES. PROPER POSITIONING: IMPROPER POSITIONING: THE FOREHEAD IS COVERED THE FOREHEAD IS EXPOSED. BY THE HELMET. A FALL COULD RESULT IN SERIOUS INJURY. * WEAR A HELMET, APPROPRIATE CLOTHING, SHOES, AND SAFETY GEAR. AVOID CLOTHING THAT CAN GET CAUGHT INTO OR UNDER THE WHEELS.
Page 48: Care & Maintenance
Care & Maintenance TAKE GOOD CARE OF YOUR BOLT X TO KEEP IT IN GOOD SHAPE. HERE’S HOW: HANDLING YOUR BOLT X AVOID EXPOSING YOUR BOLT X TO SEVERE VIBRATION OR INTENSE PHYSICAL IMPACT. • NEVER DISASSEMBLE THE BATTERY. •...
Page 49: Stay Connected
Stay connected. Be sure to follow @ridejetson on social media to learn about fantastic offers, giveaways, and all the latest Jetson news. Loving your ride? Then be sure to leave a review at ridejetson.com/reviews. We can’t wait to hear from you!
Page 52 Date Code: 08/2024 Document Edition: v1.0 © 2024, JETSON. ALL RIGHTS RESERVED. Manufactured for TruRide Tech LLC. No portion of this document, including shape, copy, graphics, and design, may be reproduced or transmitted in any form or by any means.
