BLUETOOTH ELECTROMECHANICAL LOCK
INSTALLATION AND USE MANUAL
BT.P571... BT.P771...
BT.H571... BT.H771...
12V
6x1,5V
LR20 D
GENERAL INSTRUCTIONS
This manual is intended for technically qualified and trained installers.
Mottura Serrature di Sicurezza S.p.A. thanks you for choosing this product and reminds you:
- To read these instructions very carefully before installing this product and before doing any maintenance.
- That all assembly and connection procedures must follow good practice procedures and comply with current laws and standards.
- To NOT install this product in explosive rooms or atmospheres or in the presence of inflammable fumes/gases.
- DO NOT install this product on a door with risk of contact with water or atmospheric agents unless the door is adequately protected.
- To switch off the power supply and disconnect all live parts before doing any installation or maintenance work on the product. To take all possible
precautions to eliminate the risk of electrical shock when performing installation or maintenance procedures described in this manual.
- That the installer must deliver these instructions and all of the maintenance instructions to the user.
- To keep these instructions for future reference and attach the sales receipt to validate the warranty.
- To contact authorized dealers only in case of problems.
Mottura Serrature di Sicurezza S.p.A. may change the characteristics of the products described in these instructions at any time and without notice.
WARRANTY TERMS
This product has been inspected by Mottura Serrature di Sicurezza S.p.A. and is guaranteed to be free of all manufacturing defects for the time
specified by current Italian law, starting on the date of purchase indicated on the sales receipt. The warranty is in force if the sales receipt, showing
details identifying the product, is exhibited to customer service personnel. The warranty covers the replacement or repair of parts found defective
at origin due to manufacturing defects. Costs of shipping to and from service centres will be paid by the customer. In case of repeated malfunctions
of the same type or unrepairable defects, Mottura Serrature di Sicurezza S.p.A. may, at its own discretion, replace the entire product.
The warranty on the replaced product will continue until expiration of the original warranty. If service work must be performed at the customer's
premises, the customer shall – if requested – pay the authorised technical personnel travel expenses.
Risks related to product transportation shall be covered by the customer when shipped directly by the customer, and by the authorised technician
when the product is picked up and shipped by the technician
LIMITS OF LIABILITY
The warranty does not cover damage deriving from:
- Negligence, carelessness or use in any manner not described in these instructions
- Failure to protect the device before doing any procedure that may generate scrap or waste (welding, drilling of panels, drilling of structure, etc.)
that prevents its correct functioning
- Maintenance performed in any manner not described in these instructions or by unauthorised personnel
-Transport without the necessary precautions and from any circumstances that cannot be attributed to manufacturing defects.
In addition, Mottura Serrature di Sicurezza S.p.A. declines all liability for any damage to persons or property deriving from failure to observe all of
the precautions described herein.
N.B. : All electrical connections and mounting operations as well as subsequent service operations must be performed with
the product DISCONNECTED from the power supply system.
