USER'S MANUAL FOR DRY CONTACT FUNCTIONS ON X-NOVA
Rev.
Date
0
25/01/2016
1
22/02/2016
2
28/07/2016
3
03/02/2017
4
03/04/2017
5
20/04/2017
GENERAL INSTRUCTIONS
Mottura Serrature di Sicurezza S.p.A. thanks you for choosing this product and reminds you as follows:
- Read the instructions very carefully before installing the device or doing any maintenance work on the product.
- All assembly and connection procedures must be done according to the Rules of Good Practice as well as in
conformity to current law.
- DO NOT install the product in explosive environments or atmospheres or in the presence of flammable fumes/gases.
- DO NOT install the product on doors with risk of contact with water or atmospheric agents unless adequately
protected.
- Always switch off the power supply and disconnect all live parts before doing any installation or maintenance work
on the product. Take all possible precautions to eliminate the risk of electrical shock when doing the installation or
maintenance procedures described in this manual.
- In case of problems contact authorized dealers only.
When installing the lock, first connect all of the selected peripherals and then the power supply.
If you have to disconnect the wires, always disconnect the power supplies first.
The warranty does not cover damage due to negligence, carelessness or use in any manner not described in these
instructions
.
Mottura Serrature di Sicurezza S.p.A. may change the characteristics of the products described in this document and
of the document itself at any time and without notice.
Description
First emission
At paragraph 1 added indication "active low" for the input signal "IN" and corrected its
graphs to paragraph 2, 3 and 5.
At point 7 Introduced the Photo of the final prototype
At point 7 added Vinternal link on connector X7
At point 7 added in the table cable color code 99.727 Mottura connected to the
connector X7
Update of layout and graphics.
DRY CONTACTS MANUAL
1/5
Advertisement
Table of Contents
Related Manuals for Mottura XNOVA Series
Summary of Contents for Mottura XNOVA Series
- Page 1 The warranty does not cover damage due to negligence, carelessness or use in any manner not described in these instructions Mottura Serrature di Sicurezza S.p.A. may change the characteristics of the products described in this document and of the document itself at any time and without notice.
- Page 2 TECHNICAL DOCUMENT DRY CONTACTS MANUAL 1) INPUT DESCRIPTION The lock has three digital input (active low) to open it controllable by shorting the pins to GND with a dry contact. If an open collector device is used, make sure the polarity is correct (i.e. collector/drain connected to IN – emitter/source connected to GND) IN1 = open the lock IN2 = close the lock...
- Page 3 TECHNICAL DOCUMENT DRY CONTACTS MANUAL 3) HOW TO GET THE STATUS OF THE LOCK AND OPEN IT Before performing a maneuver we suggest to know the state of the lock, then make an opening. The lock remains awake (providing its status) for all the time necessary to complete the maneuvers. In the following example we show this general sequence: a) Wake up the lock with short time pulse at input IN (see the time 0.5 sec.
- Page 4 TECHNICAL DOCUMENT DRY CONTACTS MANUAL 5) INCREASE THE OPENING TIME OF THE LATCH BOLT When you run a command OPEN (IN) the latch bolt comes out just after the opening of the door (dashed line). If for some reason the door does not open, the latch bolt back outside after 10 sec anyway (Continuous line). Open signal Level Spring latch status signal with door opened at sec.
- Page 5 +Vdc (from battery pack 9V ) All other pins are not relevant [* Mottura cable color code 99.727] Mottura Serrature di Sicurezza S.p.A. Strada Antica di Francia, 34 - 10057 Sant'Ambrogio (TO) - Italia Tel. +39 011 9343111 - Fax +39 011 9312427...
