QUICK INSTALL GUIDE
Software Release 2.3.1
S i m p ly c o n n e c t i n g t h e wo r l d

Advertisement

loading
Need help?

Need help?

Do you have a question about the AR740 RPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allied Telesis AR740 RPS

Summary of Contents for Allied Telesis AR740 RPS

  • Page 1 AR740 RPS QUICK INSTALL GUIDE Software Release 2.3.1 S i m p ly c o n n e c t i n g t h e wo r l d...
  • Page 2 AT-RPS 740 Quick Install Guide Document Number C613-04025-01 REV B. Copyright © 1999-2001 Allied Telesyn International, Corp. 960 Stewart Drive Suite B, Sunnyvale CA 94086, USA. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn.

  • Page 3: Package Contents

    Quick Install Guide Documentation Roadmap AT -RPS 740 AT -AR740 Router Safety and Statutory Information AR Router Hardware Reference Quick Install Guide AR700 Series Router Quick Install Guide AR Router Software Reference General Customer Support AR740 Router Quick Start Guide Visit www.alliedtelesyn.co.nz for Application Notes the latest documentation, FAQs,...

  • Page 4: Selecting A Site

    AR740 RPS Selecting a Site The RPS unit can be installed in a standard 19-inch rack or on a level surface such as a desktop or bench. When installing the RPS, choose a site that: Allows adequate airflow around the RPS vents. If RPS units are stacked on top of each other, their rubber feet must be fitted.
  • Page 5 Quick Install Guide Connect the DC cable(s). Using the DC cables that were included with your RPS, connect each cable to a router and then to the RPS. Connect the AC power supply cable(s). Using the supplied AC power cord(s), connect the RPS to a mains power supply and then switch the power switch(es) to the ON position.
  • Page 6 AR740 RPS Fault Indicators and What They Mean LEDs on the rear panel indicate the RPS’s operational status. Table 1: LEDs. State Function Power Green The RPS unit is receiving AC power and the voltage is within an acceptable range.

  • Page 7: Where To Find More Information

    Quick Install Guide Where to Find More Information There are three sources of further information: The Statutory and Safety Information booklet for the AT-RPS 740, which includes important safety information and statutory declarations. The AR Router Hardware Reference, which includes detailed hardware specifications and pinout information for the RPS.
