smsng-g7 VESA adapter (V2)
Assembly
instructions
The VESA adapter is compatible with monitors from the Samsung (samsung.com)
Odyssey G6, G7, G8, neo G8, G9, neo G9 series and other models:
C49G94TSSR, C49G95T, C49HG90DMU, C49J890DKR, C49J890DKU,
C49J890DKUXEN, C49RG90, C49RG90SSI, C49RG90SSN, C49TG90,
C49UG90, C49UG90DMR, CHG90, CRG9, G9, G95A, G95NA, G95NC, G95T,
LC32G75T, LC32G75TQ, LC49G95T, LC49G97T, LC49G97TSSNXDC,
LC49J890DKEXXY, LC49J890DKUXEN, LC49RG90SSIXCI,
LC49RG90SSNXZA, LC49RG90SSRXUF, LC49RG90SSUXEN,
LC49UG90DMEXXM, LS49C954U, LS49C954UAKXKR, LS49CY955ENXZA,
LS49CY955EUXEN, LS49KG954ECXZW, LS57CG952NNXZA, S49A950U,
S49A950UIN, S49A950UIU, S49AG952NN, S49AG95NC, S49C954U,
S57C952NN, S95UC, neo G9
With the VESA adapter, you can conveniently attach your SAMSUNG monitor to a
monitor arm with a VESA hole pattern (75 x 75 mm). Use the supplied screws and
nuts for this.
Direct wall mounting is NOT possible as the VESA adapter already contains metric
threads through which no screws can be inserted for mounting to the wall.
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu
Advertisement
Related Manuals for 3idee smsng-g7
Summary of Contents for 3idee smsng-g7
- Page 1 VESA hole pattern (75 x 75 mm). Use the supplied screws and nuts for this. Direct wall mounting is NOT possible as the VESA adapter already contains metric threads through which no screws can be inserted for mounting to the wall. support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...
-
Page 2: Important Safeguards
Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability. -
Page 3: Waste Disposal
For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu... -
Page 4: Scope Of Delivery Accessories
Assembly instructions Scope of Delivery Accessories 1x smsng-g7-part1 1x smsng-g9-part2 4x M4x60 Screw with cross recess (SP60) 4x M4x35 Screw with cross 4x M4x14 Screw with cross recess (SP33) recess (SP2) -
Page 5: Horizontal Mounting
Assembly instructions Horizontal / Vertical Alignment Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can quickly be exceeded if not installed properly. We are continuously working on developing monitors and adapters that are also suitable for vertical orientation. -
Page 6: Assembly Instruction
Assembly instructions Assembly Instruction Step 1 To get the best possible mounting, please check if your Samsung monitor belongs to Option A or Option B models. Option A: CRG9, CHG90, G94T, G95T Option B: G8, neo G8, G9, neo G9 To ensure an optimal user experience, you should check whether you need the extension piece (smsng-g9-part2) or not. - Page 7 Assembly instructions Step 3 (Option A) Please check that all 4 screws are properly tightened. (Figure Figure 3 Step 3 (Option B) Please check that all 4 screws are properly tightened (Figure Figure 4 Step 4 ⚠ Important: If the instructions in this step are not suitable for your device, please follow the mounting guidelines of the manufacturer of your monitor arm or swivel arm to mount the monitor to the wall or swivel arm.
- Page 8 Assembly instructions Step 5 Please make sure that all 4 screws are tight. (Figure 6) Figure 6...
