3idee smsng-s27d Assembly Instructions Manual

Vesa adapter
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
smsng-s27d VESA adapter
Assembly
instructions
The VESA adapter is compatible with the following Samsung products
(samsung.com):
S20300BL, S22D360H, S22D391H, S24D360HL, S24D391HL, S27D360H,
S27D390H, S27D391H
With the VESA adapter, you can easily attach your SAMSUNG monitor to a monitor
arm with a VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for
this.
If you want to attach your VESA adapter directly to the wall, use suitable screws
and wall plugs (not included).
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu

Advertisement

loading
Need help?

Need help?

Do you have a question about the smsng-s27d and is the answer not in the manual?

Questions and answers

Related Manuals for 3idee smsng-s27d

Summary of Contents for 3idee smsng-s27d

  • Page 1 VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for this. If you want to attach your VESA adapter directly to the wall, use suitable screws and wall plugs (not included). support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...

  • Page 2: Important Safeguards

    Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability.

  • Page 3: Waste Disposal

    For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu...

  • Page 4: Scope Of Delivery Accessories

    Assembly instructions Scope of Delivery Accessories 4x M4x14 screw with cross recess 4x M4 nut with flange (SP1) (SP1)

  • Page 5: Horizontal Mounting

    Assembly instructions Horizontal / Vertical Alignment Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can quickly be exceeded if not installed properly. We are continuously working on developing monitors and adapters that are also suitable for vertical orientation.

  • Page 6: Assembly Instruction

    Assembly instructions Assembly Instruction Step 1 Place your SAMSUNG monitor securely on a soft surface. Now remove the base of your SAMSUNG monitor if it is attached. To do this, pull firmly on the base of your monitor and press it left and right at the same time.
  • Page 7 Assembly instructions Step 4 Now insert your monitor into the VESA adapter from above and hold your VESA arm from below at the same time. (Figure 4) Figure 4 Step 5 Done! Make sure that the VESA adapter comes off when you pull the monitor up.
