smsng-c24rg VESA adapter
Assembly
instructions
The VESA adapter is compatible with the following Samsung products
(samsung.com):
24CRG50, C24RG50FZR, C24RG52FQU, C24RG54FQU, LC24RG5, LC24RG50
With the VESA adapter, you can easily attach your SAMSUNG monitor to a monitor
arm with a VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for
this.
Direct wall mounting is NOT possible, as the VESA adapter already contains metric
threads through which no screws can be inserted for mounting to the wall.
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for 3idee smsng-c24rg
Summary of Contents for 3idee smsng-c24rg
- Page 1 VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for this. Direct wall mounting is NOT possible, as the VESA adapter already contains metric threads through which no screws can be inserted for mounting to the wall. support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...
- Page 2 Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability.
- Page 3 For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu...
- Page 4 Assembly instructions Scope of Delivery Accessories 4x M4x14 screw with cross recess (SP2)
- Page 5 Assembly instructions Horizontal / Vertical Alignment Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can quickly be exceeded if not installed properly. We are continuously working on developing monitors and adapters that are also suitable for vertical orientation.
- Page 6 ATTENTION: Make sure you use the right screws! (Figure 2) Step 3 This is how the 3idee VESA adapter should look after it is attached to your monitor arm. (Figure 3) Figure 3...
- Page 7 Assembly instructions Step 4 Now insert your monitor into the VESA adapter from above while holding your monitor arm from below. (Figure 4) Figure 4 Step 5 Done! Make sure that the VESA adapter comes off when you pull the monitor up. This is because the monitor is designed to remove the original Samsung monitor base (Figure 6).
