smsng-cwr32 VESA adapter
Assembly
instructions
The VESA adapter is compatible with the following Samsung products
(samsung.com):
32UR59C, LU32R590CWNXZA, LU32R590CWPXEN, LU32R592CWU,
U32R590, U32R590CWE, U32R590CWP, U32R590CWU, U32R591CWN,
U32R591CWU, U32R592CWR, U32R593CWR, U32R593CWU, U32R594CWR
(LU32R594CWRXZG), U32R594CWU (LU32R594CWXZG), UR59C
With the VESA adapter, you can easily attach your SAMSUNG monitor to a monitor
arm with a VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for
this.
Direct wall mounting is NOT possible, as the VESA adapter already contains metric
threads through which no screws can be inserted for mounting to the wall.
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu

Advertisement

loading
Need help?

Need help?

Do you have a question about the smsng-cwr32 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 3idee smsng-cwr32

Summary of Contents for 3idee smsng-cwr32

  • Page 1 VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for this. Direct wall mounting is NOT possible, as the VESA adapter already contains metric threads through which no screws can be inserted for mounting to the wall. support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...

  • Page 2: Important Safeguards

    Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability.

  • Page 3: Waste Disposal

    For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu...

  • Page 4: Scope Of Delivery Accessories

    Assembly instructions Scope of Delivery Accessories 4x M4x14 screw with cross recess 2x M4x14 screw with cross recess (SP2) (SP4)

  • Page 5: Horizontal Mounting

    Assembly instructions Horizontal / Vertical Alignment Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can quickly be exceeded if not installed properly. We are continuously working on developing monitors and adapters that are also suitable for vertical orientation.

  • Page 6: Assembly Instruction

    Remove the base of your Samsung Curved monitor. First remove the round cover on the back of the monitor. Step 2 Now lever the 3idee VESA adapter into the receptacle on the back of the screen. (Figure 1) Figure 1...
  • Page 7 Assembly instructions Step 5 ⚠ Important: If the instructions in this step are not suitable for your device, please follow the mounting guidelines of the manufacturer of your monitor arm or swivel arm to mount the monitor to the wall or swivel arm. We recommend a second person for this step.
